Appendix| Measurement on Narrow Targets
A 5 Measurement on Narrow Targets
50 %
45 %
40 %
35 %
30 %
25 %
20 %
15 %
10 %
5 %
0 %
0 0.5 1 1.5
Target dispacement perpendicular to the sensor axis [mm]
Fig. 31 Example of measuring range deviation in the case
of a sensor distance of 10 % of the measuring range
50 %
45 %
40 %
35 %
30 %
3 mm
25 %
4 mm
20 %
15 %
10 %
5 %
0 %
0 0.5 1 1.5
Target dispacement perpendicular to the sensor axis [mm]
Fig. 33 Example of measuring range deviation in the case
of a sensor distance of 100 % of the measuring range
i
Figures give an influence example shown on the sensors CS05 in the case of different sensor distances to the target as well as
target widths. As this results from internal simulations and calculations, please request for detailed information.
capaNCDT 6240
3 mm
4 mm
6 mm
8 mm
2 2.5 3
6 mm
8 mm
2 2.5 3
50 %
45 %
40 %
35 %
30 %
25 %
3 mm
20 %
4 mm
15 %
10 %
5 %
0 %
0 0.5 1 1.5
Target dispacement perpendicular to the sensor axis [mm]
Fig. 32 Example of measuring range deviation in the case of a
sensor distance of 50 % of the measuring range
y
y >8 mm
Fig. 34 Signal change in the case of displacement of thin
targets in the opposite direction to the measurement direction
6 mm
8 mm
2 2.5 3
z
z constant
x
Movement
in x-direction
