ProMinent DULCOMETER diaLog DACb Assembly And Operating Instructions Manual page 45

Mains voltage
Mains voltage
Mains voltage
Mains voltage
Mains voltage
Safety low voltage
Fig. 20: Terminal diagram with assignment options.
Voltage output
Digital contact input 1
Digital contact input 2
Digital contact input 3
Digital contact input 4
External, pump 1, raise (potential-free)
External, pump 2, lower (potential-free)
Standard signal output 1 0/4-20 mA
Standard signal output 2 0/4-20 mA
Solenoid valve 1 (raise)
Solenoid valve 2 (raise)
Alarm relay
40252229
XP1, XR1, XR2, XR3: see terminal type 1
minal type 1' on page 41
XK1, XK2, XK3, XA1, XA2, XA3: see terminal type 2
9.4.4.2 'Terminal type 2' on page 41
Assembly and installation
A2465
Ä Chapter 9.4.4.1 'Ter‐
Ä Chapter
45
