Appendix| Tilt Angle Influence on the Capacitive Sensor
A 4

Tilt Angle Influence on the Capacitive Sensor

0
-1
-2
-3
CS02
-4
-5
-6
-7
-8
-9
-10
0 0.1 0.2 0.3 0.4 0,5
Angle  [°]
Fig. 28 Example of measuring range deviation in the case
of a sensor distance of 10 % of the measuring range
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
-10
0 0.1 0.2 0.3 0.4 0.5
Angle  [°]
Fig. 30 Example of measuring range deviation in the case
of a sensor distance of 100 % of the measuring range
capaNCDT 6240
CS10
CS1
0.6 0.7 0.8 0.9 1
CS1
CS10
CS02
0.6 0.7 0.8 0.9 1
0
CS1
-1
-2
CS02
-3
-4
-5
-6
-7
-8
-9
-10
0 0.1 0.2 0.3 0.4 0.5
Angle  [°]
Fig. 29 Example of measuring range deviation in the case
of a sensor distance of 50 % of the measuring range
i
Figures give an influence example shown on the
sensors CS02/CS1 and CS10 in the case of different
sensor distances to the target. As this results from
internal simulations and calculations, please request
for detailed information.
CS10
0.6 0.7 0.8 0.9 1
Page 88
