Installation and Assembly
4.7

Electrical Connections

4.7.1

Connectivity Options

The power supply and the signal output are located at the front side of the controller.
Controller
PS 2020
Fig. 15 Measuring system assembly
capaNCDT 6240
LAN cable
RJ-45-connectors
CCxxx
Ammeter/
Sensor
Voltmeter
R u
n
E th
e r
C A
T
X 1
X 2
SPS
Page 40
