HTML Operation

This section introduces using the built-in HTML pages to configure and operate the NAVigator, including:
•

Opening the Embedded HTML Pages

•
HTML Pages Overview
• Creating a NAV System
•
Detailed Descriptions and Operations
The NAVigator can be controlled and operated through either the front panel CONFIG (USB) port (see
on page 7) or the rear panel NAV/PoE port (see
A
Configuration port uses IP over USB technology. The factory-embedded pages are always available and cannot
be erased or overwritten.
NOTE: If connection to the NAVigator using either the NAV/PoE port or OOB port is unstable, try turning off
the proxy server in your web browser.
Opening the Embedded HTML Pages
Access the NAVigator using HTML pages as follows:
1. Start the web browser.
NOTES:
• Extron recommends the following browsers to fully support the NAV system:
• Google Chrome — All screen images in this guide use Chrome
• Mozilla Firefox
• Microsoft Edge
• The network must be properly configured for multicasting (IGMP). Failure to do so may result in
degraded performance.
3. Click in the Address field of the browser and enter the IP address.
NOTES:
• Default settings:
Config (USB)*
NAV/PoE (RJ-45)
OOB (RJ-45)
* For the Config port, the address for IP over USB CANNOT be changed.
For the NAV/PoE port, if unit does not receive an IP address from the DHCP Server, it self-assigns a Link Local IP

address in the range 169.254.X.X.
If you use IP over USB, Extron recommends waiting a minute after plugging in the cable from your
PC to identify the USB connection as a valid Ethernet port.
4. Press the keyboard <Enter> key.
Port DHCP
On

Off
figure 2, on page 4) or OOB port (
B
IP address
203.0.113.22
192.168.253.254
NAVigator System Manager • HTML Operation
on page 4). The
C
Subnet mask
255.255.255.0
figure 5,
