Parameters in the adjustable menus
Setting of the various parameters in
the adjustable menus
Kanal 1
7.55
Kanal 3
635
mV
ORP
Fig. 6: Example of a continuous display when used with 3 meas‐
uring channels (e.g. pH/chlorine/ORP) and the display of all 3
measuring channels
No time-controlled menu items
The controller does not exit any menu items in a
time-controlled manner, the controller remains in a
menu item until this menu item is exited by the
user.
1. Select the desired parameter in the display using
ð There is an arrow tip in front of the selected parameter,
which indicates the selected parameter.
2.
Press .
ð You are now in the setting menu for the desired param‐
eter.
3. You can adjust the desired value in the setting menu using
the four arrow keys and then save it using
ð
Range error
If you enter a value that is outside the
possible setting range, the message
[Range error] appears after
pressed. Pressing
the value to be set.
The controller returns to the menu once
pressed.
Cancelling the setting process
Pressing
without a value being saved.
Operating concept
Kanal 2
0.30
.
has been
or returns you to
has been
returns you to the menu
A2441
or .
