162 Appendix B: Technical reference
• Maximum frequency. The maximum frequency is the number of times a signal
will reach the peak of its pulse within a thousandth of a second.
Mode Total voltage (Vcc)
Input 5 V
24 V
Output 24 V
5 V
• Power characteristics. The power characteristics describe the minimum and
maximum voltage and current for input and output signals.
Mode Description
Input Voltage range for Matrox 4Sight X unit to interpret voltage
on auxiliary I/O interface (input ports) as a "1."
Voltage range for Matrox 4Sight X unit to interpret voltage
on auxiliary I/O interface (input ports) as a "0."
Output Allowable voltage range on Matrox 4Sight X auxiliary I/O
interface output ports (sink to ground, 100 mA, fuse
protected).
Allowable current range on Matrox 4Sight X auxiliary I/O
interface output ports.
Current load (Icc)
100 mA
5 mA
100 mA
5 mA
Minimum
2.4 V
0 V
0 V
0 A
Maximum
30 kHz
30 kHz
60 kHz
60 kHz
60 kHz
60 kHz
Maximum
24 V
0.8 V
24 V
0.1 A
