Initial Operation
6.4.9

Sensor Information

Index Subindex Data type
0x2220
0 Uint8
1 Uint8
2 Uint8
3 Uint8
4 Uint8
5 Int32
6 Int32
7 Int32
8 Int32
9 Float
10 Float
11 Float
12 Float
13 Uint8[32]
14 Uint8[32]
15 uint8
16 uint8[138] R
capaNCDT 6240
Name
Sensor block
R NrOfObjects
RW block index offset
RW page index to read
R number of pages
R measurement unit
R article number
R Option
R Batch number
R serial number
Nominal measuring
R
range
R Nominal offset
R current measuring range Actual measuring range
R current offset
R Target material
R Sensor/channel name
R extension length
extension
Description
Request sensor information
The offset lets you scroll through existing sensor blocks [0 - 0x1F]
Specifying an index lets you scroll through existing pages
Max. number of pages
Signal unit
Part number
Option
Batch number
Serial number
Nominal measuring range
Nominal offset
Actual offset
Target material
Sensor/channel name
Length of block extension
Page 61
