- Page 1 User Guide TouchLink ® TLP Pro 525, 725, and 1025 Series TouchLink Pro Touchpanel Control Systems 68-2831-01 Rev. C 09 18...
- Page 2 Safety Instructions Safety Instructions • English Istruzioni di sicurezza • Italiano AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad WARNING: This symbol, ,when used on the product, is avvertire l’utente della presenza di tensione non isolata pericolosa intended to alert the user of the presence of uninsulated dangerous all’interno del contenitore del prodotto che può...
- Page 3 より 『Extron Safety www.extron.com and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください。 Copyright © 2017-2018 Extron Electronics. All rights reserved. www.extron.com All trademarks mentioned are the property of their respective owners.. Trademarks All trademarks mentioned in this guide are the properties of their respective owners.
- Page 4 FCC Class A Notice NOTE: This FCC Class A Notice applies to TLP Pro 725 Series models. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 5 ATTENTION : Débarrassez-vous des piles utilisées selon le mode d’emploi. Class 1 Laser Product Any service to this product must be carried out by Extron Electronics and its qualified service personnel. CAUTION: Using controls, making adjustments, or performing procedures in a manner other than what is specified herein may result in hazardous radiation exposure.
- Page 6 FCC Radio Frequency Interference — Safety Notices NOTE: The Safety Notices and Industry Canada Notices on this and the following pages refer to the TLP Pro 525M and TLP Pro 1025T models. Antenna Warnings WARNING: The radiated output power of the wireless device is far below the FCC radio frequency exposure limits.
- Page 7 Radio Frequency (RF) Exposure Information This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the antenna and your body. IC conformité Canada, avis d’Industry Canada (IC) CAN ICES-3 (B)/NMB-3(B) Cet appareil est conforme aux normes des cahiers des charges sur les normes radioélectriques...
- Page 8 Conventions Used in this Guide Notifications In this user guide, the following are used: WARNING: Potential risk of severe injury or death. AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. CAUTION: Risk of minor personal injury. ATTENTION : Risque de blessure mineure.
-
Page 9: Table Of Contents
Contents Introduction Configuration Software ............1 ........21 About the TLP Pro 525, 725 and 1025 Series ..1 Configuration Software ..........21 Features ..............2 Installing GUI Designer, Global Configurator, All Models ............2 Toolbelt, and Room Agent ........22 TLP Pro 525M, TLP Pro 725M, and Using the Software ..........23 TLP Pro 1025M ..........2 Touchpanel Web Page ..........24... - Page 10 TLP Pro 525, 725, and 1025 Series Touchpanels • Contents...
-
Page 11: Introduction
Introduction This guide describes the function, installation, and operation of the following Extron Touchlink Pro Touchpanels: TLP Pro 525M, TLP Pro 525M NC, TLP Pro 725M, TLP Pro 725M NC, TLP Pro 1025M, • and TLP Pro 1025M NC — wall mountable touchpanels. -
Page 12: Features
The TLS 525M, TLS 725M, and TLS 1025M have the same physical appearance as the corresponding TLP Pro models but have different firmware. The TLS models can only be used with the room scheduling software (see the Room Agent Help File and Room Agent User Guide, which are available at www.extron.com Features... -
Page 13: Application Diagram
Tx Rx Tx Rx DTP OUT Tx Rx Extension 50/60 Hz Extron TLP Pro 725T RS-232 over DTP Ethernet 7" TableTop TouchLink Pro HDMI Touchpanel COM 1 COM 2 DIGITAL I/O IPCP PRO 250 Tx Rx RTS CTS Tx Rx POWER... -
Page 14: Installation Overview
Before starting to install the TLP Pro models, download and install the latest versions of the following software: GUI Designer — For designing layouts for Extron TouchLink Pro touchpanels and third … party touch interfaces. Global Configurator Plus and Professional — For setting up and configuring the …... - Page 15 Mount and cable the units: ATTENTION: Do not power on the touchpanels or control processors until you have read the • Attention about Power over Ethernet (PoE) power supplies (see page 10). Ne branchez pas les écrans tactiles ou les processeurs de contrôle avant d’avoir lu •...
-
Page 16: Panel Features
Panel Features This section describes the TLP Pro touchpanels: Front Panel Features • Rear Panel Features • TLP Pro 525T, TLP Pro 725T, and TLP Pro 1025T Base • Front Panel Features Figure 2 shows the TLP Pro 725M (left) and TLP Pro 725T (right) front panels. The front panels for all models have the same features and are very similar, apart from size. - Page 17 Communication LED — (see figure 2 on the previous page). Shows the configuration and connection status of the touchpanel: Unlit during normal operation (the touchpanel is configured and connected to an • IP Link Pro control processor). Blinks if the touchpanel has been configured but is not connected to an IP Link Pro •...
-
Page 18: Rear Panel Features
Rear Panel Features Figure 3 shows the rear panels of the TLP Pro 525M (top left), TLP Pro 725M (bottom left), TLP Pro 1025M (top right) and TLP Pro 725T (bottom right). The rear panels of the TLP Pro 525T and TLP Pro 1025T are similar to the TLP Pro 725T. - Page 19 NOTE: purchased separately. An Extron IPL Pro control processor must also be connected to the same network domain as the TouchLink Pro touchpanel (see the www.extron.com for a list of compatible models). The network port has two LEDs. The green LED lights steadily to indicate that the touchpanel is connected correctly to a network.
- Page 20 ATTENTION: The installation must always be in accordance with the applicable provisions of National • Electrical Code ANSI/NFPA 70, article 725 and the Canadian Electrical Code part 1, section 16. Cette installation doit toujours être conforme aux dispositions applicables du Code •...
- Page 21 USB port (see figure 3 on page 8) — Compatible with USB 2.0. The TLP Pro 525T, TLP Pro 725T, and TLP Pro 1025T have a plastic cover that must be removed for access to the USB port. Speaker (TLP Pro 525M, 725M, and 1025M only) — rovides audible feedback for the user.
-
Page 22: Tlp Pro 525T, Tlp Pro 725T, And Tlp Pro 1025T Base
Modes). LAN/PoE connector— Attach the LAN/PoE cable to this RJ-45 port. An Extron IPL Pro control processor must also be connected to the same network domain as the TouchLink Pro touchpanel (see the www.extron.com for a list of suggested models). - Page 23 Connect a straight-through Ethernet cable from the power injector to a switch or router (see figure , on page 9). This cable carries network information from the switch or router to the power supply. A second straight-through cable carries the network information and 48 VDC from the power injector to the touchpanel ( ).
-
Page 24: On-Screen Menus
On-screen Menus On-screen menus allow initial configuration of the touchpanels. The figures in this section show screens for the TLP Pro 725T. Unless stated otherwise, the screens for the other touchpanels are very similar. Setup Menu To open the setup menu, use a screw driver with a fine blade to press the button. -
Page 25: Network
Network Verify with your network administrator whether the IP address for the touchpanel is assigned by Dynamic Host Configuration Protocol (DHCP) or set manually. If they are set manually, you need to obtain an IP address, a subnet mask, a gateway address, and a Domain Name Server (DNS) from the network administrator. - Page 26 If DHCP is disabled, set the unit IP address, subnet mask, gateway address, and DNS server address. Press the button for the address to be edited. A screen opens, showing the address and a numerical keypad. IP Address Clear 1 9 2 1 6 8 2 5 4 2 5 1...
-
Page 27: Display
Display Press the button in the navigation panel at the top of the screen to open the Display Display screen. Display Audio Advanced Exit Status Network Auto Brightness Sleep Timer LCD Brightness Minutes Wake on Motion Figure 10. Display Screen Display screen allows you to set the Sleep Timer... -
Page 28: Audio
Audio Press the button in the navigation panel at the top of the screen to open the Audio Audio screen. Display Audio Advanced Exit Status Network Master Click Sound Figure 11. Audio Screen On the Audio screen, use the slider controls to adjust the Master Click , and... -
Page 29: Advanced
Advanced Press the button in the navigation panel at the top of the screen to open the Advanced Advanced screen. The TLP Pro 725M and TLP Pro 1025M series wall mount models have the option to switch the rear panel status lights on or off (see figure 12). This option is not available for the TLP Pro 525M, TLP Pro 525T, TLP Pro 725T, or TLP Pro 1025T series touchpanels (see figure 13). - Page 30 Menu PIN The PIN setup options allow you to enable, disable, or change the setup menu PIN. The PIN is a 4-digit number. Each digit can have any value from 0-9. Select the first digit of the PIN. When selected, it is highlighted in yellow. Enter New Menu PIN Back Cancel...
-
Page 31: Configuration Software
• Configuration Software Designing a graphical user interface (GUI) for the TouchLink Pro touchpanel takes two steps: Design the layout of the screen text and graphics using GUI Designer. Assign functions to the text and graphics using Global Configurator Plus and Professional. -
Page 32: Installing Gui Designer, Global Configurator, Toolbelt, And Room Agent
Installing GUI Designer, Global Configurator, Toolbelt, and Room Agent NOTE: Use GUI Designer, Global Configurator Plus and Professional, and Toolbelt to configure the TLP Pro touchpanel. GUI Designer, Global Configurator, and Toolbelt can be downloaded from www.extron.com. Select the button (see figure 15, ) and then click the option ( Download... -
Page 33: Using The Software
Toolbelt Use the Toolbelt software for device discovery, device information, firmware updates, and configuration of network settings, system utilities, and user management for TouchLink Pro devices (see the Toolbelt Help file for more detailed information). TLP Pro 525, 725, and 1025 Series Touchpanels • Configuration Software... -
Page 34: Touchpanel Web Page
Touchpanel Web Page There is a single, read-only page that provides general and network information about the unit (see figure 16, below). It also allows you to upgrade the unit firmware. Use the Setup Menu (see page 14) or Toolbelt to configure the touchpanel network settings. To access the touchpanel default web page, enter the IP address of the touchpanel into the web browser of a PC connected to the same subnet. -
Page 35: Updating The Firmware
Updating the Firmware Firmware for the TLP Pro 725 series touchpanels can be upgraded using Toolbelt or the touchpanel web page. Before starting, consult your IT team and ensure that the touchpanel has a unique IP address. Downloading Firmware Power on a computer that is connected to the same network as the touchpanel. Go to www.extron.com, click (see figure 18, ) and then click... -
Page 36: Mounting
Mounting There are several options for mounting these touchpanels. Visit the Extron website (www. extron.com) for a complete list. This section outlines the various options for: Mounting the TLP Pro 525M, 725M, and 1025M • Mounting to a Wall Box or Junction Box •... -
Page 37: Mounting The Tlp Pro 525M, 725M, And 1025M
Mounting the TLP Pro 525M, 725M, and 1025M Mounting to a Wall Box or Junction Box Some local building codes require the touchpanel to be mounted in a junction box. Junction boxes or wall boxes must be purchased separately. NOTES: •... - Page 38 Figure 22 shows how to mount the TLP Pro 725M. Mounting the TLP Pro 525M or 1025M is very similar. Back View Figure 22. Mounting the TLP Pro 725M to a Wall Box (left) and Mounting Plate (right) Install a junction box or wall box (see figure 20, ), following the instructions provided by the manufacturer.
-
Page 39: Mounting To Drywall
Mounting to Drywall If the wall box is not required by local building codes, you can mount the TLP Pro 525M, 725M, or 1025M directly into drywall. Go to www.extron.com and download the cut-out template for your touchpanel. Print the template at 100% size (no scaling). -
Page 40: Reference Material
Reference Material This section describes: Network Port Requirements and Licensed Third-Party Software Used by the • Touchpanels Digital I/O Port Cases • Reset Modes • Network Port Requirements and Licensed Third-Party Software Used by the Touchpanels For information about network port requirements and licensed third-party software for all the touchpanels described in this guide, please refer to the Pro Series Control Product Network Ports and Licenses Guide, which is available at www.extron.com. -
Page 41: Connecting A Two-Position Switch To The Digital I/O Port
Connecting a Two-position Switch to the Digital I/O Port +5.0 V 1k ohms Two-position Switch SW 2 Digital Voltage SW 1 Protection Figure 25. Connecting a Two-position Switch to the Digital I/O Port Port Configured — Input with pullup (switch 1 open, switch 2 closed) Two Position Switch Open —... -
Page 42: Reset All Ip Settings
Result The unit reverts to factory-installed firmware. Event scripting does not start if the unit is powered on in this mode. All user files and settings such as drivers, adjustments, and IP settings are maintained. NOTE: To return the unit to the firmware version that was running prior to the reset, cycle power to the unit. -
Page 43: Enable Or Disable The Dhcp Client
Enable or Disable the DHCP Client This mode toggles between DHCP enabled and DHCP disabled. This can also be carried out from the Network screen of the Setup menu (see page 15). Activation To enable or disable the DHCP client for the LAN port: Press the button five times (consecutively). - Page 44 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
