Installation and Assembly
Sensor cable CCmxC
8.6 (.34)
13.7 (.54)
17.5
(.69)
Cable length x
Sensor cable CCmxB
Cable length x
Dimensions in mm (inches), not to scale
Model
Cable length
CCmxC
1.4/2.8 or 4.2 m
CCmxC/90
1.4/2.8 or 4.2 m
CCmxB
1.4/2.8 or 4.2 m
CCmxB/90
1.4/2.8 or 4.2 m
capaNCDT 6240
27 (1.06)
37 (1.46)
27 (1.06)
37 (1.46)
Cable ø
2 axial
1x axial +
connector
1x 90
2.1 mm
2.1 mm
2.1 mm
2.1 mm
Sensor cable CCmxC/90
21 (.83)
Sensor cable CCmxB/90
25 (.98)
ø10
(.39)
ø7 (.28)
For sensors
0
0.05 - 0.8 mm
0.05 - 0.8 mm
7 mm
(once)
1 ... 10 mm
1 ... 10 mm
ø6 (.24)
ø5.4 (21)
Min. bending radius
15 mm
(permanently)
