d. Click the Display Settings > Color Bit Depth drop-down list (see
all outputs in the KVM workstation to 8-bit depth or Auto. Auto (if selected) communicates with the
display to check its capabilities and sets the color bit depth accordingly.
e. Click the HDCP Mode drop-down list to select between Follow Input, Always Encrypt, and Disable
Authentication for all outputs in the workstation.
NOTE:
• Follow Input mimics the HDCP encryption state of the connected source.
• Alway Encrypt maintains the HDCP encrypted state with the output display device to improve
system switching performance.
• Disable Authentication disables HDCP Authentication and encryption attempts with the
connected sink devices, making the display behave as a non-HDCP compliant.
8. Click the Display ID drop-down list (
the desired display within the workstation display layout. In Use
the layout.
NOTES:
• A KVM workstation can have up to four decoders associated with it.
• In the Output Assignment area:
= indicates that a decoder has been assigned to a display.
= indicates that no decoder is assigned to the display.
TIPS:
• If necessary, drag the left scroll bar (
• Click the blank space in the Display ID menu to unassign the decoder.
• Use the ID function to help identify a decoder to easily identify the display and verify that the right
decoder is selected, as follows:
• Press and release the device ID button (
the Output Assignment area. Press and release the button again to clear the highlight.
• Click the ID button or ID All button (
LED and the on-screen display for an individual decoder or all decoders on and off.
9. Select K/M (
) for the decoder that is to be primary in the workstation. The primary decoder must have a
8
keyboard and mouse connected.
NOTES:
• Only one decoder can be primary and have K/M selected.
• Only the primary decoder should have a physically connected keyboard and mouse.
• The primary decoder must have USB enabled and its device class filtering set to HID only (see
Configure the USB settings
• The K/M radio button is unavailable for selection if the USB is disabled on the NAV 5nn decoder or if
the device class filtering is not set to HID only.
• The K/M column displays
• You cannot Save the configuration (see
) for one or more desired decoders to assign that decoder to
6
) to display additional decoders.
C
) on the front panel of a decoder to highlight the ID field in
D
) in the Output Assignment area to toggle the front panel ID
E
on page 55.
if the decoder is not in the NAV 5nn series.
step 12
on page 84) unless one K/M decoder is selected.
NAVigator System Manager • HTML Operation
figure 84,
on page 82) to force
5
changes to
for that display (
) in
7
83
