Existing limit value error with alarm
14.2

Setting limit values channel 1

Limit values ch. 1
Limit value 1
Limit value 2
System response / hysteresis
Fig. 98: Setting limit values channel 1
14.2.1

Setting [Limit 1]

You can manually reset an existing limit value error with alarm,
for instance to enable a controlled restart of a system to ensure
that the limit value situation can be left.
If an alarm is pending, you can call up the
from the continuous display by pressing
question and use to reset. Resetting the alarm cancels the limit
value error/alarm. Checking of the limit value criterion restarts in
line with the delay periods set. Metering is started if necessary.
Continuous display ➨
[Limit values] ➨
or
[Limit value channel 1]
Continuous display ➨
[Limit values] ➨
or
[Limit ch. 1] ➨
➨ or
Limit 1
Function
Value
ON delay
OFF delay
No relays assigned!
Please assign in <Relays> menu.
Fig. 99: Setting Limit 1
Setting the
[System alerts] menu
. Select the alarm in
[Limit values] ➨
➨ or
[Limit value channel 1] ➨
4.1.5
A1012
[Limit values] ➨
➨ or
[Limit value channel 1] ➨
[Limit 1]
Low limit
6,00 pH
[Limit values]
[Limit ch. 1]
4.1.1.4
A1013
