Assembly and installation
9.4.4.4 Terminal type 4 (plug-in terminal):
Tab. 10: Connectible conductor:
Component
Bared length (without cable end sleeve):
single-wire:
fine-wired:
with cable end sleeve with collar:
with cable end sleeve:
9.4.4.5 Terminal type 5a (single terminal for internal conductor as a coaxial cable):
Tab. 11: Connectible conductor:
Component
Terminal area (single and fine-wired):
Bared length:
9.4.4.6 Terminal type 5a (single terminal for external conductor as a coaxial cable):
Tab. 12: Connectible conductor:
Component
Terminal area:
Bared length:

9.4.5 Terminal diagram

9.4.5.1 Requirements
Only one sensor per assembly
The controller comes with terminal diagrams showing 1:1 assignment.
42
Value
8 mm
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 14
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 14
min. 0.2 mm², max. 0.75 mm²;
or min. AWG 24, max. AWG 20
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 16
Value
min. 0.33 mm², max. 1.5 mm²;
or min. AWG 22, max. AWG 16
see drawing, Fig. 32
Value
shielding diameter min. 1 mm, max. 5 mm
see drawing, Fig. 32, tighten manually.
You can connect 2 sensors to the base assembly and 1 sensor to
the extension assembly.
For example, you can connect a chlorine sensor and an ORP
sensor to the base assembly and a pH sensor or an interference
variable to the extension assembly.
