ProMinent DULCOMETER diaLog DACb Assembly And Operating Instructions Manual page 156

Function: Data logger
156
The maximum file size is 2 GB
The maximum file size is 2 GB. The SD card needs
to be the same size.
Record
New
DATALOG0.CSV
Fig. 122: Check the file to write it to an existing file, here
[DATALOG0.CSV]
3. If you wish to attached measured data to an existing file, then
check this file and the data will be written to this file
If the SD card is removed, then data can be recorded for a max‐
imum of 24 hours in the controller's internal memory with a storage
interval of 10 seconds. Around six times as long with an interval of
60 seconds. When the SD card is re-inserted into the controller,
then the data from the internal memory is backed up to the SD
card. This can take up to 20 minutes if 24 hours of data has been
recorded. The green LED on the SD card reader flashes red/
orange during this time.
9.1.3.4.1
