Sensor Cable - MICRO-EPSILON capaNCDT 6240 Operating Instructions Manual

Installation and Assembly
CSG0.50-CAm2.0 and CSG1.00-CAm2.0
Thickness 0.9
Sensor structures
2.9
4.2 (0.17)
(0.11)
4.5
(0.18)
CSG0,50-CAm2,0 CSG1,00-CAm2,0
Dimensions in mm (inches), not to scale
ensor Cable
4.3 S
The sensor is connected to the controller by the sensor cable. The connection is made by simple plugging. The connector locks auto-
matically. The tight fit can be checked by pulling the connector housing (cable bushing). The lock can be released and the connector
can be opened by pulling the knurled housing sleeve of the cable bushing.
capaNCDT 6240
-0.05 (0.04 -0.002 ) Sensor structures
200 (7.87)
216 (8.5)
3.85
(0.15)
9.9 (0.39)
1 (0.04)
Page 31
