User Guide
TouchLink
®
TLP Pro 525, 725, and 1025 Series
TouchLink Pro Touchpanel Control Systems
68-2831-01 Rev. G
09 21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TLP Pro 525 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Extron electronics TLP Pro 525 Series

  • Page 1 User Guide TouchLink ® TLP Pro 525, 725, and 1025 Series TouchLink Pro Touchpanel Control Systems 68-2831-01 Rev. G 09 21...
  • Page 2 Safety Instructions Safety Instructions • English Instructions de sécurité • Français AVERTISSEMENT : Ce pictogramme, , lorsqu’il est utilisé sur le WARNING: This symbol, , when used on the product, is intended to produit, signale à l’utilisateur la présence à l’intérieur du boîtier du alert the user of the presence of uninsulated dangerous voltage within produit d’une tension électrique dangereuse susceptible de provoquer the product’s enclosure that may present a risk of electric shock.
  • Page 3 安全说明 • 简体中文 警告: 产品上的这个标志意在警告用户, 该产品机壳内有暴露的危险 电压, 有触电危险。 注意: 产品上的这个标志意在提示用户, 设备随附的用户手册中有重 要的操作和维护(维修)说明。 关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍使 用的特性等相关内容, 敬请访问 Extron 网站 , www.extron.com,参见 Extron 安全规范指南,产品编号 。 68‑290‑01 安全記事 • 繁體中文 안전 지침 • 한국어 경고: 이 기호 가 제품에 사용될 경우, 제품의 인클로저 내에 있는 警告: 若產品上使用此符號,...
  • Page 4 FCC Class A Notice NOTE: This FCC Class A Notice applies to TLP Pro 725 Series models. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Battery Notice This product contains a battery. Do not open the unit to replace the battery. If the battery needs replacing, return the entire unit to Extron (for the correct address, see the Extron Warranty section on the last page of this guide). CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type.
  • Page 6 FCC Radio Frequency Interference — Safety Notices NOTE: The Safety Notices and Industry Canada Notices on this and the following pages refer to the TLP Pro 525M and TLP Pro 1025T models. Antenna Warnings WARNING: The radiated output power of the wireless device is far below the FCC radio frequency exposure limits.
  • Page 7 Radio Frequency (RF) Exposure Information This equipment complies with IC RSS‑102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the antenna and your body. IC conformité Canada, avis d’Industry Canada (IC) CAN ICES-3 (B)/NMB-3(B) Cet appareil est conforme aux normes des cahiers des charges sur les normes radioélectriques...
  • Page 8 Conventions Used in this Guide Notifications In this user guide, the following are used: WARNING: Potential risk of severe injury or death. AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. CAUTION: Risk of minor personal injury. Risque de blessure mineure. ATTENTION : ATTENTION: •...
  • Page 9: Table Of Contents

    Contents Introduction Configuration Software ............1 ........21 About This Guide ............1 Configuration Software ..........21 About the TLP Pro 525, 725 and 1025 Series ..1 Installing Software ..........21 Features ..............2 Using the Software ..........23 All Models ............2 TLP Pro 525, 725, and 1025 Series Web Page ..24 TLP Pro 525M, TLP Pro 725M, and Updating the Firmware ..........26 TLP Pro 1025M ..........2...
  • Page 10 TLP Pro 525, 725, and 1025 Series Touchpanels • Contents...
  • Page 11: Introduction

    Introduction This section discusses the following topics: • About This Guide • Features • About the TLP Pro 525, 725 and • Application Diagram 1025 Series • Requirements About This Guide This guide describes the function, installation, and operation of the following Extron Touchlink Pro Touchpanels: TLP Pro 525M, TLP Pro 525M NC, TLP Pro 725M, TLP Pro 725M NC, TLP Pro 1025M, •...
  • Page 12: Features

    All Models LCD touchscreen — With 24‑bit color depth and a vibrant edge‑to‑edge glass display. • TLP Pro 525 Series — 5‑inch touchscreen with 800x480 (WVGA) resolution. • TLP Pro 725 Series — 7‑inch touchscreen with 1024x600 (WSVGA) resolution. •...
  • Page 13: Application Diagram

    Application Diagram WiFi 1 2 3 4 Extron Extron DTP HDMI 4K FF 220T 330 Rx Ceiling Speakers Receiver MODEL 80 LINK OUTPUTS POWER AUDIO 0.7A MAX DTP IN OVER DTP RS-232 Tx Rx Tx Rx DTP HDMI 4K 330 Rx HDMI RS-232 Laptop...
  • Page 14: Installation Overview

    Installation Overview This section provides an overview of the installation process. Follow the links for a more detailed explanation of each step. Before starting to install the TLP Pro models, download and install the latest versions of the following software: GUI Designer —...
  • Page 15 Mount and cable the units: ATTENTION: • Do not power on the touchpanels or control processors until you have read the Attention about Power over Ethernet (PoE) power supplies (see page 13). • Ne branchez pas les écrans tactiles ou les processeurs de contrôle avant d’avoir lu la mise en garde sur les sources d’alimentation via Ethernet (PoE) (voir...
  • Page 16: Panel Features

    Panel Features This section describes the TLP Pro touchpanels: Front Panel Features • Rear Panel Features • TLP Pro 525T, TLP Pro 725T, and TLP Pro 1025T Base • Front Panel Features Figure 2 shows the TLP Pro 725M (left) and TLP Pro 725T (right) front panels. The front panels for all models have the same features and are very similar, apart from size.
  • Page 17 Communication LED — (see figure 2 on the previous page). Shows the configuration and connection status of the touchpanel: Unlit during normal operation (the touchpanel is configured and connected to an • IP Link Pro control processor). Blinks if the touchpanel has been configured but is not connected to an IP Link Pro •...
  • Page 18: Rear Panel Features

    Rear Panel Features Figure 3 shows the rear panels of the TLP Pro 525M (top left), TLP Pro 725M (bottom left), TLP Pro 1025M (top right) and TLP Pro 725T (bottom right). The rear panels of the TLP Pro 525T and TLP Pro 1025T are similar to the TLP Pro 725T.
  • Page 19 RESET button (TLP Pro 525M, 725M, and 1025M only) — (see figure 3 on page 8) Pressing the button allows the unit to be reset in any of three different modes and RESET Reset can also be used to toggle between enabling and disabling the DHCP client (see Modes on page 33).
  • Page 20 USB port (see figure 3 on page 8) — Compatible with USB 2.0. The TLP Pro 525T, TLP Pro 725T, and TLP Pro 1025T have a plastic cover that must be removed for access to the USB port. Speaker (TLP Pro 525M, 725M, and 1025M only) — rovides audible feedback for the user.
  • Page 21: Tlp Pro 525T, Tlp Pro 725T, And Tlp Pro 1025T Base

    TLP Pro 525T, TLP Pro 725T, and TLP Pro 1025T Base Figure 4 shows the TLP Pro 725T (top) and the TLP Pro 525T base (bottom). TLP Pro 1025T base is similar to the TLP Pro 725T base. MENU button A A A B B B C C C D D D E E E F F F RESET button...
  • Page 22: Connecting Power

    LAN/PoE connector (see figure 4 on the previous page) — These touchpanels must be powered by Power over Ethernet (PoE; see Connecting Power, below). ATTENTION: • Do not power on the touchpanels or control processors until you have read the Attention about Power over Ethernet (PoE) power supplies (see page 13).
  • Page 23 ATTENTION: • The installation must always be in accordance with the applicable provisions of National Electrical Code ANSI/NFPA 70, article 725 and the Canadian Electrical Code part 1, section • Cette installation doit toujours être conforme aux dispositions applicables du Code américain de l’électricité...
  • Page 24: On-Screen Menus

    On-screen Menus On‑screen menus allow initial configuration of the touchpanels. The figures in this section show screens for the TLP Pro 525M. Unless stated otherwise, the screens for the other touchpanels are very similar. Setup Menu To open the setup menu, use a screw driver with a fine blade to press the button.
  • Page 25: Network

    Network Verify with your network administrator whether the IP address for the touchpanel is assigned by Dynamic Host Configuration Protocol (DHCP) or set manually. If they are set manually, you need to obtain an IP address, a subnet mask, a gateway address, and a Domain Name Server (DNS) from the network administrator.
  • Page 26 If DHCP is disabled, set the unit IP address, subnet mask, gateway address, and DNS server address. Press the button for the address to be edited. A screen opens, showing the address and a numerical keypad. IP Address Clear 1 9 2 1 6 8 2 5 4 2 5 1...
  • Page 27: Display

    Display Press the button in the navigation panel at the top of the screen to open the Display Display screen. Display Audio Advanced Exit Status Network Auto Brightness Sleep Timer LCD Brightness Minutes Wake on Motion Figure 11. Display Screen Display screen allows you to set the Sleep Timer...
  • Page 28: Audio

    Audio Press the button in the navigation panel at the top of the screen to open the Audio Audio screen. Display Audio Advanced Exit Status Network System Click Sound Figure 12. Audio Screen On the Audio screen, use the slider controls to adjust the System Click , and...
  • Page 29: Advanced

    Advanced Press the button in the navigation panel at the top of the screen to open the Advanced Advanced screen. The TLP Pro 725M and TLP Pro 1025M series wall mount models have the option to switch the rear panel status lights on or off (see figure 13). This option is not available for the TLP Pro 525M, TLP Pro 525T, TLP Pro 725T, or TLP Pro 1025T series touchpanels (see figure 14).
  • Page 30 Menu PIN The PIN setup options allow you to enable, disable, or change the setup menu PIN. The PIN is a 4‑digit number. Each digit can have any value from 0‑9. Press a number on the keypad. A blue circle appears in the first box. Enter New Menu PIN Back Cancel...
  • Page 31: Configuration Software

    Configuration Software This section of the user guide provides information about: Configuration Software • Installing Software • Using the Software • TLP Pro 525, 725, and 1025 Series Web Page • Updating the Firmware • Configuration Software Use Toolbelt to provide device information, firmware updates, and configuration of network settings, system utilities (reset, reboot), and user management (username and password) for TouchLink Pro devices.
  • Page 32 You may see the product immediately, for example Global Configurator Plus and (see figure 17, ). Use the left and right arrows ( ) to scroll through all the Professional highlighted products. If the software is not shown, click the initial letter of the product in the alphabet menu ( 1 1 1 2 2 2...
  • Page 33: Using The Software

    Using the Software Use GUI Designer and Global Configurator Plus and Professional to design and configure a graphical user interface (GUI) for the TouchLink Pro touchpanel. Design the layout of the screen text and graphics using GUI Designer, which is a Windows‑based application.
  • Page 34: Tlp Pro 525, 725, And 1025 Series Web Page

    TLP Pro 525, 725, and 1025 Series Web Page To access the touchpanel default web page, enter the IP address of the unit into the web browser of a PC connected to the same subnet. A log‑in page opens. Figure 18. TLP Pro 1025T Login Page Figure 18 shows the login page for the TLP Pro 1025T.
  • Page 35 The web page opens. Figure 19 shows the TLP Pro 725T web page. The web pages for the other touchpanels are very similar. Figure 19. TLP Pro 1025T Web Page There is a single page, most of which is read‑only, providing general and network information •...
  • Page 36: Updating The Firmware

    Updating the Firmware Firmware for the TLP Pro 725 series touchpanels can be upgraded using Toolbelt. Before starting, consult your IT team and ensure that the touchpanel has a unique IP address. Power on a computer that is connected to the same network as the touchpanel. Go to www.extron.com, click (see figure 20, ) and then click...
  • Page 37: Mounting

    Mounting There are several options for mounting these touchpanels. Visit the Extron website (www.extron.com) for a complete list. This section outlines the various options for: Mounting the TLP Pro 525M, 725M, and 1025M • Mounting to a Wall Box or Junction Box •...
  • Page 38: Mounting The Tlp Pro 525M, 725M, And 1025M

    Mounting the TLP Pro 525M, 725M, and 1025M Mounting to a Wall Box or Junction Box Some local building codes require the touchpanel to be mounted in a junction box. Junction boxes or wall boxes must be purchased separately. NOTES: •...
  • Page 39 Figure 23 shows how to mount the TLP Pro 725M. Mounting the all the other touchpanels is very similar. Back View Figure 23. Mounting the TLP Pro 725M to a Wall Box (left) and Mounting Plate (right) Install a junction box or wall box (see figure 23, ), following the instructions provided by the manufacturer.
  • Page 40: Mounting To Drywall

    Mounting to Drywall If local building codes do not require a wall box, you can mount the touchpanel directly into drywall. Go to www.extron.com and download the cut‑out template for your touchpanel. Print the template at 100% size (no scaling). Remove the gray area in the center of the template, place the template against the wall or furniture in a suitable location, and ensure that it is level.
  • Page 41: Reference Material

    Reference Material This section describes: Best Practices for Cleaning Your Extron Products • Network Port Requirements and Licensed Third-Party Software Used by the • Touchpanels Digital I/O Port Cases • Reset Modes • Secure Sockets Layer (SSL) Certificates • IEEE 802.1X Certificates •...
  • Page 42: Digital I/O Port Cases

    Digital I/O Port Cases Connecting an Occupancy Sensor to the Digital I/O Port +5.0 V 1k ohms SW 2 Digital Control Signal Voltage Protection SW 1 Ground Figure 25. Connecting an Occupancy Sensor to the Digital I/O Port Port Configured — Input (switch 1 open, switch 2 open) Room Occupied —...
  • Page 43: Reset Modes

    Reset Modes The touchpanels described in this guide have three reset modes that are initiated by pressing the button. An additional (fourth) mode toggles between enabling and disabling the DHCP RESET client: Use Factory Firmware (see below). • Reset All IP Settings (see page 34).
  • Page 44: Reset All Ip Settings

    Reset All IP Settings This mode resets all IP settings to factory defaults. Activation To reset all IP settings: Hold down the button for about 6 seconds until the LED blinks twice (once at RESET Reset 3 seconds and again at 6 seconds). Release and press RESET momentarily (for <1 second) within 1 second.
  • Page 45: Enable Or Disable The Dhcp Client

    Enable or Disable the DHCP Client This mode toggles between DHCP enabled and DHCP disabled. This can also be carried out from the Network screen of the Setup menu (see page 15). Activation To enable or disable the DHCP client for the LAN port: Press the button five times (consecutively).
  • Page 46: Ieee 802.1X Certificates

    IEEE 802.1X Certificates IEEE 802.1X is a standard that enables port‑based network access control via an authentication server. The protocol requires that all devices must be authenticated before gaining privileges to access the secure part of the network. The Extron implementation of 802.1X supports PEAP ‑ MSCHAPV2 and EAP ‑ TLS methods of authentication.
  • Page 47: Snmp

    SNMP Extron control products support Simple Network Management Protocol (SNMP). SNMP facilitates the exchange of basic network management information between network devices. It helps in monitoring of operations and factors such as packet usage, memory usage, remote password resets, and collection of error information. An information technology administrator can use common IT tools to monitor those factors, as well as look up device location and the name of the contact person for the device.
  • Page 48 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
