RESET button and LED (see
D
levels of NAVigator reset (see
Connector and Cable Details
Twisted pair cable termination and recommendations
Figure 3 details the TIA/EIA T568-B wiring standard. Use this standard to terminate twisted pair (TP) cables with
RJ-45 connectors.
Side
Pins:
1 2 3 4 5 6 7 8
Insert
Twisted
Pair Wires
Figure 3.
TP Cable Termination
Power supply wiring
Figure 4 shows how to wire the connector. Use the supplied tie-wrap to strap the power cord to the extended tail
of the connector.
Smooth
Ridges
A
A
Power Supply
Output Cord
Figure 4.
Power Connector Wiring
figure 2
on page 4) — Press this button and observe the LED to initiate three
Reset
Operations, on page 7).
RJ-45
Connector
TIA/EIA T 568B
Pin
Wire color
1
White-orange
Orange
2
3
White-green
4
Blue
5
White-blue
6
Green
7
White-brown
8
Brown
SECTION A–A
Captive Screw
Connector
NAVigator System Manager • Installation and Basic Operation
Tie Wrap
5
3
5
