Tab. 14: Sensor connection cable, coaxial, for terminal XE1/XE2 and X5/X6
Designation
Cable combination, coaxial, Ø 5 mm 0.8 m - SN6 – pre-assembled.
Cable combination, coaxial, Ø 5 mm 2 m - SN6 – pre-assembled.
Cable combination, coaxial, Ø 5 mm 5 m - SN6 – pre-assembled.
9.4.5.5 Module: 2x conductive conductivity/temperature sensors. Part number 734223
Belegungsvarianten
Kanal 1
Fig. 27: Module: 2x conductive conductivity/temperature sensors. Part number 734223
A module for the direct measurement of two pH values or two
redox potentials or pH value and redox potential via a coaxial
cable.
For the direct connection of pH and ORP sensors.
n
Maximum cable length: 10 m
n
Kanal 2
A module for the direct measurement of the electrolytic conductivity
based on the conductive principle. For the direct connection of 2
electrode conductivity sensors.
Connectible conductor:
XE1, XE2, XE3, XE4: see terminal type 4
minal type 4 (plug-in terminal):' on page 42
Maximum cable length: 30 m, screened.
n
Assembly and installation
Part number
1024105
1024106
1024107
2x Konduktive Leifähigkeit/
Temperatur
Ä Chapter 9.4.4.4 'Ter‐
