11.1.11
Temperature
Measured variable temperature [mA],
(as main measured variable):
11.1.12
mA general
Measured variable [mA general]
11.1.13
Features of the two-channel version
Two channel version
Two channel version with two iden‐
tical measured variables
[mA] , (as main measured variable)
For the measured variable
temperature measuring transducer or a Pt100V1 measuring trans‐
ducer is prerequisite. The measuring range is: 0 ... 100 °C. A tem‐
perature sensor cannot be connected directly to the controller.
[mA general] measured variable, various preselected
With the
measured variable can be selected and/or one measured variable
can also be freely edited with its unit of measure. The temperature
measurement cannot be used for compensation purposes,
because the influence of the temperature measurement on the
measured value is not known. In principle, the settings are per‐
formed in the same way as with the other measured variable. A
standardised calibrated signal is expected by the controller from
each connected device
If a second measuring channel is available (dependent on the iden‐
tity code, channel 2), then this second measuring channel can be
configured according to the descriptions of the first measuring
channel.
If the measured variables of measuring channel 1 and measuring
channel 2 are chosen identically, then the menu item
[Differential meas] appears in the [Measurement] menu. The
[Differential meas] function is switched off "ex works". The function
[Differential meas] can be activated and the calculation [K1-K2]
executed. The result of the calculation is displayed in the main dis‐
play 2 by pressing the
key again you jump back to the main display 1. The limit value cri‐
teria for the
[Limit values] .
Setting measured variables
'Temperature [mA]' use of a DMTa
key or
key. By pressing the
[Differential meas] can be set in the menu
or
73
