Calibration
12.2

Calibrating the ORP Sensor

12.2.1

Selecting the calibration process for ORP

Selecting the calibration process
Selecting the calibration process
12.2.2

1-point calibration of ORP sensor (CAL)

88
There are two calibration processes available for calibrating the
controller:
1-point (with buffer solution)
n
Data input
n
1.
Continuous display ➨
CAL ORP
Offset
Last calibration
CAL setup
Calibration process
Pot. equalisation
continue with <CAL>
Fig. 51: [ORP] calibration menu
ð The calibration menu is displayed.
2.
Use to select the Setup menu or start calibration by
pressing
3. [CAL Setup] : Press
ð The menu for selecting the calibration process appears.
4. Using the arrow keys select the required menu item
[Calibration process] and press
ð The input window appears.
5. Use the arrow keys to select the calibration process and
press
6.
Continue with
ð You can now start your chosen calibration process.
Correct sensor operation
Correct measuring and metering is only pos‐
–
sible if the sensor is working perfectly
Refer to the sensor's operating instructions
–
– Remove the sensor from the in-line probe
housing and re-fit it for calibration. To do this,
refer to the operating instructions for your in-
line probe housing
0.0 mV
13:26:11
11/04/2013
1 point
No
A1027
