Alarms pane

The Alarms pane (see figure
system managed by this NAVigator. Figure 123 shows the pane when alarms are present. Some alarms self-clear
when specific conditions are met, others remain as long as the conditions that cause them remain. As an
example, a temperature alarm remains until the NAVigator cools down.
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
Figure 123. Clearing Alarms
ATTENTION:
• Critical alarms ( ) should be resolved immediately.
• Warning alarms ( ) are less serious.
Manually clear one or more alarms from the system as follows:
1. Click LEARN MORE (see figure 123,
2. Click the All checkbox (
3. Click CLEAR ALARMS to clear the alarm (
117, on page 109) shows any alarms that have been triggered in the NAV
E
).
1
) or individual endpoint checkboxes (
2
).
4
5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
) to select one or more alarms to clear.
3
NAVigator System Manager • HTML Operation
