Operating concept
1.1 Display and keys
Fig. 1: Operating cross (1) / Active keys are displayed in [black] in the display; inactive keys in [grey].
Continuous display
Fig. 2: A display change is made within a sequence of actions.
I.
Continuous display 1
II. Display 2
III. Display 3
IV. Display 4
1.
The following path is shown as an example:
Continuous display ➨
[Slope] ➨
➨
[Calibrate]
The function of the keys is described in the table
'Functions of the keys ' on page 10 .
➨ = describes as a symbol an action by the operator that leads to
a new possibility for an action.
[Naming in the display] = square brackets contain the name that
appears with the identical wording in the controller display.
Additional information can be obtained via the
Illumination of the display
In the event of an error with the status [ERROR],
the backlight of the display changes from 'white' to
'red' . This makes it easier for the operator to react
to an error.
➨
or
[Calibrate] ➨
.
[Slope]
Operating concept
A1035
➨
or
A1036
Ä Chapter 1.2
key.
7
