Parameter
[Function]
[Max. stroke rate]
[Assignment]
Maximum pump frequency
The pumps are activated according to the control
variable up to the pump's respective maximum
stroke rate.
Continuous display ➨
[Pump 1 channel 1] ➨
or
Pump 1
Function
Max. stroke rate
Assignment
Fig. 103: Setting [Pump 1]
Use the
ð The relevant setting menu appears.
Settable function
Set the pump to:
[Increase value]
n
[Decrease value]
n
[Off]
n
The maximum stroke rate can be set freely between 0 ... 500 /min.
The factory setting is 180/min
Assign the pump to the relevant measuring channel:
Channel 1: Pump 1 and pump 2
n
Channel 2: Pump 3 and pump 4
n
[Pumps] ➨
➨ or
Decrease value
Channel 1
or keys to select the menu and confirm with
[Pumps]
Setting the
[Pumps] ➨
A1068
