9.4.4.1 Terminal type 1
Tab. 7: Connectible conductor:
Component
Bared length (without cable end sleeve):
single-wire:
fine-wired:
with cable end sleeve with collar:
with cable end sleeve:
9.4.4.2 Terminal type 2
Tab. 8: Connectible conductor:
Component
Bared length (without cable end sleeve):
single-wire:
fine-wired:
with cable end sleeve with collar:
with cable end sleeve:
9.4.4.3 Terminal type 3 (plug-in terminal):
Tab. 9: Connectible conductor:
Component
Bared length:
single-wire:
fine-wired:
with cable end sleeve with collar:
with cable end sleeve:
The respective permitted line cross-section can be found in the
details below on the respective terminals.
Value
10 mm
min. 0.75 mm², max. 4 mm²;
or min. AWG 18, max. AWG 12
fine-wired: min. 0.75 mm², max. 2.5 mm²;
or min. AWG 18, max. AWG 14
with cable end sleeve with collar: min. 0.75 mm²,
max. 1.5 mm²;
or min. AWG 18, max. AWG 16
with cable end sleeve: min. 0.75 mm², max. 2.5 mm²;
or min. AWG 18, max. AWG 14
Value
10 mm
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 14
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 14
min. 0.25 mm², max. 0.75 mm²;
or min. AWG 24, max. AWG 20
min. 0.25 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 16
Value
12 mm
min. 0.2 mm², max. 2.5 mm²;
or min. AWG 24, max. AWG 14
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 16
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 16
min. 0.2 mm², max. 1.5 mm²;
or min. AWG 24, max. AWG 16
