Page 1: Command Line Interface
Command Line Interface for 1813 and 1823 VoIP Gateways, 1862 SIP IAD, and 6212-A1 Router User’s Guide Document Number 1800-A2-GB20-00 June 2005... - Page 2 Command Line Interface User’s Guide Copyright 2005 Paradyne Corporation. All rights reserved. Printed in U.S.A. Notice This publication is protected by federal copyright law. No part of this publication may be copied or distributed, transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the express written permission of Paradyne Corporation, 8545 126th Ave.
- Page 3 This instruction guide introduces the command line interface (CLI) for the Telnet management of the 1813 and 1823 VoIP Gateways, the 1862 SIP IAD, and 6212 Router. If your device has a console port, you can also access the CLI from a VT100 terminal or equivalent (such as a PC running Hyperterminal or Telix).
-
Page 4: Table Of Contents
Command Line Interface User’s Guide Table of Contents CHAPTER 1 TELNET ACCESS ... 10 ETTING A OMMON ... 12 OGIN CHAPTER 2 GENERAL OPERATION... 13 CLI R ... 13 EFERENCE ... 14 ENERIC 2.2.1 ls... 14 2.2.2 help... 14 2.2.3 accountstats... - Page 5 3.2.3 PART 3 Set up an IP address for the WAN interface... 31 3.2.4 PART 4 Delete the PVC to RFC 1483 Routed ... 31 A... 32 3.3.1 PART 1 create a new PVC ... 32 3.3.2 PART 2 Set the PVC to IPoA ... 32 3.3.3 PART 3 Delete the PVC for IPoA ...
- Page 6 Command Line Interface User’s Guide 4.10 ... 46 INGS 4.11 ... 47 4.12 OICE ONFIGURATION 4.12.1 Voice Options... 47 4.12.2 Jitter Buffer Configuration ... 48 4.12.3 Country ... 48 4.13 HONE PERATIONS 4.13.1 Normal Call Hold ... 48 4.13.2 Consultation Call Hold ... 49 4.13.3 Call Resume ...
- Page 7 5.4.4 start ... 67 5.4.5 comconf ... 67 5.4.6 delcomm ... 67 5.4.7 trapconf ... 68 5.4.8 trap... 68 5.4.9 agconfig... 69 ... 69 IREWALL 5.5.1 policy... 69 5.5.2 policy delete ... 70 5.5.3 policy modify... 70 5.5.4 policy enable ... 71 5.5.5 policy disable ...
- Page 8 Command Line Interface User’s Guide 5.8.3 subnet ... 88 5.8.4 host... 89 5.8.5 lease ... 90 DHCP ... 90 RELAY 5.10 ADSL ... 91 5.10.1 setmode ... 91 5.10.2 readcmv... 91 5.10.3 writecmv... 92 5.10.4 mon... 92 5.10.5 addusercmv ... 92 5.10.6 delusercmv ...
- Page 9 5.15.13 list... 108 5.15.14 ipoa ... 108 5.15.15 routedbridge... 110 5.15.16 1483mer ... 110 5.15.17 mer ... 111 5.15.18 relay ... 111 5.15.19 liststat... 112 5.15.20 ppptrace ... 112 5.16 ... 112 5.16.1 showatmconn... 113 5.16.2 vcadd ... 113 5.16.3 vpadd...
-
Page 10: Chapter 1 Telnet Access
Command Line Interface User’s Guide Chapter 1 Telnet Access The Command Line Interface (CLI) can be used to configure your endpoint device. Telnet is used to access the CLI. To Telnet to the device, you can either set your PC’s IP address to the same domain as the endpoint, or set the endpoint’s IP address to the same domain as your PC. - Page 11 You can modify the IP address of your PC by from its TCP/IP definition. Follow the steps below: STEP 1: Enter the TCP/IP screen. (Under Windows XP, for example, click on Control Panel from the Windows Start menu. Double-click on Network Connections.Right-click on Local Area Connection and select Properties.
-
Page 12: Login
Command Line Interface User’s Guide 1.2 Login To access Telnet to manage your endpoint, complete the following steps: The default IP address is 192.168.1.1. Use the default IP address to log on to the endpoint if it was not changed. STEP 1 Make sure that the endpoint and your PC are on the same network segment. -
Page 13: Chapter 2 General Operation
Command Line Interface User’s Guide Chapter 2 General Operation 2.1 CLI Reference All the system commands for various modules are organized in different directories. All these directories are put under the directory called home. However, they can be listed using the ls command. -
Page 14: Generic
Command Line Interface User’s Guide 2.2 Generic The CLI provides generic commands for navigating between directories, listing the commands in a directory, and providing help. All the generic commands can be executed from any directory. 2.2.1 When you enter a directory, you can use the ls command to display the available commands. It lists all the commands registered in the current working directory. -
Page 15: Accountstats
The following screen is an example of displaying the usage for the rip command. [1234 @ home]$ help -o rip DESCRIPTION Contains RIP related commands USAGE If nothing is specified, it displays information about all general commands. 2.2.3 accountstats accountstats modulename This command displays accounting details of the specified module. -
Page 16: Date
Command Line Interface User’s Guide 2.2.6 date date This command displays the endpoint date and time. EXAMPLE [1234 @ home]$ date DATE (MM:DD:YYYY) 1:10:2002 TIME (H:M:S) 4:56:59 2.2.7 erase erase This command erases all the configurations in the system. That means the factory default settings are retrieved. -
Page 17: Time
COMMAND DESCRIPTION address destination IP address you wish to ping in the form x.x.x.x, where each x is a decimal number 0 to 255. size Data size to ping the host. The accepted size is 56 bytes to 1492 bytes. EXAMPLE 2.2.11 time... -
Page 18: Logger
Command Line Interface User’s Guide 2.3 logger logseverity logftpserver loginfo logadd 2.3.1 logSeverity logseverity -o error/info on/off This command is used to set the trace for the log severity level. COMMAND DESCRIPTION error/info This option specifies the severity level. on/off This option specifies weather the trace is set or not. -
Page 19: Logftpserver
Loglevel can be given as exception, error or info. <module name> Module name can be all, ip, tcp, udp, sockets, rawip, icmp, arp, igmp, app, cdcli, if, telnet, dns, snmp, http, ping, ftp, ftpd, tftp, bootp, dhcpc, dhcps, qosbw, ipsec, ike, nat, firewall, diffserv, logger, queuing, ipoa, pppoa, ethoa, httpproxy, ftpproxy. -
Page 20: User Account
Command Line Interface User’s Guide This command displays the configured logger information. This will contain the trace information, ftpserver, and login information. EXAMPLE [1234 @ logger]$ loginfo Error Trace Info Trace Server Address User Name Password 2.4 User Account A default user account is provided to configure, maintain, and operate the endpoint in HTTP (web), CLI, and FTP modes. - Page 21 The two access privileges are admin and ordin. The admin privilege provides full right including read and write accesses. The ordin privilege only allows reading and monitoring the parameters via http or cli. An ftp user must have an admin privilege. adduser adduser username -o -services [services] -permissions [permissions] services : [cli/ftp/http]...
- Page 22 Command Line Interface User’s Guide COMMAND DESCRIPTION <username> The name of the user whose services or permissions are to be modified. EXAMPLE -addservices <cli | ftp | http> Adds cli, ftp, or http services to the user. -delservices <cli | ftp | http> Removes cli, ftp, or http services from the user.
-
Page 23: Ethernet Ip Address
listusers listusers The listusers command lists all registered users to use cli/http/ftp. EXAMPLE [1234 @ auth]$ listusers 1234 cli http ftp ADMIN pppoe http maylyne pizza cli ftp [1234 @ auth]$ resetuser The resetuser command resets the user password. This is an administrators command; ordinary users can not use this. -
Page 24: Primary Ip Address
Command Line Interface User’s Guide To set up an IP address and subnet mask for the Ethernet interface, use the following command after the prompt of [1234 @ home]$. ifconfig -o <interface-name> inet <address> [parameters] ifconfig -o -a displays the information of the interfaces ifconfig -o -l parameters- mtu <n 72-1500>, broadcast <address>, netmask <mask>, up, down COMMAND DESCRIPTION... -
Page 25: Alias Ip Address
2.5.2 Alias IP Address To set up the alias IP address, use this command: [1234 @ home]$ ifconfig –o <interface name> inet <address> alias netmask <address> EXAMPLE [1234 @ home]$ ifconfig -o eth0 inet 172.1.1.1 alias netmask 255.255.255.0 The above example assigns an alias IP address of 172.1.1.1 with a 24-bit subnet mask to the eth0 interface. -
Page 26: Delete
Command Line Interface User’s Guide EXAMPLE add 0x112233445566 192.168.3.4 Adds the H/W address and IP Address mapping in the database. 2.6.2 delete delete <0xH/Waddress > Deletes an entry in the existing RARP DataBase. <0xH/Waddress > Hardware address in hexadecimal format. EXAMPLE delete 0x112233445566 Deletes mapping of H/W address 11:22:33:44:55:66 to IP Address, from the database. -
Page 27: Rarpd
2.6.4 rarpd rarpd <-a | interface> The rarpd command starts the RARPD on the specified interface or all the interfaces. EXAMPLE rarpd eth0 This command starts the RARPD on eth0 interface. rarpd eth0 If RARPD is already running the above command, it displays: “Rarpd is already running on the interface”... - Page 28 Command Line Interface User’s Guide COMMAND DESCRIPTION <value> The baud rate of the console session. 0 represents 9600 bps; 1 represents 38400 bps; 2 represents 57600 bps. 3 represents 115200 bps. EXAMPLE baudrate 3 The baudrate command configures the baud rate to 115200 bps. 1800-A2-GB20-00...
-
Page 29: Chapter 3 Quick Configuration
Chapter 3 Quick Configuration This chapter describes how to configure the endpoint for the first time using the CLI. The endpoint can work after these settings are complete. 3.1 RFC 1483 Bridged To enable the bridging function of the endpoint, enter the sndcp directory from the prompt of [1234 @ sndcp]$. -
Page 30: Part 3 Delete The Pvc For Rfc1483 Bridged
Command Line Interface User’s Guide 5. Type bridge enable. 6. If the bridge prompt pops up, a PVC 0/35 is successfully enabled for the RFC 1483 Bridged mode. 3.1.3 PART 3 Delete the PVC for RFC1483 Bridged To delete the PVC set up for the RFC 1483 Bridged, you must delete the service first under the bridge prompt. -
Page 31: Part 2 Set The Pvc To Rfc 1483 Routed
3. At the atm prompt, type home or exit to return to the home prompt. 3.2.2 PART 2 Set the PVC to RFC 1483 Routed 1. Return to the home prompt. 2. Type sndcp to enter the sndcp prompt. 3. Type routedbridge atm0 enable 0 35 -o -enc LLC. In this case, atm0 is used. You can choose other atm interface if you wish. -
Page 32: Ipoa
Command Line Interface User’s Guide 3.3 IPoA 3.3.1 PART 1 create a new PVC 1. Type atm at the home prompt to enter the atm directory. 2. Type vcadd 0 35 ubr aal5 3. At the atm directory, type home or exit to return to the home prompt. 3.3.2 PART 2 Set the PVC to IPoA 1. -
Page 33: Part 3 Delete The Pvc For Ipoa
4. If the sndcp prompt pops up, a PVC 0/35 is successfully created for the IPoA mode. 3.3.3 PART 3 Delete the PVC for IPoA To delete the PVC set up for IPoA, you must delete the profile first under the sndcp prompt. Secondly, delete the VC under the atm prompt. -
Page 34: Part 3 Delete The Pvc For Pppoe
Command Line Interface User’s Guide The pppoe command covers the settings for the PPPoE entry number, encapsulation type, timeout period, authentication, user name, password, VPI, VCI, and NAT. You can complete a PPPoE entry by typing this command that covers these basic settings. If you need a complete setting, refer to the usage instruction above. -
Page 35: Pppoa
3.5 PPPoA 3.5.1 PART 1 Create a new VC 1. Type atm to enter the atm directory. 2. Type vcadd 0 35 ubr aal5 3. At the atm prompt, type home or exit to return to the home prompt. 3.5.2 PART 2 Set the PVC to PPPoA 1. -
Page 36: Part 3 Delete The Pvc For Pppoa
Command Line Interface User’s Guide The pppoa command covers the basic settings for the PPPoA profile number, encapsulation type, timeout period, authentication, user name, password, VPI, VCI, and NAT. You can complete a PPPoA entry by typing this command that covers these basic settings. If you need a complete setting, refer to the usage instruction above. -
Page 37: Part 3 Set Up An Ip Address For The Wan Interface
3. Type 1483mer to display the command to set up an MER entry. The command usage is shown below. For the port parameter specified in the command, always type mer0. Only one MER entry can be created. EXAMPLE 4. If the sndcp prompt pops up, a PVC 0/35 is successfully created for MER mode. 3.6.3 PART 3 Set up an IP address for the WAN interface 1. -
Page 38: Chapter 4 Command Line Interface Sip
Command Line Interface User’s Guide Chapter 4 Command Line Interface SIP SIP Configuration 4.1 SIP Host (User Agent) 4.1.1 Configuration Command syntax: confighost <Interface> -o [-up <useproxy(yes/no)>] Usages: This command configures binding interface and proxy info for Host. Description: Interface: Binding interface of SIP User-Agent useproxy: Option of Using Proxy/Registrar server if it is configured. -
Page 39: Sip Proxy/Registrar Server
4.2 SIP Proxy/Registrar Server 4.2.1 Configuration Command syntax: configproxyreg <proxy/register Addr> -o [-p <proxy/register Port>] Usages: This command configures the Proxy/Registrar Server host address and Port Number. Description: Address: Ip Address or FQDN of outbound SIP-Proxy/Registrar server . Port: Port Number of SIP-Proxy server where it will Receive all the SIP messages. -
Page 40: Displaying
Command Line Interface User’s Guide This command configures the Domain. Description: Configured domain. Domain: Example: configdomain paradyne.com 4.3.2 Displaying Command syntax: listdomain Usages: Display the Configured Domain information. Example: #### Domain LIST #### Domain --------------------- paradyne.com 4.4 Codecs Supported 4.4.1 Configuration Command syntax: configcodecs -o... -
Page 41: Displaying
4.4.2 Displaying Command syntax: listcodecs Usages: Displays all the Configured Codecs. Example: #### CODECS INFO #### PCMU PCMA G729 --------------------- 4.5 Phone 4.5.1 Configuration Command syntax: configphone <portNumber> <phoneUserName> -o [-d<DispName>] [-e<expires>] [-q<qvalue>] [-c<PreferCodec>] Usages: This command Configures sip parameter required to build SIP messages for phone(s) attached to SIP UA to send signaling information to peer. -
Page 42: Displaying
Command Line Interface User’s Guide 4.5.2 Displaying Command syntax: listphones Usages: Display the Configured sip parameters of all the configured phones. Example: #### PHONELIST #### port User DispName Expires QValue Codec Frame CallerID DTMF ---------------------------------------------------------------------------- Buddy List (List of remote user(s) one wish to call, only works when not using proxy) 4.5.3 Configuration Command syntax:... -
Page 43: Displaying
4.5.4 Displaying Command syntax: listbuddy Usages: List all the Configured buddy with their information . Example: #### BUDDYLIST#### Index Name Host Dial Port DispName -------------------------------------------------- 5551234 192.168.1.2 4.5.5 Deleting Command syntax: Usages: Delete the Configured buddy information in the Buddy List according the specified index. -
Page 44: Displaying
Command Line Interface User’s Guide username: Host Ipaddr: Example: Configcf 1 102 192.168.1.102 Command syntax: Usages: To enable call forward to the given port only when the configuration is done. Example: callforward 1 -o -cf yes -uf yes 4.6.2 Displaying Command syntax: listcf Usages:... -
Page 45: Displaying
The configcf command is used to configure the authentication username and password. Description: portnumber: username: password: Example: configauth 1 123 abc 4.7.2 Displaying Command syntax: listauth Usages: Display the authentication information. Example: #### AUTHLIST#### --------------------------------- 4.8 Registration Command syntax: register <PortNumber> Usages: send Register request to Registrar server and phone corresponding to the port number is registered with proxy/registrar. -
Page 46: Inter-Digit Timeout
Command Line Interface User’s Guide Presently Valid values are 1or 2. Example: register 1 4.9 Inter-digit Timeout Command syntax: digitimeout <sec> Usages: Used to set inter digit timeout value. Description: Inter digit timeout value, valued value are from 1 to 10, 0 to disable. sec: Example: digitimeout 4... -
Page 47: Dial Plan
4.11 Dial Plan Command syntax: dialplan -o list dialplan -o add <dialnumber> <outnumber> dialplan -o del <index> Usages: Used to configure dialplan for converting dialed digits to out-dialing digits. Description: dialnumber: Out-dialing digits. outnumber: Example: dialplan –o add xxxx 555xxxx dialplan –o add 949xxxxxxx xxxxxxx 4.12 Voice Configuration 4.12.1... -
Page 48: Jitter Buffer Configuration
Command Line Interface User’s Guide 4.12.2 Jitter Buffer Configuration Command syntax: jitter -o [-t <Type>] [-thr <Threshold>] Usages: Configuring jitter parameters. Description: FJB or AJB. Type: Threshold: Thresold is only for Fixed Jitter Buffer scheme. Example: jitter -o -t FJB -thr 20 4.12.3 Country Command syntax:... -
Page 49: Consultation Call Hold
4.13.2 Consultation Call Hold This feature enables the user to hold his conversation and allows making a new connection (consulting connection) to another user. User by pressing * key followed by 2(Normal Hold) and dialing a valid number after getting dial tone invokes consultation. -
Page 50: Chapter 5 Advanced Configuration
Command Line Interface User’s Guide Chapter 5 Advanced Configuration 5.1 Static Route To set up the static route, type route at the prompt to display the static route commands. These commands are used to add, delete, modify, and flush the static route table. route add -o -dest {dest ip addr} -gateway {gateway ip addr} [{-option value}*] route add -o -dest {dest ip addr} -interface {interface name} [{-option value }*] route delete -o -dest {dest ip addr}... -
Page 51: Ethernet
5.2 Ethernet The ethernet command is used to configure the Ethernet interface parameters. Ethernet commands are located in the “ethernet” directory. setemac rmon pread pwrite elink down stat 5.2.1 MAC Address setemac <xx:xx:xx:xx:xx:xx> This sets up the MAC address. In order for the MAC changes to take effect, the configuration must be saved (using ‘save’command in the home directory) and the system rebooted. -
Page 52: Rmon
Command Line Interface User’s Guide 5.2.2 rmon This command reads the MAC RMON counters. Type rmon eth0 at the prompt to collect the Ethernet interface statistics. 5.2.3 pread pread <interface> <port(decimal)> Reads PHY register EXAMPLE [1234 @ ethernet]$ pread eth0 1 Register 1 value 0xffff Displays the register 1 value of eth0 interface. -
Page 53: Elink
5.2.5 elink elink <interface> -o [[auto] | [10 | 100 | auto_speed ] | [half | full | auto_duplex] The elink command configures the speed and/or duplex of the Ethernet interface. The default setting is auto for auto negotiation. With auto negotiation, both the speed and duplex are configured based upon what the link is connected to. -
Page 54: Ethernet Up/Down
Command Line Interface User’s Guide 5.2.6 Ethernet up/down The default setting of the Ethernet function is enabled. To disable it, use the down eth0 command. To enable it, use the up eth0 command. When the Ethernet interface is disabled, the telnet or web session will be terminated. -
Page 55: Pvc
This disables the ARP proxy 5.3.2 pvc add/delete port vpi vci encapsulation -o <-vpn OUI vpnId> The pvc command attaches a PVC to the WAN interface. COMMAND DESCRIPTION This adds the specified PVC to the bridge. delete This deletes the specified PVC to the bridge. <port>... -
Page 56: Group3
Command Line Interface User’s Guide If the bridge group was already set up, to configure the new group, delete the previous group by using the bridge delete command, and then group the new interfaces you wish to the bridge. The group and group3 commands are similar functions, but they group different number of interfaces to the bridge. -
Page 57: Cachetimer
If the bridge group was already set up, to configure the new group, delete the previous group by using the bridge delete command, and then group the new interfaces you wish to the bridge. COMMAND DESCRIPTION interface_name The name of an interface e.g. eth0, atm0… atm1 etc. EXAMPLE group eth0 atm0 atm4 The interfaces eth0, atm0, and atm4 are assigned to the bridge. -
Page 58: List
Command Line Interface User’s Guide 5.3.7 list list Lists bridge parameters. EXAMPLE 5.3.8 stats stats Displays bridge statistics. EXAMPLE 5.3.9 bridge bridge enable | disable | delete Enables, disables, or deletes the configuration of the bridge. 5.3.10 vstats vstats lists the VLAN groups. 1800-A2-GB20-00... -
Page 59: Vlantable
5.3.11 vlantable vlantable groupNumber(0 - 3) -o ethernetPort(1 - 4) -atm vci vpi configures the VLAN groups. Up to four groups (0-3) can be set up, and four Ethernet ports (0- 3) can be joined to these groups. COMMAND DESCRIPTION groupNumber(0 - 3) There are four groups. -
Page 60: Fdbmode
Command Line Interface User’s Guide enables VLAN disables VLAN 5.3.13 fdbmode fdbmode [single/multi] configures the forwarding database learning type. COMMAND DESCRIPTION multiple The learned entries will be distributed to five databases, (VLAN 1~4 and non-VLAN) single The learned entries will be collected into a single database. 5.3.14 igmpsnooping igmpsnooping on/off... - Page 61 COMMAND DESCRIPTION <portname> A string identifying the port e.g. eth0, atm0 -priority <priority> A positive integer indicating the port priority. Must be a value between 0 and 255. -linkcost <linkcost> A positive integer indicating the cost associated with the port. The value can range from 0 to 65535.
-
Page 62: Filter
Command Line Interface User’s Guide span span enable | disable Enables to disable the spanning tree protocol. list list Lists the spanning tree configuration. 5.3.16 filter filter <action> <mac_address> -o [-fwd | -drop] Configures the filtering capability of MAC addresses for the bridge. Up to 128 addresses may be specified. -
Page 63: Filterlist
filter modify 2:3:4:4:5:2 -o -drop Change the filter action for MAC address 2:3:4:4:5:2 to drop. 5.3.17 filterlist filterlist Lists the contents of the filter database. EXAMPLE 5.3.18 filterflush filterflush Flush the dynamic entries of the filter database. 5.3.19 l2_list List the layer 2 entries. EXAMPLE [1234 @ bridge]$ l2_list L2 Module is [enable]... - Page 64 Command Line Interface User’s Guide ifname -act allow|deny l2_fil del -o priority_number Sets up the layer 2 filter. L2 Filters for this endpoint are based on MAC addresses. COMMAND DESCRIPTION <priority> This is the priority level of the rule, smaller numbers have higher priorities, if a conflict between rules occurs.
-
Page 65: Snmp
5.4 SNMP The SNMP commands allow listing and setting of current SNMP configuration. list sysconf shutdown start comconf delcomm trapconf agconfig trap 1800-A2-GB20-00 Command Line Interface User’s Guide... -
Page 66: List
Command Line Interface User’s Guide 5.4.1 list list This command lists the current SNMP configuration like system version, system contact, System location, system id etc. EXAMPLE 5.4.2 sysconf sysconf [-d] [-c] [-l] [-i] value -d: System Version Description -c: System Contact -l: System Location -i: Assigned Enterprise Number The sysconf command configures system version description, system contact, system location,... -
Page 67: Shutdown
EXAMPLE [1234 @ snmp]$ sysconf -d office1 This command configures the system version description to office1. 5.4.3 shutdown shutdown This command shuts down the SNMP agent. To configure the SNMP agent, shut down the agent first. 5.4.4 start strat This command starts the SNMP agent. 5.4.5 comconf comconf $ipaddress $community_name -o $access... -
Page 68: Trapconf
Command Line Interface User’s Guide COMMAND DESCRIPTION $index Community index in list. The index number can be displayed using the list command. EXAMPLE delcomm 0 5.4.7 trapconf trapconf [1][2] $IPADDRESS $community this command sets up the SNMP trap 1 and trap 2 COMMAND DESCRIPTION SNMP Version 1 SNMP Version2... -
Page 69: Agconfig
5.4.9 agconfig agconfig $interface -o $port This command sets up the SNMP agent COMMAND DESCRIPTION $interface interface on which agent will run, such as eth0, mer0, atm0….atm7, and ppp0….ppp7. $port Port Number (the default port No is 161) EXAMPLE agconfig atm0 -o 121 If the SNMP agent is running, to configure its parameters, first shut it down by using the shutdown command, and then you can configure the parameters. -
Page 70: Policy Delete
Command Line Interface User’s Guide COMMAND DESCRIPTION policy set <Policy-ID > <RxIfName> <TxIfName> <Sequence> {Allow|Deny} [srcip <a.b.c.d> [<e.f.g.h>]] [dstip <a.b.c.d> [<e.f.g.h>]] [sport <p1> [<p2>]] [dport <p1> [<p2>]] [proto <Protocol>] [nat <NAT-Action-ID>] This command is used to add firewall rule. 5.5.2 policy delete policy delete <QoS-Policy-ID>... -
Page 71: Policy Enable
5.5.4 policy enable policy enable <QoS-Policy-ID> Enable the firewall rule. 5.5.5 policy disable policy disable <QoS-Policy-ID> Disable the firewall rule. 5.5.6 policy list policy list [default] [<IfName1>] [<IfName2>] List the firewall rule. EXAMPLE policy set eth0 atm0 2 allow srcip 192.168.1.23 dstip 172.16.1.100 proto tcp 5.5.7 nat <interface>... -
Page 72: Publicip
Command Line Interface User’s Guide Alias only unregistered addresses -same_ports [yes|no] Try to keep original port numbers for connections -status Display currently configured NAT options -disable Disable NAT -enable Enable NAT 5.5.8 publicip publicip publicip add/delete <public address> publicip list NAT Public Address Configuraton COMMAND DESCRIPTION publicip add/delete <public address>... -
Page 73: Nataction
LOCAL-ADDR/PORT ALIAS-ADDR/PORT REMOT-ADDR/PORT LINK/EX.TIME IN/OUT-PKTS ~~~~~~~~~~~~~~~ ~~~~~~~~~~~~~~~ ~~~~~~~~~~~~~~~ ~~~~~~~~~~~~ ~~~~~~~~~~~ 192.168.1.127 0.0.0.0 192.168.1.151 3322 5.5.10 nataction nataction nataction add static/rdaddr/rdport <addr1 [addr2]> [-tp port1 [port2]] nataction delete/list/enable/disable <action-id> Redirect the IP address or the port. COMMAND DESCRIPTION nataction add Add static NAT address, redirect address, or redirect port. nataction delete <action-id>... -
Page 74: Setwt
Command Line Interface User’s Guide COMMAND DESCRIPTION spoof list : list the all the trusted and untrusted interfaces along with status spoof enable : Enable spoof protection spoof disable : Disable spoof protection spoof eth1 trusted : Set eth1 as trusted interface spoof eth1 untrusted : Set eth1 as untrusted interface 5.5.12... -
Page 75: Attach
Traffic Name Weight (%) --------------------------------- Default Medium High Critical Real Time Premium Urgent 5.5.15 Attach attach attach <interface_name> -o linkspeed <kbps> admission <yes/no> borrow <yes/no> ackpriority This command is used to attach an interface to WFQ. Default Link Speed : Baud rate of the interface Default admission: no Default Borrow: yes Default AckPriority : Disable... -
Page 76: Listwfq
Command Line Interface User’s Guide ackpriority <enable/disable> ACK packet can be transferred first. EXAMPLE attach adsl0 –o linkspeed 800 admission no borrow yes ackpriority no 5.5.16 listwfq listwfq This command is used to show all configured WFQ EXAMPLE listwfq Interface Information: ---------------------- Name Link Speed Admission Borrow Ack Priority adsl0 800... -
Page 77: Qstat
EXAMPLE remove adsl0 5.5.18 qstat qstat qstat $interface_name This command is used to show queues statistics on a interface. 5.5.19 createtc createtc createtc <dfmark/dfnomark> <priority_class> -o assuredbw <value> maxbw <value> This command is used to create a Traffic Conditioning rule. COMMAND DESCRIPTION <dfmark/dfnomark>... -
Page 78: Listtc
Command Line Interface User’s Guide This command is used to delete TC. EXAMPLE deletetc all 5.5.21 listtc listtc listtc <action_id/all> This command is used to list the TC rule. EXAMPLE Listtc all ActionId DF-Marking Priority Assured BW(kbps) Max BW(kbps) --------------------------------------------------------------- dfnomark Critical NA ---------------------------------------------------------------... -
Page 79: Napt
attack enable/disable <attack_type> attack list This command is used to setup rules to avoid some attacks from network. COMMAND DESCRIPTION attack set <attack_type> [<threshold> <timeout>] Set the attack type rule with threshold and timeout value. attack enable/disable <attack_type> Enable or disable the rule of the attack type. attack list List the current attack list. -
Page 80: Natif
Command Line Interface User’s Guide 5.6.1 natif natif [enable/disable/list] -o ifname The natif command enables or disables the dynamic NAPT for the WAN interface (e.g., atm0, ppp0, mero…), or displays the interface status. EXAMPLE natif enable -o mer0 enables NAPT for mero. natif disable –o atm0 disables NAPT for atm0. - Page 81 unregistered_only nat -o -unregistered_only [yes|no] If yes, only the outbound packets with unregistered source IP addresses are translated. All the outbound packets with the registered source IP addresses are forwarded on the WAN interface without translation. This is useful if you have one more subnet having a registered IP address that shares the common WAN link with the subnet having an unregistered IP address.
-
Page 82: Addressmap
Command Line Interface User’s Guide nat -o –alias_address 202.54.30.50 This command configures alias address as 202.54.30.50 and maps this IP address to a interface and takes that as NAT interface. ifa network_if_name This command configures the specified WAN interface to use dynamic Network Address Translation. -
Page 83: Portmap
[<public_addr>] Maps one or more single local IP addresses to a public IP address. One to one mapping is used for both inbound and outbound connections and many to one mapping are used only for outbound connections. For outbound connections, the packets matches a static link then it creates dynamic link with that static link information on outgoing path. -
Page 84: Delrdaddr
Command Line Interface User’s Guide This option is used to add or delete the portmap link. tcp | udp This option specifies whether the ports numbers for these arguments are TCP or UDP port numbers. <local_addr>:[<port>/<port range>] The IP address (local_addr) of the machine on the local LAN that the packet will be directed to. The value of the destination port in the packet header is specified by port or the port should fall in the specified range of ports. -
Page 85: Maplist
The local_addr specified in the addrdaddr command. If the local address is a single address or a subnet address, the user should specify the local address/subnet address. If it is a range of addresses, the user should specify the first address in the range. Removes an address mapping that was specified in the addressmap command. -
Page 86: Delpublic
Command Line Interface User’s Guide addpublic 217.15.52.34 This command enters the public IP address 217.15.52.34 into the pool. 5.6.9 delpublic delpublic <index> This command removes the entered IP addresses specified by index. 5.6.10 listpubaddrs listpubaddrs This command lists the public IP addresses that were configured with addpublic 5.7 HTTP proxy httpproxy -o [enable/disable] [-stat] [-display] [-auth [enable/disable]] Proxy servers restrict users from communicating directly with the public servers. -
Page 87: Dhcp Server
httpproxy -o –display This option is used to display the configured information of httpproxy. httpproxy -o -stat This option is used to display the statistics of the connections passing through the httpproxy, including inbound packets, outbound packets, inbound bytes, and outbound bytes. httpproxy -o -auth[enable/disable] This option is used to enable or disable the authentication module in httppproxy. -
Page 88: Stop
Command Line Interface User’s Guide 5.8.2 stop stop This command stops the DHCP server. EXAMPLE [1234 @ dhcpserver]$ stop DHCP Server stoppped !!! [1234 @ dhcpserver]$ 5.8.3 subnet subnet if add -o -subnet <subnet> -netmask <mask> -startip <startip> -endip <endip> - leasetime <lease time in days>... -
Page 89: Host
The amount of time the DHCP lease of the IP address will last. This is specified in days. The default is 7 days. -broadcast <broadcast-address> The IP broadcast address that the server will listen to for DHCP requests. By default a standard broadcast address for the subnet is used. -
Page 90: Lease
Command Line Interface User’s Guide EXAMPLE host add -o -macaddr 00.00.00.d1.26.95 -ipaddr 192.168.5.34 This command specifies that the machine with the MAC address of 00.00.00.d1.26.95 will be assigned the IP address 192.168.5.34. host delete -o -macaddr 00.00.00.d1.26.95 This command removes this host configuration for the machine with the MAC address of d1.26.95. -
Page 91: Adsl
This option shows the status of the DHCP Relay. 5.10 ADSL Commands for setting and viewing ADSL parameters are in the “adsl” directory. 5.10.1 setmode setmode <mode> [-trellis on/off] [-vendor default/broadcom/gsv/infineon/ti] -o [-bitswap on/off] This command sets the mode of the ADSL link to ANSI (T1.413), G.DMT, G.Lite, or multi- mode. -
Page 92: Writecmv
Command Line Interface User’s Guide 5.10.3 writecmv writecmv <cmv_index> <offset> <value> The ADSL Configuration and Management Variables (CMV) can be written with the writecmv command. The CMV variables are documented in “CMV Reference Manual”. This command will take effect only after the link is reconnected. COMMAND DESCRIPTION <cmv_index>... -
Page 93: Delusercmv
The offset value which is a decimal in the range of 0 to 65535. <value> Value of the CMV. Value is expected in hexadecimal format. <command> Type of operation ( Read or Write ). <msgid> Message Id in decimal digits. 5.10.6 delusercmv delusercmv <index>... -
Page 94: Mwrite
Command Line Interface User’s Guide COMMAND DESCRIPTION <offset > 0 - 3ffff (hexadecimal) < value > 0 - ffff (hexadecimal) 5.10.10 mwrite mwrite <offset> <value> This command writes 1 32-bit word into Eagle 16 bit data memory COMMAND DESCRIPTION <offset> 0xa0000000 - 0xbfffffff (hexadecimal) <value>... -
Page 95: Tone
This command terminates the ADSL link 5.10.14 tone tone <offset1> <offset2> Options offset1 and offset2 are the numeric value from 0 to 287 EXAMPLE To read all the tone information, enter the command: tone 0 287 To read the tone 11 to 20 information, enter the command: tone 11 20 5.10.15 bitalloc... -
Page 96: Adsl2+ Cli
Command Line Interface User’s Guide 5.11 ADSL2+ CLI 5.11.1 Configuration Command syntax: setmode <Hex value> Usages: This command sets the mode of the ADSL link to ANSI (T1.413), G992.1(G.dmt), G992.2(G.Lite), G992.3(ADSL2), G992.5(ADSL2+) or multi-mode. After executing this command, the configuration can be saved and the next time the machine is rebooted, the mode will take effect. -
Page 97: Displaying
5.11.2 Displaying Command syntax: Usages: It displays the state of the ADSL connection. It only gives meaningful information when the link is Example: ADSL Monitoring is Successful. The values are: adslLineStatus : OPERATIONAL adslMode : G992_5_A Upstream = 1016 Kb ( Interleave ) Downstream = 23996 Kb ( Interleave ) ====================================================== DIAG Info... -
Page 98: Dns
Command Line Interface User’s Guide 5.12 DNS list help dnsr Commands for setting DNS parameters are in the “dns” directory. From the “home” directory, type “dns” to enter the directory. The available commands are shown below after typing ls. Among the commands, help is used to give instructions about how to use the other commands. 5.12.1 list list... -
Page 99: Dnsr
[cli @ dns]$ set –n1 137.23.41.2 This command sets the primary name server for DNS queries. [cli @ dns]$ set –n1 0 This command removes the primary name server. 5.12.3 dnsr dnsr start -o [<server1>] [<server2>] dnsr stop -o [<server1>] [<server2>] This command enables/disables the DNS relay function. -
Page 100: Igmp Proxy
[1234 @ home]$ igmp -o -proxyif eth0 [1234 @ home]$ -routerif <interface> This option sets the router interface. Typically a WAN interface (ATM0, PPP0) is specified. When the router interface is successfully configured, the home prompt displays. EXAMPLE [1234 @ home]$ igmp -o -routerif atm0 [1234 @ home]$ -deleteif <interface>... -
Page 101: Rip
5.14 Rip RIP is a protocol that automatically updates the routing entries on the system. This is done by cooperating with other nearby routers. The RIP commands are located in the “rip” directory. Two commands are available: rip and ver. In order for any configuration changes to take effect, the configuration must be saved (with “save”... -
Page 102: Sndcp
Command Line Interface User’s Guide 5.15 SNDCP The SNDCP commands are located in the sndcp directory. routedbridge ipoa list pppoe pppoealive onetime pppoestart pppoestop pppoelist pppoedefault pppoa pppoedel pppoadel pppoastart pppoastop pppoalist pppoadefault liststat ppptrace 1483mer relay 5.15.1 pppoe pppoe <profile> -o <-if Interface> <-encap Encapsulation> <-restarttime Timeout> <-auth Auth>... - Page 103 Command Line Interface User’s Guide COMMAND DESCRIPTION profile Profile number to configure. Specify an integer number from 0 through 7. Interface Interface name with unit number. Eight PPP interfaces are available: ppp0, ppp1, ppp2, ppp3, ppp4, ppp5, ppp6, ppp7. These interfaces are configured for the PPPoE and PPPoA services. Encapsulation Encapsulation type (LLC or VC) Timeout...
-
Page 104: Pppoedefault
Command Line Interface User’s Guide The ATM vpi value which was assigned in a vcadd command or listed in a atmshowconn command. The ATM vci value which was assigned in a vcadd command or listed in a atmshowconn command. mask This specifies the netmask for the PPP interface. -
Page 105: Pppoestart
This command configures the specified profile as the default PPPoE connection. This profile must be using “auto” mode. Out of all the profiles which are using the “auto” option, only one can be run at a time. This command is used to specify that profile. If the “pppoedefault” command is not used, the first profile that used the “auto”... - Page 106 Command Line Interface User’s Guide COMMAND DESCRIPTION <profile> Profile number to configure. Specify an integer number from 0 through 7. interface Interface name with unit number. Eight PPP interfaces are available: ppp0, ppp1, ppp2, ppp3, ppp4, ppp5, ppp6, and ppp7. These interfaces are configured for the PPPoE and PPPoA services. Encapsulation Encapsulation type (LLC or VC) Timeout...
-
Page 107: Pppoastart
This enables or disables NAT (Network Address Translation) for this PPP interface. The default is for NAT to be disabled. mask This specifies the netmask for the PPP interface. The mask is specified in dot notation (i.e.255.255.255.0). OUI vpnId This specifies the VPN encapsulation. The OUI (Organizationally Unique Identifier) and VPN identifier are specified as numbers. -
Page 108: Pppoadefault
Command Line Interface User’s Guide 5.15.12 pppoadefault pppoadefault <profile> This command configures the specified profile as the default PPPoA connection. This profile must be using “auto” mode. Out of all the profiles which are using the “auto” option, only one can be run at a time. - Page 109 COMMAND DESCRIPTION interface The name of the WAN interface. Typically this is ‘atm0’. enable This enables this IPoA interface. disable This disables this IPoA interface. <vpi> <vci> These are the vpi and vci values on which ipoa has to be enabled/disabled. Vpi and vci are assigned with the vcadd command.
-
Page 110: Routedbridge
Command Line Interface User’s Guide 5.15.15 routedbridge routedbridge <interface> disable <vpi><vci> routedbridge <interface> enable <vpi><vci> -o <-enc encapsulation> <-vpn OUIvpnId> This command configures the specified WAN interface to use Routed Bridge which is RFC 2684 routing. Note the Maximum Transfer Unit (MTU) for the Routed Bridge is 9182. COMMAND DESCRIPTION interface The name of the WAN interface. -
Page 111: Mer
This command configures the specified WAN interface to use 1483MER (MAC Encapsulation Routing). The “mer” command is used to enable the configuration. COMMAND DESCRIPTION port The MER interface name (mer0). Vpi vci These are the vpi, vci values on which the 1483 is configured. vpi,vci are assigned with the vcadd command. -
Page 112: Liststat
Command Line Interface User’s Guide enable This enables the PPPoE Relay feature. disable This disables the PPPoE Relay feature. -display This displays the PPPoE Relay configuration. 5.15.19 liststat liststat bridge | routedbridge | ipoa | pppoe | pppoa This command lists the statistics of the specified module. 5.15.20 ppptrace ppptrace [on | off ]... -
Page 113: Showatmconn
5.16.1 showatmconn showatmconn This command lists the existing PVCs. EXAMPLE 5.16.2 vcadd vcadd <vpi> <vci> <service> <encaps> -o -peak <val> -avg <val> -mbs <val> -cdvt <val> This command establishes a Permanent Virtual Circuit (PVC) with the specified traffic descriptors. The service specifies the traffic type of the PVC. Permissible values are: cbr, rtvbr, nrtvbr, or ubr. -
Page 114: Vpadd
Command Line Interface User’s Guide This option defines the fastest rate a user can send cells to the network. It is expressed in units of cells per second. -avg <value> This option defines the maximum sustainable/average rate a user can send cells to the network. It is expressed in cells per second. -
Page 115: Deletevc
Peak cell rate (in cells/s) <avg val> Average/minimum (SCR) cell rate (in cells/s) <mbs val> Burst size in cells <cdvt val> Cell delay variation tolerance (in micro secs) 5.16.4 deletevc deletevc <vpi> <vci> This command deletes the specified PVC. The PVC is identified by the vpi / vci values. EXAMPLE deletevc 0 39 This command deletes a PVC with vpi=0 and vci=39. -
Page 116: Remote Web/Telnet/Ftp/Snmp
Command Line Interface User’s Guide The loopback identifier. This is specified as 32 hex digits. The default is: FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF 5.17 remote web/telnet/ftp/snmp remote [web|telnet|ftp|snmp] [on|off] This command enables or disables the remote access via web, telnet, ftp, or snmp. EXAMPLE remote web on This command enables the remote web access. - Page 117 Priority is mandatory parameter for configuring rule in ACL. By specifying priority we can prioritize rule in Access Control List. The priority values range from the highest priority 1 to the lowest priority 65535. <PERMISSIONS> This is a mandatory parameter for configuring a rule in ACL. By using this permission parameter we can specifies action for specific rule.
-
Page 118: Deleteacl
Command Line Interface User’s Guide Video files: Video: generic for all video files .mpg, .mpeg: video/mpeg (specific) -TIMEOFDAY <DAY1> <TIME1> <DAY2> <TIME2> This option is used filter the connections using the specified time. We can specify the day and time.DAY1 and DAY2 should be in string format like sun, mon, tue, wed, thu, fri, sat. TIME1, TIME2 should be in the hh:mm (24:00 hr format). -
Page 119: Listacls
5.18.3 listacls listacls <module> This command is used to displays the acls for the specified module. EXAMPLE listacls httpproxy This command displays all the acls configured for httpproxy. 1800-A2-GB20-00 Command Line Interface User’s Guide... -
Page 120: Chapter 6 Performance Monitoring
Command Line Interface User’s Guide Chapter 6 Performance Monitoring 6.1 Bitmap This bitmp command shows the allocation status of bitmaps like sockets, mbuffs and clusters. 1800-A2-GB20-00... -
Page 121: Statistic
6.2 Statistic The statistic command collects the information about IP, TCP, UDP, and ICMP protocols. [1234 @ home]$ statistic statistic parameter parameters - IP|TCP|UDP|ICMP|INTERFACE For example, to display the IP statistics, type statistic IP to display the IP information. 1800-A2-GB20-00 Command Line Interface User’s Guide... -
Page 122: Chapter 7 Tftp Upload & Download
Command Line Interface User’s Guide Chapter 7 TFTP Upload & Download The TFTP application provides both upload and download functions for the software and configuration settings. The upload enables the endpoint software (put app) or configurations (put param) uploaded as a file, which can be used for backup and maintenance purposes. -
Page 123: Uploading The Software File
The message “Using octet mode to transfer files” or “using netascii mode to transfer files” displays for your reference. To return to the home prompt, use the bye command. The following sections of this chapter will describe the procedures for the upload and download. In all the examples used in these sections, the TFTP server IP address, 172.16.4.16 and file name are only used for reference. -
Page 124: Auto Upgrade
Command Line Interface User’s Guide 4. The following message pops up if the software upload is successful. putting app to xxx.xxx.xxx.xxx : Sent bytes in seconds tftp> connect 172.16.4.16 connected to : 172.16.4.16 tftp> binary mode set to octet tftp> put app sw2003.bin putting app to 172.16.4.16 : sw2003.bin [octet] Sent 983040 bytes in 3 seconds tftp>... - Page 125 1. At the tftp prompt, type connect xxx.xxx.xxx.xx. tftp> connect 172.16.4.12 connected to : 172.16.4.12 A message, “connected to : xxx.xxx.xxx.xxx,” pops up if successful. 2. Type the transfer mode (binary or ascii). tftp> binary mode set to octet A message, “mode set to octet/netascii,” pops up. 3.
-
Page 126: Upgrading The Software
Command Line Interface User’s Guide 7.4 Upgrading the software 1. At the tftp prompt, type connect xxx.xxx.xxx.xx. tftp> connect 172.16.4.12 connected to : 172.16.4.12 A message, “connected to : xxx.xxx.xxx.xxx,” pops up if successful. 2. Type the transfer mode (binary or ascii). tftp>... -
Page 127: Downloading The Configurations
7.5 Downloading the Configurations 1. At the tftp prompt, type connect xxx.xxx.xxx.xx. tftp> connect 172.16.4.16 connected to : 172.16.4.16 A message, “connected to : xxx.xxx.xxx.xxx,” pops up if successful. 2. Type the transfer mode (binary or ascii). tftp> binary mode set to octet A message, “mode set to octet/netascii,”... -
Page 128: Chapter 8 Wireless Lan
Command Line Interface User’s Guide Chapter 8 Wireless LAN This chapter is only relevant for devices that have wireless LAN functionality. The parameters listed below are available from the [root @ wlan]$ directory. Wireless LAN Configuration Command syntax: wlancfg get [parameter] wlancfg set [parameter]=[value] Usages: Configures/gets wireless LAN configuration. - Page 129 Parameter TxRate 0 : Auto 1 :1Mbps 2 : 2Mbps 3 : 5.5Mbps 4 :11Mbps 5 : 6Mbps 6 : 9Mbps 7 : 12Mbps 8 : 18Mbps 9 : 24Mbps 10 : 36Mbps 11 : 48Mbps 12 : 54Mbps Channel 1~14,depends on country region BeaconPeriod 20~999, unit : ms...
- Page 130 Command Line Interface User’s Guide Parameter TurboRate 0 : Disable 1 : Enable NoForwarding 0 : Disable 1 : Enable HideSSID 0 : Disable 1 : Enable ShortSlot 0 : Disable 1 : Enable IEEE8021X 0 : Disable 1 : Enable AuthMode OPEN SHARED...
- Page 131 Parameter Key1 5 ascii characters or 10 hex numbers 13 ascii characters or 26 hex numbers Key2 5 ascii characters or 10 hex numbers 13 ascii characters or 26 hex numbers Key3 5 ascii characters or 10 hex numbers 13 ascii characters or 26 hex numbers 5 ascii characters or 10 hex Key4...
-
Page 132: Wireless Association
Command Line Interface User’s Guide wlancfg get Channel Wireless Association When the endpoint finishes booting, the stations can connect to AP during the “AssocTime” interval. Afterward, if other stations want to connect to AP, please use CLI “association” command to let them connect to AP during the “AssocTime” interval. Command Line Interface 8.3.1 disassoc... -
Page 133: Listdevices
8.3.4 listdevices Command syntax: listdevices Usages: List subscribed devices. 8.3.5 Example Assumption that no station connected to AP. First we set the “AssocTime” interval to 1 minute. And we get the “AssocTime” interval. Then we list subscribed devices. It’s a blank list, because nobody connected to AP. -
Page 134: Wireless Lan Batch Configuration
Command Line Interface User’s Guide [root @ wlan]$ remaintime The remainder association time : 00:40 [root @ wlan]$ listdevices Subscribed devices list =============== Entry =============== Entry #01> 00:0D:88:87:E5:DE [root @ wlan]$ disassoc 00:0D:88:87:E5:DE [root @ wlan]$ listdevices Subscribed devices list =============== Entry =============== Wireless LAN Batch Configuration Command syntax:... - Page 135 Option Apply Note: The end of batch file must be SSID=xxxx. If you Telnet to the endpoint with wireless interface, the Telnet session will be broken by “batch apply.” Example: batch clear batch add -o Channel=10 batch add -o HideSSID=0 batch add -o SSID=Wireless batch apply 1800-A2-GB20-00...
