Subsequent Extension of Functions

6 Subsequent Extension of Functions
Installed
Package 2
Package 3
Package 0=no data
logger
Manual entry of the activation code:
24
User qualification, subsequent extension of functions: trained
n
user, see
Prerequisite: The hardware for channel 3 must be available in the
controller. The data logger can be enabled without the need for
extension of the hardware. Missing hardware must be retrofitted in
the manufacturer's factory. Channel 2 can be enabled from
upgrade package 2 or upgrade package 3. The upgrade packages
correspond to the upgrade packages also described in the identity
code. The data logger function can always be enabled.
Validity of the activation code
An activation code is only valid and can only be
used for the relevant controller with the specified
serial number.
The activation code can be transmitted via email and is then read
into the controller from the SD card (maximum 32 GB) or entered
using the controller keypad. The enabled function is then available
and need only be activated and parametrised.
The following information must be available to determine the acti‐
vation code:
The serial number of the controller in question, see operating
n
menu under
the upgrade package required.
n
Required
Upgrade: Package 2 to package 3.
Upgrade: Package 2 to package 4.
Upgrade: Package 3 to package 4.
Upgrade: data logger.
1. Press
2.
Use
3.
Press
4.
Use
5.
Press
6. Select
7.
Press
8. Use the 4 arrow keys to enter the activation code.
9. Press
10. Use
11. Press
ð The controller is now restarted.
Ä Chapter 2.4 'User qualification' on page 16
[Diagnostics] , [Device information,] .
.
[Setup] .
and to select
.
[Activation code] .
and to select
.
[Manual input] .
.
.
[Double check] .
and to select
.
Order number
1047874
1047875
1047876
1047877
