If the call is directed to several switchboards, a static image is displayed in the video image area
(3); press it (by left-clicking) to display the images taken by the calling station camera. The video
stream can be viewed on one switchboard only and no longer on several switchboards at the
same time: this means that if a second switchboard (only during the call phase) requests the
video stream, this is no longer available to the first one that had already requested it.
The operator can establish an audio-video connection with the visitor clicking on the answer button (10)
(if a headset is used) or picking up the handset of Door phone 1060/41 (in this case green icon is
frozen and does not blink).
If the operator is busy on another conversation, new call from calling station will be notified inside free
panel call data area (7) o (8).
To answer, the operator must press on the data area from which the new call originates (7) or (8);
The previous conversation is put on hold.
To close a communication, click on button
been received) or hang up handset of
To resume the call on hold, the operator must click on button
related call data area panel (7) o (8).
If both call data areas are busy, the calling station signals Busy on its display (if not equipped with
display, it emits a deterrence tone).
For all the details on how to call from a calling station the switchboards of a system (of
competence or not) see
installation manuals of the various calling stations.
If the Switchboard application is running in background on your PC screen, the incoming call from
a calling station is shown by the Switchboard application icon on the open taskbar, which starts
flashing.
22
(4) o (6) (according to the panel on which the call has
1060/41.
Door phone
the system technical manual for the installer
(12) after having clicked on the
or the user's and
