7
Functions to Backup the Controller's Setting Data
Saving the unit configuration as a text
file
Maximum size of the SD card:
Copying unit configuration onto the
SD card:
Functions to Backup the Controller's Setting Data
User qualification, backup setting data: trained user, see
n
Ä Chapter 2.4 'User qualification' on page 16
The following functions are available:
Save unit configuration as a text file.
n
Save unit configuration on an SD card.
n
Upload unit configuration from SD card into DACa.
n
32 GB
The function enables you to save the unit configuration on the SD
card (maximum 32 GB) for documentation purposes and to print or
document using a PC and printer. The file that is written has the
name CONFIG.TXT and the ASCII file format. There needs to be
an SD card with free memory space in the controller's reader.
Proceed as follows to save the configuration as a pure text file on
the SD card:
1.
Press
key
2.
Use
and
to select
3.
Press
.
4.
Use
and
to select
5.
Press
.
6.
Use
and
to select
7.
Press
.
8.
Use
and
to select
[Save unit configuration as a pure text file] .
9.
Press
.
ð The configuration is now saved, which takes approx. 5
minutes.
10.
Then press
.
11.
You can now remove the SD card and process the file, if nec‐
essary, or simply leave the file on the SD card. This file
cannot be read back by the controller.
[Copy unit configuration file onto SD card] function is used for
The
documentation or backup purposes. You can use this file to dis‐
tribute a recurring unit configuration to different controllers. You
can save the unit configuration set on one controller as a unit con‐
figuration file on the SD card. When it is saved, the directory
CONFIG is saved on the SD card and the file CONFIG.BIN is
saved in this directory. This file saves all user-dependent controller
setting data. Sensor calibration data is not copied as this data has
to be defined separately for each measuring point. There needs to
be an SD card with free memory space in the controller's reader.
1.
Press
2.
Use
and
to select
3.
Press
.
4.
Use
and
to select
5.
Press
.
[Setup] .
[Extended configuration] .
[Upload or save unit configuration] .
[Setup] .
[Extended configuration] .
25
