3.2 Identity code

Tab. 3: Device identification / Identity code
DAC: DULCOMETER, Multi-parameter Controller diaLog DACb
Mounting type
W Mounted on a surface
S Mounted on a control panel
E Spare parts assemblies
Design
00 with ProMinent logo
01 without ProMinent logo
E0 Spare part, processor, complete
E2 Spare part, HMI, complete, with PM logo
E3 Spare part, HMI, complete, Pool design
Operating voltage
4 24 V DC
6 100 - 230 V AC 50/60 Hz
Basic measured variables
VA mV/mA measuring input
AA mA/mA measuring input
VV mV/mV measuring input
L3 Conductive conductivity
Extended functions
0
1
2
3
4
none
Hardware preparation
Package 2: interference variable (mA) or external remote setpoint via mA, both
acting on channel 1
Package 3: 2nd measurement + control, additionally 2 pumps, additionally 3
control inputs
Package 4: combination of packages 2 and 3
Software default settings
0 No default settings
Connection of measured variables
0 All sensor inputs via terminal
1 1x mV input on SN6 socket
2 2x mV inputs on SN6 socket
3 3x mV inputs on SN6 socket
Connection of digital sensors/actuators
0 none
Communication interface
X none
Nameplate and ID code
