Initial Operation
6.4

Object Directory

6.4.1

Error Protocol

Index Subindex Data type
0x2010 0 Uint32[64] R
6.4.2

Reset Device

Index Subindex Data type
0x2026 0 Uint8
6.4.3

Triggering

Index Subindex Data type
0x2031
1 Uint16
capaNCDT 6240
Name
device error log
Name
W reset device
Name
RW Trigger settings
Description
Reads out the last 32 error codes with time stamp
Description
One byte performs reset
Description
0: No trigger
1: Rising edge, one measurement is output
2: Falling edge, one measurement is output
4: High level, value output, as long as the level is active
8: Low level, value output, as long as the level is active
16: Gate trigger with rising edge, starts resp. stops the measuring
value output alternatively
32: Gate trigger with falling edge, starts resp. stops the measuring
value output alternatively
