Navigation of the plant using the maps
The topological nodes of the plant can be navigated using the maps and exploiting the "sensitive" areas
identified during map construction. Five "sensitive" areas (the five blocks) marked with their labels are
identified in the image below (site map):
Figure 114: site map displayed with "sensitive" areas
DS1060-121G
