Assembly and installation
9.4.5.2.2 Terminal diagram for the extension unit (channel 3) with assignment options
Stromquelle
Fig. 21: Terminal diagram for the extension unit (channel 3) with assignment options (module C, optional)
46
Normsignal-Ausgang3 0/4-20 mA
Digitaler Kontakteingang
Digitaler Kontakteingang
Digitaler Kontakteingang
Temperatur
Potenzialausgleich
Temperatur
Normsignal-Eingang
2-Leiter-Normsignal-Eingang
Sensor
Externe Pumpe 3, heben (potenzialfrei)
Externe Pumpe 4, senken (potenzialfrei)
Only one main measured variable, e.g. pH, may be connected to a
unit. The mA signal of a magnetically inductive flow device can
also be connected depending on the ID code.
XK2, XK3, XA3, XA4, XE7, XE8: see terminal type 2
9.4.4.2 'Terminal type 2' on page 41
XE6: see terminal type 5a
(single terminal for internal conductor as a coaxial cable):'
on page 42
XE5: see terminal type 5b
(single terminal for external conductor as a coaxial cable):'
on page 42
Ä Chapter 9.4.4.5 'Terminal type 5a
Ä Chapter 9.4.4.6 'Terminal type 5a
A1174
Ä Chapter
