Page 1 Matrox Mojito MAX Installation and User Guide (Windows version) July 8, 2013 Y11149-201-0750...
Page 2 Disclaimer Matrox Electronic Systems Ltd. reserves the right to make changes in specifications at any time and without notice. The information provided by this document is believed to be accurate and reliable. However, no responsibility is assumed by Matrox Electronic Systems Ltd. for its use; nor for any infringements of patents or other rights of third parties resulting from its use. No license is granted under any patents or patent rights of Matrox Electronic Systems Ltd.
Page 3 The warranty is voided by removal or alteration of identification labels on the Matrox Product or its parts. In the event of a defect in a Matrox Product during the applicable warranty period, Matrox shall at its sole option, either i) repair the defect using new or refurbished parts and return the repaired Matrox Product within a reasonable delay;...
Page 4 Matrox at its sole discretion. Matrox disclaims any representation that it will be able to repair any Matrox Product under this warranty or make a Matrox Product exchange without risk to or loss of the programs or data.
Page 5 Matrox Product or any business interruption. Matrox disclaims and shall have no obligation to indemnify or defend You or any third party in respect of any actual or alleged infringement of any actual or pending patents, copyright or other intellectual property rights.
Page 6 When returning a Matrox Product, leave the configuration as it was when You were using it, and leave all identification stickers on the Matrox Product. Pack the Matrox Product in its original box and return it to your Matrox dealer or distributor where the Matrox Product was purchased, together with your proof of purchase.
Page 7 However, Licensee must use the Software on a single computer owned or leased by Licensee at a time, in conjunction with and for the purpose of, operating the Matrox hardware. Licensee shall also have the right to make one copy of the Software in any computer-readable or printed form for back-up or archival purposes;...
Page 8 Software. Licensee is solely responsible for adequate protection and backup of the data and equipment used in connection with any of the Software, and Matrox will not be liable for any damages that may be suffered in connection with use of the Software.
Page 9 This License will automatically terminate if Licensee fails to comply with any of the terms and conditions hereof. In such event, Licensee must destroy all copies of the Software and all of its component parts. Matrox reserves the right to terminate this License without prejudice to any additional recourses Matrox may have against Licensee if Licensee violates any of this Licenses' terms and conditions.
Page 10 The failure of Matrox to enforce at any time any of the provisions of this Agreement, or the failure to require at any time performance by the Licensee of any of the provisions of this Agreement, shall in no way be construed to be a present or future waiver of such provisions, nor in any way affect the right of Matrox to enforce each and every such provision thereafter.
Page 11 End User agrees to indemnify Matrox for any and all claims arising from any violation by it of the terms of this License Agreement.
Page 12 MPEG Licensing Authority, LLC (or MPEG LA). Matrox has no obligation to indemnify, defend or hold End User harmless from and against any claims of infringement of intellectual property that reads upon or is infringed by a generally recognized audio, video, technology or patent standard or recommendations, including without limitation AVC/H.264, IEEE...
Page 13 Matrox is given a reasonable opportunity to object to or restrict such disclosure requirement to the extent practicable, and then such disclosure shall be permitted only subject to the terms and conditions of such order or other legal requirement.
Page 14 INJURY. LICENSEE WILL NOT USE, OR PERMIT TO BE USED, THE PRODUCTS FOR SUCH HIGH-AVAILABILITY, FAIL-SAFE OR CRITICAL APPLICATIONS AND FURTHER, LICENSEE AGREES TO INDEMNIFY, DEFEND AND HOLD HARMLESS MATROX AND ITS MANAGERS, DIRECTORS, OFFICERS, EMPLOYEES, AGENTS, AFFILIATES, SUCCESSORS, AND ASSIGNS FROM AND...
Page 15: Table Of Contents
Mojito MAX hardware ..............8 Updating your display card’s drivers ............ 9 Setting Matrox Mojito MAX as your default audio playback device ..9 Note about using sleep and hibernation modes with Mojito MAX..9 Removing your Matrox Mojito MAX software........10...
Page 16 Connecting the Mojito MAX I/O cable to your system ......12 Connecting HDMI and SDI devices to Mojito MAX ......13 Connecting S-Video devices to Mojito MAX ........14 Mojito MAX RS-422 serial connection ..........15 Typical Matrox Mojito MAX connections ..........16 Analog component video connections ............
Page 17 Available effects ................. 72 How to apply a Matrox video effect in Adobe Premiere Pro....73 How to apply a Matrox video transition in Adobe Premiere Pro ..73 Applying a mask to your Matrox effects..........74 Using Select Mask ..................75 Creating a Matrox primary color correction........
Page 18 Defining your playback settings ............116 Chapter 8 Using Matrox Mojito MAX with Avid Editing Applications Creating a new project on Matrox Mojito MAX ......... 120 Defining your playback settings ............120 Specifying your video output settings ............120 Specifying your genlock settings ............. 124 Specifying your audio output settings............
Page 19 Autodesk 3ds Max ................... 171 Autodesk Combustion ................172 eyeon Fusion ................... 172 NewTek LightWave 3D ................172 Chapter 11 Using Mojito MAX with Adobe and Microsoft Live Media Encoders Overview.................... 174 Specifying your settings for media streaming ........174 Contents...
Page 20 Chapter 15 Using the Matrox MAX H.264 Codec with Adobe Software Exporting to Matrox MAX H.264 files using Adobe Media Encoder .208 Performing a direct export of an Adobe Premiere Pro sequence ..213 Transcoding for Blu-ray Disc authoring in Adobe Encore ....215 Specifying your Matrox MAX H.264 settings ........
Page 21 Specifying your capture format settings .......... 230 Starting your capture................ 234 Chapter 17 Monitoring Your Matrox Mojito MAX System Using X.info to display Mojito MAX information ........ 238 Displaying system information ..............238 Displaying hardware information ............240 Monitoring your Mojito MAX’s operating temperatures ......241 Selecting your primary Matrox I/O device ..........
Page 22 Playback using Avid editing applications ..........262 Playback using Matrox A/V Tools and Matrox WYSIWYG......264 Supported video output formats for monitoring .......268 Adobe Premiere Pro ................268 Avid editing applications ................269 Matrox A/V Tools..................270 Matrox MAX H.264 Capture and Telestream Wirecast......271...
Page 23: Introducing Matrox Mojito Max
Introducing Matrox Mojito MAX This chapter lists the Mojito MAX system requirements, and describes the Mojito MAX documentation.
Page 24: Welcome To Matrox Mojito Max
• Intel Core 2 Duo 2.67 GHz or Intel Core i7 2.67 GHz CPU. ¦ Note If you want to use Mojito MAX with Telestream Wirecast, you must have an Intel Core i7 2.67 GHz CPU or greater. • Microsoft Windows 7 Professional, Ultimate, or Home Premium (64-bit) with Service Pack 1.
Page 25: Check Our Website For Equipment Information
MAX-compatible devices, check the Matrox Mojito MAX Support section of our website at www.matrox.com/video/support. ¡ Important To use Matrox Mojito MAX with Avid editing software, you must use an Avid-certified system as listed in the “System Recommendations” section of the Matrox Mojito MAX Support section of our website at www.matrox.com/video/support.
Page 26: Last-Minute Information
• 1080i @ 29.97 fps Represents full-size 1920 ×1080 interlaced video at 29.97 frames per second. Last-minute information Any important information that wasn’t available for inclusion in this manual by publication time is provided to you in the Matrox Mojito MAX Release Notes. Chapter 1, Introducing Matrox Mojito MAX...
Page 27: Installing Your Matrox Mojito Max Hardware And Software
Installing Your Matrox Mojito MAX Hardware and Software This chapter explains how to install the Matrox Mojito MAX hardware and software.
Page 28: Installing Multiple Matrox Mojito Max Cards
Installing multiple Matrox Mojito MAX cards You can choose to install multiple Matrox Mojito MAX cards to feed live video and audio to Telestream Wirecast for streaming and recording (see Chapter 13, “Using Matrox Mojito MAX with Telestream Wirecast”). All other applications used with your Matrox Mojito MAX hardware, such as Matrox A/V Tools and editing applications, support only one Matrox I/O device.
Page 29: Installing Your Matrox Mojito Max Card
MAX hardware with CompressHD. For details on installing CompressHD, see your Matrox CompressHD Installation and User Guide. • If you want to use a Matrox Convert DVI product with Mojito MAX on the same system, you must install Matrox MtxConvert.utils instead of Matrox Mtx.utils.
Page 30: Installing The Matrox Effect Patterns
Mtx.utils and the Matrox Mojito MAX hardware. This flexibility allows you to use a remote editing workstation to create a rough cut of your project, and then copy the project and assets to your Mojito MAX system to finish the job. ¦ Note If you’ve installed Matrox Mtx.utils, you do not need to install the...
Page 31: Updating Your Display Card's Drivers
Setting Matrox Mojito MAX as your default audio playback device You can use Matrox Mojito MAX as your output device for playing back audio using Windows Driver Model (WDM)-based applications on your Windows system, such as Windows Media Player. To set Mojito MAX as your default sound playback device in Windows, do the following: Choose Start >...
Page 32: Removing Your Matrox Mojito Max Software
• To remove Matrox Mtx.utils from your computer, choose Start > All Programs > Matrox Mtx.utils > Uninstall Matrox Mtx.utils • To remove the Matrox effect patterns from your computer, choose Start > All Programs > Matrox Effect Patterns > Uninstall Matrox Effect Patterns •...
Page 33: Connecting External Devices To Matrox Mojito Max
Connecting External Devices to Matrox Mojito MAX This chapter shows how to connect external devices to Matrox Mojito MAX.
Page 34: Available Mojito Max Connections
The HDMI and SDI inputs and outputs are located on the Mojito MAX card, and all other available inputs and outputs are located on the Mojito MAX I/O cable.
Page 35: Connecting Hdmi And Sdi Devices To Mojito Max
Your Matrox Mojito MAX card includes one HDMI input and output, and one SDI input and output. Connect an HDMI or SDI device to your Mojito MAX via an HDMI or SDI cable connected to the corresponding input/ouput on your Mojito MAX card.
Page 36: Connecting S-Video Devices To Mojito Max
S-Video device to your Mojito MAX input/output. Connect the Y (luminance) and C (chrominance) BNC connectors on the S-Video adapter cable to the Pb/Y and Pr/C connectors on the Mojito MAX I/O cable respectively, as shown below. ¦ Note When you connect an S-Video device to Mojito MAX, you won’t be able...
Page 37: Mojito Max Rs-422 Serial Connection
Mojito MAX I/O cable to your computer, and then connect the RS-422 cable on the Mojito MAX I/O cable to the RS-422 serial port on your external device. For information on how to configure Matrox RS-422 device control settings in Adobe Premiere Pro, see “Setting up Matrox device control”...
Page 38: Typical Matrox Mojito Max Connections
You may, however, use the same deck as both your source and record device by making the input and output connections to a single deck. For details on the Mojito MAX inputs/outputs, see “Mojito MAX input and output descriptions”...
Page 39: Digital Video Connections
In this illustration, we’re using SDI connectors for video and audio, and an HDMI connector for video monitoring. The video is genlocked using a tri-level sync generator. Matrox Mojito MAX card Matrox Mojito MAX I/O cable To Mojito MAX card Tri-level sync...
Page 40: Mojito Max Input And Output Descriptions
This section describes the inputs and outputs available on the Matrox Mojito MAX card and I/O cable. Inputs This section describes the inputs that are available on the Mojito MAX card and I/O cable. For a list of the supported input and capture formats, see Appendix B, “Matrox Mojito MAX Supported Input and Capture...
Page 41: Outputs
Connect XLR cables from a camera, VTR, audio mixer, or other audio input source. Outputs This section describes the outputs that are available on the Mojito MAX card and I/O cable. Matrox Mojito MAX card • HDMI OUT Provides a Type C HDMI socket output for HD/SD HDMI video, and up to eight channels of embedded audio, to a digital HDMI device.
Page 42 S-Video adapter cable, to a video monitor, VTR, or other S-Video device. For instructions on how to connect S-Video devices to Mojito MAX, “Connecting S-Video devices to Mojito MAX” on page 14. ¦ Note The component output is not available when using the S-Video output.
Page 43 Calibrating Your HDMI Monitor for Video This chapter explains how to use the Matrox HDMI Calibration Utility to calibrate your RGB HDMI monitor for video.
Page 44: Calibrating Your Hdmi Monitor For Video
Overview The Matrox HDMI Calibration Utility is a unique tool designed to calibrate your RGB HDMI monitor or television so that it performs like a traditional broadcast video monitor. This utility provides a wizard that walks you through the calibration process using specially designed patterns to effectively identify and compensate for the processing errors that may be present in your HDMI monitor.
Page 45 ° To run the Matrox HDMI Calibration Utility: Ensure that your HDMI monitor is connected to the HDMI output on your Mojito MAX, turn the HDMI monitor on, and allow it to warm up for about 20 or 30 minutes.
Page 46: Loading Matrox Hdmi Calibration Settings
When you set the HDMI video output to RGB - calibrated , the video that is output from the Mojito MAX HDMI output will have the color settings that are saved in the currently loaded calibration file. This is used when you want to monitor video on your RGB HDMI monitor.
Page 47 ¦ Note When you configure your Matrox WYSIWYG output settings, the settings apply to all programs that display Matrox WYSIWYG output. This means that when you set the HDMI video output to RGB - calibrated using the Matrox WYSIWYG Control Panel, the currently loaded calibration settings will be applied when you preview HDMI video using any program that displays Matrox WYSIWYG output, such as Adobe After Effects.
Page 48 Your notes Chapter 4, Calibrating Your HDMI Monitor for Video...
Page 49 Using Matrox Mojito MAX with Adobe Premiere Pro This chapter explains how to define various settings for using Matrox Mojito MAX with Adobe Premiere Pro. This includes creating a new Premiere Pro project, and specifying your playback, capture, and export settings.
Page 50: Using Matrox Mojito Max With Adobe Premiere Pro
Displaying warnings in Adobe Premiere Pro’s Events panel Matrox Mojito MAX uses Adobe Premiere Pro’s Events panel to issue certain error messages and warnings. To display these, choose Window > Events . For more information about using the Events panel, see your Adobe Premiere Pro documentation.
Page 51: About The Matrox 10-Bit Editing Workflow
Matrox 10-bit uncompressed format for use in your sequence, render your video previews to Matrox 10-bit uncompressed format, and output your sequence at 10-bit on Matrox Mojito MAX for preview or export to tape. ° To use a Matrox 10-bit editing workflow: Create your sequence using one of the available presets under .
Page 52: Defining Your Playback Settings
Defining your playback settings In order to use your Matrox Mojito MAX hardware to output video and audio played back in Adobe Premiere Pro, you must set your video and audio devices to use the Matrox Player as follows: Choose Edit > Preferences > Playback .
Page 53 ° To specify your video output settings: In the Matrox Playback Settings dialog box, click the Video Output tab. Select Lock output formats if you want to ensure that the currently selected main and secondary video output formats for playback won’t change when working in your project.
Page 54 Under Main Output and Secondary Output , you can specify the settings you want for your main and secondary outputs from Mojito MAX. Depending on your sequence’s video format, you may not be able to change some of the settings.
Page 55 Outputs adjusted RGB HDMI video using the RGB - calibrated • currently loaded Matrox HDMI calibration settings for your HDMI monitor or television. For details on calibrating your HDMI monitor and loading calibration settings using the Matrox HDMI Calibration Utility, see Chapter 4, “Calibrating Your HDMI Monitor for...
Page 56 ¡ Important Only 10-bit uncompressed clips without effects or with GPU-accelerated effects, and video previews that have been rendered using the Matrox 10-bit uncompressed codec can be output at 10-bit. For more information about using this feature, see “About the Matrox 10-bit editing workflow”...
Page 57: Specifying Your Genlock Settings For Playback
¦ Note The status of your genlock source will be displayed, such as Locked or Not Locked , to indicate whether or not Mojito MAX is presently locked to your selected genlock source. When you change the genlock source, Defining your playback settings...
Page 58: Specifying Your Audio Output Settings
Mojito MAX locks to the new genlock source. Under Genlock Video Format , select your genlock source’s video format. If you can’t select a video format, make sure that your genlock source matches the specified video format.
Page 59: Specifying Your Closed Captioning Settings
SDI audio output ( 20-bit or 24-bit ). Under HDMI Audio Output , select Output only two audio channels if you want to output two audio channels from the Mojito MAX HDMI output, instead of eight channels. This option is especially useful for HDMI monitors that don’t accept more than two audio channels.
Page 60 Under Video Output , select Enable overlay on output to overlay the closed captions on all the Mojito MAX video outputs, which lets you display closed captioning on video monitors that don’t have a closed captioning feature. For the overlay to be displayed, closed captioning display must be enabled in Adobe Premiere Pro’s Program Monitor menu.
Page 61: Defining Your Video Preview Settings
MPEG-2 I-frame NTSC Standard for a Matrox NTSC standard sequence. • If you set the bit depth for your video output on Mojito MAX to 10-bit, you must use the Matrox 10-bit uncompressed codec for rendering video previews.
Page 62: Mapping Audio Output For A 5.1 Master Track
Mapping audio output for a 5.1 master track To properly output embedded HDMI audio on Matrox Mojito MAX for a 5.1 master track, you must map the audio output channels in your sequence as follows: • Channel 1: Left front •...
Page 63: Defining Your Capture Settings
Defining your capture settings The Matrox Capture Settings dialog box provides various settings for capturing video and audio in Adobe Premiere Pro on Matrox Mojito MAX. For information about the supported capture formats, see Appendix B, “Matrox Mojito MAX Supported Input and Capture Formats.”...
Page 64 ¦ Note If Matrox Mojito MAX can’t detect your source device when you start a capture, you’ll receive an error message. Either black video will be captured or the capture won’t be able to start until a valid input signal is present. In either case, you must make sure that your source device is switched on and properly connected to Mojito MAX to properly capture the video.
Page 65 Capture Aspect Ratio is set to match the Input Aspect Ratio . Under Codec , select the codec that you want to use for the capture. When capturing to an .m2v file, the codec is set to Matrox MPEG-2 IBP . Matrox 8-bit Uncompressed Captures video to 8-bit uncompressed format.
Page 66: Specifying Your Audio Capture Settings
Matrox Mojito MAX. Remarks • When you capture to an .avi file on Matrox Mojito MAX, the clip’s video and audio are saved to the .avi file, and the clip’s audio is also saved to one or more separate .wav files.
Page 67 If you want the VU meters to be displayed each time you configure your Matrox Mojito MAX capture settings or open the Capture panel to start a capture, select Show VU meters . For details on using the VU meters, see “Monitoring audio levels for capture”...
Page 68 .wav files you don’t want to be created, or click the D (default) button for each Filename list if you want to capture only channels 1 and 2. When Matrox Mojito MAX saves each .wav file, it assigns a .Stereo.wav or .Mono.wav suffix to the base name you gave for the associated video file.
Page 69 Monitoring audio levels for capture If you select Show VU meters on the Audio Capture Settings page, each time you configure your Matrox Mojito MAX capture settings or open the panel to start a capture in Adobe Premiere Pro, VU meters will be...
Page 70: Specifying Your Video Output Settings For Previewing Captured Clips
Specifying your genlock settings for capture You can select the source to which you want to genlock all devices connected to your Mojito MAX system during capture, as well as adjust the timing settings for all video outputs from Mojito MAX.
Page 71 Remarks To avoid inaccurate In/Out points during batch capture, you must select an external sync source. If you want to genlock to your video input source, select Video Input . Click OK to save your settings. Defining your capture settings...
Page 72: Notes About Capturing To Matrox .M2V Files
.m2v clips, and the time code information won’t appear for your .m2v clips in the Project panel. • Matrox .m2v files are to be used for DVD authoring with Adobe Encore. However, if you want to use your Matrox .m2v clips in Adobe Premiere Pro, be aware of the following issues: The associated .wav files for your .m2v clips are not automatically...
Page 73: Selecting Your Mpeg-2 I-Frame Settings
Selecting your MPEG-2 I-frame settings When using the Matrox MPEG-2 I-frame or Matrox MPEG-2 I-frame HD codec to capture or render video, you can specify various settings for the MPEG-2 I-frame compression. ° To select your MPEG-2 I-frame settings: Click the Configure button. This displays a dialog box similar to the following: Drag the Data Rate slider until your desired data rate is displayed.
Page 74 Select the Force Frame-based DCT setting to render macroblocks as frames rather than as fields. In some cases, graphics will yield less artifacts if this option is selected. Click OK to save your settings. Chapter 5, Using Matrox Mojito MAX with Adobe Premiere Pro...
Page 75: Selecting Your Mpeg-2 Ibp Settings
Selecting your MPEG-2 IBP settings When capturing video to a Matrox .m2v file using Adobe Premiere Pro, the codec is set to Matrox MPEG-2 IBP. You can specify various settings for the MPEG-2 IBP compression. ° To select your MPEG-2 IBP settings: Click the Configure button.
Page 76 (towards Fast/Low quality ) to decrease the quality of the motion estimation and speed up the video compression. Click OK to save your settings. Chapter 5, Using Matrox Mojito MAX with Adobe Premiere Pro...
Page 77: Exporting To A Matrox .Avi File
Matrox codecs to the ones included with Premiere Pro to allow you to export your sequence to a Matrox .avi file. With Matrox Mojito MAX, you can also export your sequence to a Matrox MAX H.264 file as explained in Chapter 15, “Using the Matrox MAX H.264 Codec...
Page 78 Exported audio will be embedded in your .avi file. Matrox Mojito MAX does not support audio-only exports to an .avi file. Click the Video tab. Under Codec , an appropriate Matrox codec is automatically selected for you based on your selected preset. You can change the codec if you want.
Page 79 If you’re exporting to Matrox MPEG-2 I-frame format, click the Configure button to select your MPEG-2 I-frame settings (see “Selecting your MPEG-2 I-frame settings” on page 51). Under Video , appropriate settings are applied based on your selected preset. You can customize these settings as follows: Sets the width and height for your exported video.
Page 80: Exporting An Ntsc Or 486P Sequence To Adobe Premiere Pro 720X480 Formats
DVD authoring programs, such as Adobe Encore. To export an NTSC or 486p sequence that has a Matrox codec editing mode to a 720 ×480 MPEG2-DVD format or any other Adobe Premiere Pro 720 ×480 format, you must select Scale to Fill from the Source Scaling menu on the panel of the Export Settings dialog box.
Page 81: Recording Your Voice-Over
The audio input channels are set to Channel 1-2 . Click OK to save your settings, and then click OK to close the Preferences dialog box. Recording your voice-over You use Adobe Premiere Pro’s Audio Track Mixer (CC) or Audio Mixer (CS6) to record your voice-over.
Page 82 You can record your voice-over on multiple tracks at the same time. If you enable recording for a mono track, you can select Matrox Left or Matrox Right from the Track Input Channel menu at the top of the panel to indicate which channel you want to record on that track.
Page 83: Setting Up Matrox Device Control
SMPTE time code protocol when capturing or exporting material to tape in Adobe Premiere Pro. To use this device control, you must connect the RS-422 connector on the Mojito MAX I/O cable to the RS-422 serial device control port on your source device or recorder (see “Mojito MAX RS-422 serial connection”...
Page 84 Because using the control track is not as reliable as LTC or VITC for device control, you should select this option only if you’re having problems using the time code on your tape. Chapter 5, Using Matrox Mojito MAX with Adobe Premiere Pro...
Page 85 30 fps Drop Frame or 25 fps if you’re using PAL video. Select Use VTR’s internal cue if the Matrox device control is having problems cueing your VTR, such as when you cue to a specific In or Out point. Because using the VTR’s internal cueing method slows down the cueing, you should select this option only if you’re experiencing problems...
Page 86: Requirements For Using Matrox Device Control
SDI video source for capture. For export to tape, you can set your genlock source to the Mojito MAX internal reference and configure the setting on your deck to genlock to the SDI video input. For details on how to set your genlock source, see “Specifying your genlock...
Page 87: Exporting Your Sequence To Tape
00:00:10:00. • To avoid repeated frames or broken time code when performing an assemble edit using Matrox device control, add ten seconds or more of black video or color bars to the end of your sequence. Exporting to tape using Matrox device control ¦...
Page 88: Exporting To Tape Using Matrox Device Control (Cs6)
• Adobe Premiere Pro uses the Matrox capture settings to allow you to preview your recording in the Edit To Tape panel. If you’ve connected the output of your recorder to the input on Matrox Mojito MAX, click Recorder to configure your video and audio input settings (input format and Settings source), and specify your video output settings for preview.
Page 89 Choose File > Export > Tape to display the following dialog box: To review or change your device control settings, click Device Options . This displays the Matrox RS-422 Device Control Settings dialog box as explained in “Setting up Matrox device control”...
Page 90: Obtaining A Frame-Accurate Export To Tape Using Matrox Device Control
Obtaining a frame-accurate export to tape using Matrox device control In order to obtain a frame-accurate export to tape when using Matrox device control, there are various settings that you may need to adjust in the Matrox RS-422 Device Control Settings dialog box: •...
Page 91 Stripe an NTSC tape with continuous and consecutive time code starting at 00:00:00:00. Create a new Matrox NTSC sequence with a bars and tone clip at least ten seconds long containing time code starting at 00:00:00:00. Make sure you place the clip at the start of your sequence.
Page 92 Alternately, if you see frame 00:00:00:05 from your bars and tone clip recorded at 00:00:30:00, then the sequence playback started five frames too late and you need to set the Playback Offset to -5. Chapter 5, Using Matrox Mojito MAX with Adobe Premiere Pro...
Page 93 Setting Up Matrox Effects with Adobe Premiere Pro This chapter explains how to set up Matrox effects such as color corrections and wipes using the Matrox plug-in for Adobe Premiere Pro.
Page 94: Setting Up Matrox Effects With Adobe Premiere Pro
When you install Matrox Mtx.utils, all the Matrox effects are added to Adobe Premiere Pro. You set up Matrox effects in your projects the same way as other effects included with your Adobe software. For example, you apply a Matrox...
Page 95: How To Apply A Matrox Video Effect In Adobe Premiere Pro
Premiere Pro The Matrox plug-in for Adobe Premiere Pro allows you to apply several Matrox video effects to your clips. To apply a Matrox video effect, drag the desired effect from the Effects panel onto the clip in the Timeline panel.
Page 96: Applying A Mask To Your Matrox Effects
Applying a mask to your Matrox effects The Matrox color correction, chroma key, and luma key effects allow you to add a mask to define the area where you want to apply your effect. For example, you may want to apply a color correction to only one area of your clip and leave the rest of the clip untouched.
Page 97: Using Select Mask
Using Select Mask To apply a mask to your Matrox effect using the Select Mask dialog box, click the triangle next to the Select property to expand it, then click the Select Mask button: dialog box allows you to apply a mask in two ways: Select Mask •...
Page 98: Creating A Matrox Primary Color Correction
Window > Workspace > Color Correction ° To set up a Matrox primary color correction: Click the triangle next to Matrox Color Correction (Primary) or Matrox Color Correction (Primary - Advanced) to expand the property list.
Page 99 , Saturation , and Luminance) Affects the lightest • areas of your clip. • Luma Mapping Graphical Allows you to see a graphical representation of your changes when you adjust the luma mapping settings. You can also modify the Creating a Matrox primary color correction...
Page 100: Using Split View
There are two ways to enable Split View. You can select the Enable Split View option in the Effect Controls panel, or work directly in Adobe Premiere Pro’s Program Monitor using your mouse. Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 101: Working With Split View In The Program Monitor
To activate the Split View controls in the Program Monitor, click the Transform icon ( ) beside the name of the Matrox color correction effect in the Effect Controls panel. The Split View button will appear in the upper left corner of the...
Page 102: Using Rgb Curves
(highlights). Before any adjustments are made, each point on the curve has the same input and output value. Default end point Default end point (shadows) (highlights) Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 103 For example, the following S-shaped master curve adds contrast in the midtones range, without creating any completely black or white areas. Creating a Matrox primary color correction...
Page 104: Adjusting Tonal Range
¦ Note You cannot increase the number of pixels in a tonal range. For example, you can’t extend the shadows curve into the highlights range. Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 105: Using The Color Balance Graph
Master color map, or adjust the color balance of only the shadows using the Shadows color map. Drag the handle toward a color you want to increase in your clip, or away from a color you Creating a Matrox primary color correction...
Page 106 Reset Color Balance button To adjust the luminance for a tonal range, drag the corresponding luminance slider under the appropriate color map. For example, if you want to adjust the Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 107 Shadows color map. Luminance slider Creating a Matrox primary color correction...
Page 108: Performing An Auto Balance
To perform an auto white balance, click the Auto White Balance button under the Master color map, and click (or click and drag) on a white or light gray area of your clip. Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 109: Matching Colors Between Two Clips
For more information about creating nested sequences, see your Adobe Premiere Pro documentation. Apply the Matrox Color Correction effect to your target clip on the timeline. Use the controls under the Reference Monitor to move to a frame in your reference clip that contains the colors you want to match.
Page 110 Select a match color from your target clip in the Source Monitor window by using the Match Color eyedropper under the corresponding color map ( Master , Shadows , Midtones , or Highlights ). Match Color eyedropper Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 111: Using The Luma Mapping Graph
Each luminance value present in your image appears as a vertical line in the histogram. A longer line indicates a higher amount of pixels in your image of that line’s luminance value. You can drag the handles Creating a Matrox primary color correction...
Page 112 The intermediate luminance values are proportionally redistributed. ¦ Note If you want to restore the default luminance values at any time, click the Restore Default Values button. Restore Default Values button Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 113: Creating A Matrox Secondary Color Correction
Creating a Matrox secondary color correction Matrox secondary color correction offers all the properties found in Matrox primary color correction, with the added capability of limiting the color correction to a specific range of pixels using the selective key properties. For...
Page 114 • with tones between the darkest and lightest areas of your clip. Highlights (Hue , Saturation , and Luminance) Affects the lightest • areas of your clip. • Luma Mapping Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 115 • Mask Allows you to apply a mask to your effect. For more information, “Applying a mask to your Matrox effects” on page 74. • Selective Key The selective key settings allow you to apply the color correction effect to a specific range of pixels in your clip.
Page 116 This type of key lets you select areas to be keyed (affected • by the color correction) based on their luminance value. Enable Select this to enable the Luma Key properties and luma key indicator in the selective key graph. Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 117 This setting is especially useful when setting up a color pass effect where you have several objects of the same color but want to retain the color for only one object. For more information, see “Creating a color pass effect” on page 100. Creating a Matrox secondary color correction...
Page 118: Using The Selective Key Graph
You can drag the handles to move the indicator to different regions in the graph to adjust the Hue Key , Saturation Key , and Luma Key properties. The luma plot histogram shows Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 119 Aperture Softness • Sat Click this button to enable or disable the Saturation Key properties ( Low Clip , Low Gain , High Gain , and High Clip ). When enabled you will Creating a Matrox secondary color correction...
Page 120 If you press you can lock and SHIFT CTRL move either the Low Clip and Low Gain handles or High Gain and High Clip handles. Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 121 To remove colors from your auto key, use the minus eyedropper. ¦ Note The Show Key mode and any color correction applied will be temporarily deactivated in the Program Monitor when using an eyedropper. Creating a Matrox secondary color correction...
Page 122: Creating A Color Pass Effect
Creating a color pass effect You can use the Matrox secondary color correction to create a color pass effect to convert your clip to black and white, with the exception of one specified color. This can be useful if you want to isolate a single color to make it prominent.
Page 123: Overview Of The Matrox Chroma Key Effects
Select Expand Outside Mask . Overview of the Matrox chroma key effects You can apply a Matrox chroma key or chroma key shadow effect to make certain areas of a foreground image transparent based on a color in that image, so that an underlying image can show through.
Page 124: Creating A Chroma Key Or Chroma Key Shadow Effect
Creating a chroma key or chroma key shadow effect To set up a Matrox chroma key or chroma key shadow effect, click the triangle next to Matrox Chroma Key/Matrox Chroma Key Shadow to expand the property list: •...
Page 125 Click this button to display the matte used to create your key Show Key effect. This enables you to further refine your key. For example, when you display the matte, your key color (such as green) appears as black, and opaque areas appear as white.
Page 126 (such as green) appears as black, and opaque areas appear as white. If you notice some white spots that you want to key, you can adjust the key controls until the undesired white spots disappear. Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 127: Using The Chroma Key Graph To Modify Key Colors And Perform An Auto Key
Using the chroma key graph to modify key colors and perform an auto key To modify your key colors directly within the chroma key graph or perform an auto key, click the triangle next to the Graphical property to expand it: •...
Page 128 You can use the eyedropper in two ways: Click the eyedropper button and click on a color on which you want to key. Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 129 Click the eyedropper button and click and drag anywhere on your clip to select a rectangular area containing colors on which you want to key. ¦ Note The Show Key mode and any chroma key applied will be temporarily deactivated in the Program Monitor when using the auto key eyedropper. This allows you to see the original colors of your clip before any modifications were made.
Page 130: Overview Of The Matrox Luma Key Effect
Overview of the Matrox luma key effect You can apply a Matrox luma key to make certain areas of a foreground image transparent based on the luminance in that image, so that an underlying image can show through. In the following example of a luma key effect, two video clips are combined to produce the effect of two cowboys riding through fire.
Page 131: Creating A Luma Key Effect
Creating a luma key effect To set up a Matrox luma key effect, click the triangle next to Matrox Luma Key to expand the property list: • Graphical Allows you to see a graphical representation of your changes when you adjust the property settings. You can adjust the luma key properties directly in the graph to select the luminance values on which you want to key.
Page 132: Using The Luma Key Graph
The luma key graph contains a luminance spectrum and a luminance eyedropper. You can drag the handles in the luminance spectrum to adjust the Transparency , , High Clip , Low Gain , and High Gain properties. Low Clip Eyedropper Chapter 6, Setting Up Matrox Effects with Adobe Premiere Pro...
Page 133 You can select luminance values on which to key by adjusting the Low Clip handles, or you can use the luminance eyedropper to automatically High Clip pick the luminance value you want to key on. The eyedropper can be used in two ways: •...
Page 134: Creating A Wipe Transition
Creating a wipe transition The Matrox wipe transitions support standard dissolves, SMPTE wipes, and organic wipes with soft edges and color borders. ° To set up a Matrox wipe transition: Click the transition’s icon in your sequence, then click the Custom button in the Effect Controls panel.
Page 135 Allows you to save your organic wipe settings to a file for future use. When you click the Save button, the Save As dialog box opens and allows you to name your effect and save it as a Matrox wipe transition (.mwt) file.
Page 136: Using The Matrox Chroma Clamper Effect
Adobe basic 3D effect to one portion of the clip, you may notice minor color differences between the two halves on your video monitor. Applying the Matrox chroma clamper effect to the portion of the clip that does not have the Adobe effect ensures that colors remain constant throughout the clip.
Page 137: Using Matrox Mojito Max With Adobe Speedgrade
Using Matrox Mojito MAX with Adobe SpeedGrade This chapter explains how to specify your playback settings for previewing video played back in Adobe SpeedGrade on Matrox Mojito MAX.
Page 138: Defining Your Playback Settings
Defining your playback settings You can output video played back in Adobe SpeedGrade on the Matrox Mojito MAX video outputs to preview your clips on your video monitor. For a list of the supported video output formats, see “Playback using Adobe SpeedGrade”...
Page 139 For more information about using Adobe SpeedGrade, see your Adobe SpeedGrade documentation. Defining your playback settings...
Page 140 Your notes Chapter 7, Using Matrox Mojito MAX with Adobe SpeedGrade...
Page 141: Using Matrox Mojito Max With Avid Editing Applications
Using Matrox Mojito MAX with Avid Editing Applications This chapter explains how to define various settings for using Matrox Mojito MAX with Avid editing applications. This includes your playback and capture settings.
Page 142: Creating A New Project On Matrox Mojito Max
Creating a new project on Matrox Mojito MAX You can create a new project for editing on Matrox Mojito MAX as explained in your Avid documentation, with the following exceptions: • Avid supports only standard raster dimensions for projects created on Matrox Mojito MAX hardware.
Page 143 Use this to select the video format you want for your outputs. Be aware that the format you select may not be supported on all the Mojito MAX outputs. For a list of the supported video output formats, see “Playback using Avid editing applications”...
Page 144 Applies the standard NTSC setup level of 7.5 IRE. • YUV/RGB Select YUV or RGB - native to set the type of video signal that is sent from the component output. For example, select RGB - native Chapter 8, Using Matrox Mojito MAX with Avid Editing Applications...
Page 145 RGB - calibrated Outputs adjusted RGB HDMI video using the • currently loaded Matrox HDMI calibration settings for your HDMI monitor or television. For details on calibrating your HDMI monitor and loading calibration settings using the Matrox HDMI Calibration Utility, see Chapter 4, “Calibrating Your HDMI Monitor for...
Page 146: Specifying Your Genlock Settings
You can select the source to which you want to genlock all devices connected to your Mojito MAX system, as well as adjust the timing settings for all video outputs from Mojito MAX. For an example of connecting an external sync source to your system, see “Typical Matrox Mojito MAX connections”...
Page 147 Mojito MAX locks to the new genlock source. If Mojito MAX is unable to lock to your genlock source, it will • automatically lock to the internal reference. However, if Mojito MAX is unable to do this, you’ll need to manually set the genlock to Internal...
Page 148: Specifying Your Audio Output Settings
Mix Mode Selection button to select Direct or Direct, surround tracks in SMPTE order , depending on the version of your Avid editing application. You can then select an output channel on Mojito MAX for each audio track in your sequence. Remarks For surround sound HDMI audio output, Matrox Mojito MAX supports the 5.1 and 7.1 SMPTE settings only (and the Direct SMPTE setting, if...
Page 149 Select Use system sound card if you want to use your system’s sound card to output audio played back from your sequence. Make sure this option is cleared if you want audio to be output from your Mojito MAX system (this ensures accurate A/V sync during playback).
Page 150: Defining Your Capture Settings
To capture video and audio on Matrox Mojito MAX, make sure that your video input and audio input sources in the Capture tool are set to Matrox . For details on how to capture material using your Avid editing application, see your Avid documentation.
Page 151 In the Capture tool, click the Hardware Setup button ( ¡ Important In order to perform a capture, make sure that Audio Punch-in mode is not selected. This mode is used only for recording a voice-over as explained in “Adding a voice-over to your sequence” on page 132.
Page 152 HDMI source, select HDMI (embedded audio) . Your audio input source may be set for you based on your selected video input source. Chapter 8, Using Matrox Mojito MAX with Avid Editing Applications...
Page 153 Click OK to save your settings. Remarks • To capture video on Matrox Mojito MAX, your project’s color space must be set to YCbCr. • Matrox Mojito MAX supports the Audio tool so that you can monitor and adjust your audio input levels for capture.
Page 154: Adding A Voice-Over To Your Sequence
Adding a voice-over to your sequence Matrox Mojito MAX supports the Audio Punch-In tool, which allows you to record audio directly into the Timeline to add voice-over narration, such as to add commentary to newsreels and documentaries. ¦ Note The Audio Punch-In tool supports recording to mono tracks only.
Page 155: Recording Your Voice-Over
From the Input Source list, select the audio source type corresponding to the device to which the microphone is connected. The audio input channels are set to Channel 1-2 . Click OK to save your settings, and then click OK to close the Matrox Capture Settings dialog box.
Page 156 Audio tool button Make sure that the Input Source is set to Matrox . Select the input channels that you want to record ( CH1 and/or CH2 ), and select the corresponding tracks on which you want to record. If you select an existing track, you can replace all or part of the audio on the track with your voice-over.
Page 157: Exporting Your Sequence To Tape
262. To export to tape without device control, simply play back your sequence and record the output from any of the available outputs on your Mojito MAX system. If your recorder supports RS-422 device control, you can connect the RS-422...
Page 158: Requirements For Using Rs-422 Device Control
RS-422 device for export to tape and you don’t have an external broadcast-quality analog sync source, you can set your genlock source to the Mojito MAX internal reference and configure the setting on your deck to genlock to the SDI video input. For details on how to set your genlock source, see “Specifying your genlock settings”...
Page 159: Using Matrox A/V Tools
Using Matrox A/V Tools This chapter explains how to use Matrox A/V Tools to capture clips, grab single-frame images, and play back clips in a clip list.
Page 160: About Matrox A/V Tools
About Matrox A/V Tools Matrox A/V Tools is an application that allows you to capture and play back clips. With A/V Tools, you can: • Capture analog, SDI, or HDMI video from your camera or VTR into .avi files on your computer.
Page 161: Using The Matrox A/V Tools Interface
Using the Matrox A/V Tools interface Once you’ve specified your A/V Tools options, a dialog box similar to the following appears: Here’s a brief description of the A/V Tools dialog box: New tab Use this tab to capture new clips to add to your clip list. See “Capturing clips”...
Page 162: Using The A/V Tools Pop-Up Menu
A/V Tools, your clips are automatically added to the clip list. The clip list can be docked to the Matrox A/V Tools dialog box or float freely as a resizable window. For more information on using the clip list, see “Working...
Page 163 • Play a clip on disk repeatedly Click the Loop button, then click the Play button. Keyboard Shortcuts Disk mode Play Rewind Fast Forward Frame Advance (apostrophe) ’ Frame Reverse (semicolon) Stop Loop Using the Matrox A/V Tools interface...
Page 164: Defining Your A/V Tools Options
The Options dialog box automatically pops up every time A/V Tools starts. Under Capture Folder , specify the folder where you want to store your captured clips. For more information, see “Selecting your capture folder” page 144. Chapter 9, Using Matrox A/V Tools...
Page 165 For information about the supported capture formats, Appendix B, “Matrox Mojito MAX Supported Input and Capture Formats.” Click OK to save your settings.
Page 166: Selecting Your Capture Folder
A/V Tools will save your video and audio clips in a subfolder with the same name as the Tape ID . For example, if you selected D:\Matrox AV Tools Capture as your capture folder, all video and audio clips from tape “MyTape” will be saved in D:\Matrox AV Tools Capture\MyTape.
Page 167 ¦ Note To return a slider to it’s default setting, click its D button. This button is available for all sliders in the Matrox dialog boxes. Click OK to save your settings. Defining your A/V Tools options...
Page 168 Specifying your video output settings You can specify various settings to configure the main and secondary outputs from Mojito MAX. Some of the settings are predetermined for you based on your editing video format. For a list of the supported video output formats, see “Playback using Matrox A/V Tools and Matrox WYSIWYG”...
Page 169 Use this to select the video format you want for your outputs. Format Be aware that the format you select may not be supported on all the Mojito MAX outputs. For a list of the supported formats, see “Playback using Matrox A/V Tools and Matrox WYSIWYG”...
Page 170 RGB - calibrated Outputs adjusted RGB HDMI video using the • currently loaded Matrox HDMI calibration settings for your HDMI monitor or television. For details on calibrating your HDMI monitor and loading calibration settings using the Matrox HDMI Calibration Utility, see Chapter 4, “Calibrating Your HDMI Monitor for...
Page 171 Under SDI Output , specify whether you want the format for your SDI output to be the same as the main or secondary output. Under Advanced , you can specify advanced video output settings. Use this slider to advance or delay your analog Analog SC/H Phase video output’s subcarrier phase with respect to the horizontal sync of the genlock source (for composite video only).
Page 172 Mojito MAX. ¦ Note The status of your genlock source will be displayed, such as Locked or Not Locked , to indicate whether or not Mojito MAX is presently locked Chapter 9, Using Matrox A/V Tools...
Page 173 When you change the genlock source, distorted video and silent audio will be output until Mojito MAX locks to the new genlock source. Under Genlock Video Format , select your genlock source’s video format. If you can’t select a video format, make sure that your genlock source matches the specified video format.
Page 174 Specifying your audio output settings The audio output page lets you adjust various settings for your audio output from your Mojito MAX system. For example, you can adjust the volume of your analog audio output before or while playing back clips.
Page 175: Defining Your Capture Settings
Defining your capture settings The Matrox Capture Settings dialog box has pages that you can use to specify your settings for capturing video and audio in A/V Tools. The settings available are based on your editing video format and your input source (video is always captured to your selected editing video format).
Page 176 The formats available depend on your selected input source. For information about the supported capture formats, Appendix B, “Matrox Mojito MAX Supported Input and Capture Formats.” From the Input Aspect Ratio list, select the aspect ratio of your SD source video (4:3 or 16:9).
Page 177 If you’re capturing to a Matrox MPEG-2 I-frame format, click the button to configure your settings. The MPEG-2 I-frame settings Configure for capture in Matrox A/V Tools are the same as when you capture using Adobe Premiere Pro. For more details, see “Selecting your MPEG-2 I-frame settings”...
Page 178 ¦ Note For any change to the input type to take effect, you must restart Matrox A/V Tools. If your editing video format is 1080p @ 23.98 fps, 25 fps, or 29.97 fps, from the Output Format list, select the format (p or PsF) that you want for previewing your captured video.
Page 179 Adobe Premiere Pro. ° To specify your settings for capturing audio in A/V Tools: Click the Options button in the Matrox A/V Tools dialog box. Click the Capture Settings button. This displays the Matrox Capture dialog box.
Page 180 MyFile.Stereo2.wav, etc. ¦ Note The channels that you choose to save to the first stereo.wav file or first two mono.wav files will be embedded in the associated .avi file. Click OK to save your settings. Chapter 9, Using Matrox A/V Tools...
Page 181 Monitoring audio levels for capture If you select Show VU meters on the Audio Capture Settings page, each time you configure your capture settings or start a capture in A/V Tools, VU meters will be displayed to let you monitor the levels of your currently selected audio input source.
Page 182 Specifying your genlock settings for capture You can select the source to which you want to genlock all devices connected to your Mojito MAX system during capture, as well as adjust the timing settings for all video outputs from Mojito MAX.
Page 183: How A/V Tools Assigns Clip Names
How A/V Tools assigns clip names When using the New tab, Clip ID displays the base name for your new clips. For example, if the Clip ID is “MyClip,” A/V Tools will assign the name MyClip000.avi to the first new clip you capture, and continue naming clips sequentially (for example, MyClip001.avi, MyClip002.avi, etc.).
Page 184: Capturing From Tape Without Device Control
Editing clips Matrox A/V Tools lets you update the clip ID and comment information for clips in your clip list, as well as change a clip’s In and Out icons. Updating clip information To update the clip ID and comment information for a clip, select the clip in the clip list and click the Edit tab.
Page 185: Working With The Clip List
Working with the clip list The following sections explain how to add new clips to the clip list, play back clips, save and load clip lists, copy, move and delete clips, and how to detach and resize the clip list. Adding clips You can add a clip or a series of clips (.avi files) to the clip list using any of the following methods:...
Page 186: Copying Clips
Remarks The first time you double-click a .dvl file in Windows Explorer, you will need to specify Matrox A/V Tools as the program you want to use to open .dvl files. If you load a .dvl file to a clip list that already contains clips, it will replace the current clip list.
Page 187: Detaching And Resizing The Clip List
Detaching and resizing the clip list You can change the size of your clip list to suit your needs. First, detach the clip list from the Matrox A/V Tools dialog box by clicking the Float/dock clip list button ( ) above the clip list. Now the clip list can be freely moved and resized.
Page 188 Click Save or Save As to save the image. Click the Close button to return to the Matrox A/V Tools dialog box. ¦ Note If you do not specify a file name in the Save As text box, or if you select...
Page 189: Keyboard Shortcuts
Keyboard shortcuts The following table provides a complete list of keyboard shortcuts available for using A/V Tools. Keyboard Shortcuts Disk mode CAM mode Play Rewind Fast Forward (apostrophe) Frame Advance ’ Frame Reverse (semicolon) Stop Loop Delete Clip Only DELETE Delete Clip + File SHIFT+DELETE Grab...
Page 190 Your notes Chapter 9, Using Matrox A/V Tools...
Page 191: Using The Matrox Wysiwyg Plug-Ins
Using the Matrox WYSIWYG Plug-ins This chapter explains how to use the Matrox WYSIWYG plug-ins available with Matrox Mojito MAX so that you can display the contents of your composition or animation on your video monitor.
Page 192: Overview
Windows taskbar. If you don’t see the icon, check your taskbar properties and make sure that you’re showing the icons for your Matrox applications. If you still don’t see the icon, choose Start > All Programs > Matrox Mtx.utils > Matrox WYSIWYG Control Panel...
Page 193: Required Steps To Use The Wysiwyg Plug-Ins
HD clips in an SD project, your output will be centered on your video monitor. Required steps to use the WYSIWYG plug-ins The following sections list the steps required to use the Matrox WYSIWYG plug-in for each application in order to preview video on your video monitor. ¦ Note The following procedures may change with a subsequent release of the program.
Page 194: Autodesk Combustion
, and click OK . eyeon Fusion Start eyeon Fusion and open the file you want to preview. Right-click on the file, and choose View On > Matrox WYSIWYG Preview NewTek LightWave 3D Start NewTek LightWave 3D and load the file you want to preview by choosing File >...
Page 195: Using Mojito Max With Adobe And Microsoft Live Media Encoders
Using Mojito MAX with Adobe and Microsoft Live Media Encoders This chapter explains how to use your Matrox Mojito MAX system as an input device to feed live video and audio to Adobe Flash Media Live Encoder or Microsoft Expression Encoder.
Page 196: Overview
Overview You can use your Matrox Mojito MAX system as an input device to feed live video and audio to Adobe Flash Media Live Encoder orMicrosoft Expression Encoder. This lets you stream media for broadcasting live events such as sports, concerts, news, educational seminars, and corporate meetings.
Page 197 From the Video Input Format list, select the video format that matches your source video. For a list of the video input formats supported on the various Mojito MAX inputs, see “Supported input formats” on page 248. From the Video Input Source list, select the type of video input you want to stream.
Page 198 For details on how to specify additional encoding settings and stream your live video and audio, refer to the documentation for your streaming media encoding application. Chapter 11, Using Mojito MAX with Adobe and Microsoft Live Media Encoders...
Page 199: Using Matrox Mojito Max With Livestream Procaster
Using Matrox Mojito MAX with Livestream Procaster This chapter explains how to use your Matrox Mojito MAX system as an input device to feed live video and audio to Livestream Procaster.
Page 200: Overview
Overview You can use your Matrox Mojito MAX system as an input device to feed live video and audio toLivestream Procaster. This lets you stream media for broadcasting live events such as sports, concerts, news, educational seminars, and corporate meetings. For example, you can select any video and audio source connected to the Mojito MAX inputs as your A/V sources for use with Procaster, and stream the live video and audio to your Livestream channel.
Page 201 Mojito MAX hardware. Start Livestream Procaster, enter your username and password, then click LOGIN Below the GO LIVE button, your Matrox hardware will automatically be selected as your video input source. Specifying your settings for media streaming...
Page 202 If you don’t see your source video, check that your Matrox Mojito MAX hardware and selected video source are properly connected. For a list of the video input formats supported on the various Mojito MAX inputs, see “Supported input formats”...
Page 203: Using Matrox Mojito Max With Telestream Wirecast
Using Matrox Mojito MAX with Telestream Wirecast This chapter explains how to stream and record your video and audio input feeds using Matrox Mojito MAX in Telestream Wirecast.
Page 204: Overview
Overview You can use Matrox Mojito MAX or any combination of Matrox I/O devices (Mojito MAX and MXO2 products) to feed live video and audio to Telestream Wirecast for streaming, and simultaneously record your original feeds to disk. The easy-to-use Matrox ISO recording tool lets you create high-quality ISO recordings of your feeds, ready for post-event editing in your favorite editing application.
Page 205 To configure your source settings, choose Sources > Show Sources Settings In the Source Settings dialog box, under MATROX INPUT DEVICES , select the Matrox device that you want to configure, and then specify the following settings: From the Video Format list, select the video format that matches your source video.
Page 206 LCD or computer monitor. Click Output Settings to specify the settings that you want for monitoring your source video and audio on your Matrox hardware as explained in “Specifying your output settings” on page 196.
Page 207: Specifying Your Settings For Matrox Iso Recording
You can choose to record your input sources to disk using various Matrox codecs. You can use the Matrox MPEG-2 I-frame codec to create .avi files, a Matrox DV codec, such as DVCPRO or DVCPRO HD, to create .mov files, and the Matrox MAX H.264 codec on Matrox I/O devices that have MAX technology to create...
Page 208 Settings In the Source Settings dialog box, under MATROX INPUT DEVICES , select the Matrox device that you want to configure, and then specify your source settings for recording as follows: From the Video Format list, select the video format that matches your source video.
Page 209 When recording HDMI embedded audio, only uncompressed embedded audio is supported. Click Output Settings to specify the settings that you want for monitoring your source video and audio on your Matrox hardware as explained in “Specifying your output settings” on page 196.
Page 210: Specifying Settings In The Matrox Iso Recording Tool
“Input states and video formats” on page 195.” Preset selection If you’d like to load a preset to apply Matrox ISO record settings to an input, click beside the input, choose Load Preset , and select the preset that you want in the displayed dialog box.
Page 211 Under Codec Settings , specify the settings that you want for each Matrox input as follows: • If the Video File Type is set to Matrox AVI , use the provided slider to select the data rate (in Mb/sec) at which the Matrox MPEG-2 I-frame codec will record your source video to disk.
Page 212 Therefore, audio will not be embedded in the video file, and separate audio files will not be created. When 2 , 4 , 6 , or 8 is selected, the Matrox ISO recording tool embeds the first audio pair (channel 1-2) from your audio source in the video file.
Page 213 Only presets that are compatible with your input’s video format will be listed, and a Matrox preset will be listed only if your input is for a device that has Matrox MAX technology.
Page 214: Matrox Iso Recording File Naming Conventions
For example, if the base name for input 1 is Record and the Video File Type is set to Matrox AVI , the resulting file will be named Record_1_0.avi. You can also have more than one recording for a Matrox input. In this case, the files are differentiated by a recording number. This occurs when: You clear and then re-select an input during a recording session.
Page 215: Record Functionality
Record_1_0_Mono1.wav, Record_1_0_Mono2.wav, Record_1_0_Mono3.wav, and so on. Record functionality This section describes the Matrox ISO recording functionality regarding the recording session, record time code, and input recording. Recording session A recording session begins when you click , and ends when you click You must have a valid input signal in order for your selected input to be recorded.
Page 216: Record Status
24-bit 3 hours Record status The Matrox ISO Record dialog box includes a record status indicator. If the indicator remains green throughout the entire recording session, all recordings completed without any dropped or skipped frames. If dropped or skipped frames occur during a recording, the indicator turns red for the duration of the recording.
Page 217: Input States And Video Formats
• Valid input signal When a signal that matches the video format selected for your Matrox device is connected to the input, such as 1080i @ 29.97 fps, the video format is displayed under the input label. If the input is selected for recording, the resulting video file will be in the displayed video format.
Page 218: Record Log File
¦ Note In order to monitor the audio channels that you’re streaming, you must connect your speakers to the output of your sound card (not your Matrox hardware), and make sure that your sound card is set as your default sound playback device in the Windows Control Panel.
Page 219 Select this when you want to disable the currently loaded Matrox HDMI calibration settings and output RGB HDMI video from Mojito MAX using its native color settings for previewing video on your HDMI monitor. Under SDI Audio Output Format , select the bit depth you want for your embedded SDI audio output ( 20-bit or 24-bit ).
Page 220 Your notes Chapter 13, Using Matrox Mojito MAX with Telestream Wirecast...
Page 221: Using The Matrox Video For Windows Codecs
Using the Matrox Video for Windows Codecs This chapter explains how to use the Matrox Video for Windows codecs to render material to Matrox .avi files.
Page 222: Overview
When using Video for Windows (VFW) programs to render material to an .avi file, you can use a Matrox VFW codec to create a Matrox .avi file. For example, you may want to render an animation to a Matrox MPEG-2 I-frame .avi file for use in your Adobe Premiere Pro projects on Matrox Mojito MAX.
Page 223: Before You Start Rendering
Before you start rendering Before you start rendering material to a Matrox .avi file, make the following settings in your VFW program: • Set the frame size (width and height) of your rendered material to full-screen, depending on the codec that you’ll be using.
Page 224: Selecting Color Space Conversion Options
Selecting color space conversion options When you render material to an .avi file using a Matrox VFW codec, you can determine how you want the luminance levels and chroma information to be processed during the color space conversion that’s performed during the render.
Page 225: Rendering Material To A Matrox Vfw .Avi File
Refer to your program’s documentation for instructions on how to select a compressor for your .avi file. If you want to export material from Adobe Premiere Pro to a Matrox .avi file, it’s recommended that you use the Matrox AVI export format as explained in “Exporting to a Matrox .avi file”...
Page 226: Configuring The Matrox Dvcpro Hd Codec
HD format with alpha. ¦ Note The Matrox Offline HD codec is not supported for rendering clips. This codec is provided only for playback of legacy Matrox Axio offline HD projects. If you’ve selected a Matrox codec that requires configuration, click the button provided by your program that allows you to configure your codec settings.
Page 227: Configuring The Matrox Mpeg-2 I-Frame Codecs
Configuring the Matrox MPEG-2 I-frame codecs When you choose to configure a Matrox MPEG-2 I-frame codec (SD or HD resolution), a dialog box similar to the following appears: Drag the Data Rate slider until your desired data rate is displayed. The higher the data rate you select, the better the video quality will be.
Page 228 In some cases, graphics will yield less artifacts if this option is selected. Click to save your settings. The settings you selected will be used each time you render material with your program, until you change the settings again. Chapter 14, Using the Matrox Video for Windows Codecs...
Page 229: Using The Matrox Max H.264 Codec With Adobe Software
Using the Matrox MAX H.264 Codec with Adobe Software This chapter explains how to use the Matrox MAX H.264 codec on your Matrox Mojito MAX card to export material to Blu-ray Disc and other media formats from Adobe Media Encoder, Premiere Pro, and...
Page 230: Exporting To Matrox Max H.264 Files Using Adobe Media Encoder
Exporting to Matrox MAX H.264 files using Adobe Media Encoder You can use the Matrox MAX H.264 codec on your Mojito MAX card to quickly and easily export material to H.264 files for Blu-ray Disk and other media formats from Adobe Media Encoder. Matrox presets are provided for creating .264 elementary stream files in HD formats that are supported for Blu-ray Disc...
Page 231 ¦ Note If you’re exporting to a Matrox .mp4 file, two types of presets will be available—Fast Encode and High Quality. Select a Fast Encode preset for fast encoding that leverages your system’s resources with your Matrox hardware.
Page 232 Matrox .264 file, the available frame sizes are 1920 x 1080 and 1280 x 720 . When exporting to a Matrox .mp4 file, you can select a Chapter 15, Using the Matrox MAX H.264 Codec with Adobe Software...
Page 233 Select this option if you’re Use Matrox MAX hardware scaler scaling your source video for export, and you want to use the Matrox MAX hardware scaler to perform the scaling. This gives good performance when scaling to an HD resolution. If you’re downscaling to an SD or lower resolution, you can get a faster export by clearing this option, which allows Adobe to perform the scaling.
Page 234 ¦ Note When exporting audio from an Adobe Premiere Pro sequence to a Matrox .264 file, the available output channels depend on the type of audio tracks being exported. For example, you can select Surround 5.1 to export 5.1 surround tracks to six mono .wav files. For a 16-channel track, you can select Mono or Stereo to export the audio to a single mono or stereo .wav file.
Page 235: Performing A Direct Export Of An Adobe Premiere Pro Sequence
Encoder, additional processing is required to transfer the sequence from Premiere Pro to Media Encoder. If you want to export only a single sequence to a Matrox MAX H.264 file (.264 or .mp4 file), you may find it more convenient and get faster results by performing a direct export as explained in this section.
Page 236 If your sequence includes closed caption text and you’d like the closed captioning to be embedded in your exported Matrox .mp4 file, under Video , select Embed closed captioning in file : Remarks Only CEA-608 closed captioning data in your sequence can be embedded in your exported Matrox .mp4 file.
Page 237: Transcoding For Blu-Ray Disc Authoring In Adobe Encore
Transcoding for Blu-ray Disc authoring in Adobe Encore Instead of exporting material to a Matrox .264 file from Adobe Media Encoder or Premiere Pro and then importing the file into Adobe Encore for Blu-ray Disc authoring, you can choose to perform the transcoding of clips directly within Encore.
Page 238 ¥ Tip You can check the Estimated File Size at the bottom of the dialog box to determine the approximate file size of your transcoded material based on your currently selected settings. If needed, you can change your Matrox MAX H.264 settings to better meet your file size requirements, such as by selecting a different encoding type and lower data rate.
Page 239 Use Matrox MAX hardware scaler for transcoding to HD for Blu-ray Disc, it’s recommended that you select this option to use the Matrox MAX hardware scaler to perform the scaling. Click the Audio tab to display the settings for your transcoded audio.
Page 240: Specifying Your Matrox Max H.264 Settings
Specifying your Matrox MAX H.264 settings When creating Matrox MAX H.264 files (Matrox .264 or .mp4 files), appropriate codec settings are applied based on the Matrox preset you selected. If needed, you can customize the settings that you want for the H.264 compression.
Page 241 59.94 Remarks Use H.264 level 4.0 if you want to create Matrox MAX H.264 files intended for mass replication of Blu-ray Discs. You can use either level 4.0 or 4.1 if you want to author and burn individual copies that are compatible with Blu-ray Disc players.
Page 242 ¦ Note When customizing the settings for a Matrox .264 file, be aware that Matrox .264 files that have a data rate higher than about 30 Mb/sec may require transcoding in Adobe Encore. The maximum H.264 level and data rate accepted by Adobe Encore for Blu-ray Disc authoring with audio and video is level 4.1 at 35 Mb/sec.
Page 243 (must be a multiple of the distance between P frames). When creating a Matrox .264 file for Blu-ray, the GOP size must be less than one second of video. For example, if the frame rate for your encoded video is 29.97 fps, the GOP size must be 29 frames or less.
Page 244 Your notes Chapter 15, Using the Matrox MAX H.264 Codec with Adobe Software...
Page 245: Using Matrox Max H.264 Capture
Using Matrox MAX H.264 Capture This chapter explains how to use the Matrox MAX H.264 Capture application to capture clips to various formats on Matrox Mojito MAX.
Page 246: Overview
Mojito MAX hardware becomes available. • If you want to run Adobe Encore at the same time as the Matrox MAX H.264 Capture application, you must set your video and audio output devices in Encore to Adobe devices only.
Page 247: How To Capture Clips
“Specifying your output settings” on page 228. Select a preset for the type of clips that you want to capture. The Matrox presets available depend on the frame rate of your video input source. Click the Advanced button to review the settings provided by your selected preset and make any required changes as explained in “Specifying your...
Page 248: Specifying Your Input Settings
Settings From the Video Input Format list, select the video format that matches your source video. For a list of the video input formats supported on the various Mojito MAX inputs for capturing clips, see “Supported input formats” on page 248.
Page 249 Preview Window of the Matrox MAX H.264 Capture dialog box. ¦ Note If your source video is HD and you choose to capture to a Matrox .avi file, video in the Preview Window will be scaled to quarter-size, and the frame rate of video played back in the Preview Window may also be reduced.
Page 250: Specifying Your Output Settings
DV video on your NTSC monitor, you can change the setup to 0 IRE to output the video at the correct brightness. 7.5 IRE Applies the standard NTSC setup level of 7.5 IRE. • Chapter 16, Using Matrox MAX H.264 Capture...
Page 251 Select this when you want to disable the currently loaded Matrox HDMI calibration settings and output RGB HDMI video from Mojito MAX using its native color settings for previewing video on your HDMI monitor. Under SDI Audio Output Format , select the bit depth you want for your embedded SDI audio output ( 20-bit or 24-bit ).
Page 252: Specifying Your Capture Format Settings
For a list of the supported capture formats based on your selected video input format, see “Supported capture formats for Matrox MAX H.264 Capture” on page 252. Select one of the following Matrox formats: File Type Matrox 264 (Blu-ray) Creates a .264 elementary stream file, which •...
Page 253 Codec Type If you’re capturing to a Matrox .264 or .mp4 file, the codec will be set to Matrox MAX H.264 . If you’re capturing to a Matrox .avi file, select the codec that you want to use for the capture:...
Page 254 Select this if you’re capturing to a Matrox .mp4 file, and you’d like to simultaneously capture to a Matrox MPEG-2 I-frame .avi file in the same format as your source video. For example, if your source video is 1080i @ 29.97 fps, your Matrox .avi file will also be 1080i @ 29.97 fps.
Page 255 Matrox MPEG-2 I-frame .avi file, stereo audio will be embedded in the .mp4 and .avi files. When capturing to a Matrox .avi file only, audio is always captured to separate .wav files, and the channels that you choose to save to the first stereo .wav file or first two mono .wav files will be embedded in the...
Page 256: Starting Your Capture
Browse to select the location that you want. A default filename will be provided as the base name for your captured clips. You can change this name if you want. When capturing to Matrox .mp4 files using the automatic file switching feature, your clips will be numbered...
Page 257 If you’re capturing to Matrox .mp4 files without .wav or .avi files, you can select the automatic file switching options that you want, such as to switch to the next clip after a specified time limit.
Page 258 Your notes Chapter 16, Using Matrox MAX H.264 Capture...
Page 259: Monitoring Your Matrox Mojito Max System
Monitoring Your Matrox Mojito MAX System This chapter explains how to use the Matrox X.info program to display important details about your Matrox Mojito MAX system and installed hardware.
Page 260: Using X.info To Display Mojito Max Information
X.info to select your primary Matrox I/O device. Matrox X.info runs continuously to monitor your system, whenever your computer is turned on and a Mojito MAX card is installed. You can open Matrox X.info to display system and hardware details by double-clicking the icon on your Windows taskbar.
Page 261 Create is created. If you had previously turned off certain Matrox warnings and want them to be re-enabled, click Re-enable Warnings . For example, some Matrox warnings provide an option to turn off the warning (that is, you can select Don’t display ).
Page 262: Displaying Hardware Information
Mojito MAX hardware. If you have multiple Matrox Mojito MAX cards, a separate tab will be provided to display the hardware information for each card. ¡ Important Whether or not you have opened Matrox X.info, if your Mojito MAX exceeds the maximum operating temperature, you’ll receive a warning...
Page 263: Monitoring Your Mojito Max's Operating Temperatures
As shown in the X.info Hardware section, the Mojito page displays the current and maximum operating temperatures for your Matrox Mojito MAX hardware. To avoid damage to your Matrox Mojito MAX, make sure that you don’t operate your Mojito MAX at or near the maximum temperature for a prolonged period of time.
Page 264 Your notes Chapter 17, Monitoring Your Matrox Mojito MAX System...
Page 265: Understanding Pulldown
Understanding Pulldown This appendix describes the available Mojito MAX pulldown methods.
Page 266: Overview
Depending on your editing video format, a pulldown may be required to convert 23.98 fps video to 29.97 fps video for output on Matrox Mojito MAX. When a pulldown is required for your video output, Matrox Mojito MAX performs either a standard 2:3 pulldown or an advanced 2:3:3:2 pulldown.
Page 267: Advanced 2:3:3:2 Pulldown
Advanced 2:3:3:2 pulldown Advanced 2:3:3:2 pulldown was developed as an alternative to the standard pulldown method for making frame rate conversions in DV video. It is used to convert 486p @ 23.98 fps video to NTSC (486i @ 29.97 fps) video. This conversion is used when video footage is acquired by a DV camera at 23.98 fps and recorded to DV tape with the recorder set for advanced pulldown (called 24PA or 24P Advanced mode on some devices).
Page 268 Your notes Appendix A, Understanding Pulldown...
Page 269: Matrox Mojito Max Supported Input And Capture Formats
Matrox Mojito MAX Supported Input and Capture Formats This appendix provides information on the video input and capture formats that are supported on Mojito MAX.
Page 270: Supported Input Formats
Supported input formats The following table shows the video input formats that are supported on the Mojito MAX video inputs for capturing or recording video. For descriptions of the Mojito MAX inputs, see “Mojito MAX input and output descriptions” page 18.
Page 271: Supported Capture Formats For Adobe Premiere Pro
The following table lists the supported capture formats when using Adobe Premiere Pro to capture clips to Matrox .avi and .m2v files, based on your selected video input format. For a list of the video input formats supported on the various Mojito MAX inputs for capturing clips, see “Supported input formats”...
Page 272: Supported Capture Formats For Avid Editing Applications
Supported capture formats for Avid editing applications The following table lists the supported capture formats on Matrox Mojito MAX, based on your project’s video format and selected input source in Avid editing applications. Matrox Mojito MAX input Project video format...
Page 273: Supported Capture Formats For Matrox A/V Tools
Supported capture formats for Matrox A/V Tools The following table lists the supported capture formats on Matrox Mojito MAX, based on your editing video format and selected input source in Matrox A/V Tools. Matrox Mojito MAX input Editing video format...
Page 274: Supported Capture Formats For Matrox Max H.264 Capture
— 1080p @ 30 fps Any_p @ 30 fps Any_ represents a custom frame size that you can enter for your Matrox .mp4 file as explained in “Specifying your capture format settings” on page 230. Appendix B, Matrox Mojito MAX Supported Input and Capture Formats...
Page 275: Matrox Mojito Max Supported Output Formats
Matrox Mojito MAX Supported Output Formats This appendix provides information on the video output formats that are supported on Mojito MAX.
Page 276: Supported Video Output Formats For Playback
Supported video output formats for playback This section lists the formats that are supported on the main and secondary Mojito MAX video outputs during playback, depending on the application used. For descriptions of the Mojito MAX outputs, see “Mojito MAX input and output descriptions”...
Page 277 Matrox Mojito MAX output Sequence video Main output Secondary output format NTSC NTSC, 480p @ 59.94 fps , 720p @ 59.94 fps, or 1080i/p /PsF @ 29.97 fps 480p @ 59.94 fps 720p @ 59.94 fps NTSC, 480p @ 59.94 fps , or 720p @ 59.94 fps...
Page 278 PAL or 1080i @ 25 fps 1080i @ 25 fps 720p @ 50 fps 720p @ 50 fps or 1080i @ 25 fps 1080i @ 25 fps PAL, 720p @ 50 fps, or 1080i @ 25 fps Appendix C, Matrox Mojito MAX Supported Output Formats...
Page 279 Matrox Mojito MAX output Sequence video Main output Secondary output format NTSC NTSC or 1080i @ 29.97 fps 1080i @ 29.97 fps 720p @ 59.94 fps 720p @ 59.94 fps or 1080i @ 29.97 fps 1080i @ 29.97 fps NTSC, 720p @ 59.94 fps, or 1080i @ 29.97 fps NTSC NTSC, 480p @ 59.94 fps...
Page 280 1080PsF @ 24 fps is supported on the SDI output only. For the best results, you should select a video output format with a frame rate that matches or is compatible with your sequence’s frame rate. Appendix C, Matrox Mojito MAX Supported Output Formats...
Page 281: Playback Using Adobe Speedgrade
Playback using Adobe SpeedGrade The following table shows the formats that are supported on the main and secondary Mojito MAX video outputs during playback using Adobe SpeedGrade, based on your selected display format. Matrox Mojito MAX output Display format Main output...
Page 282 NTSC, 720p @ 59.94 fps, or 1080i @ 29.97 fps 1080PsF @ 23.98 fps NTSC, 480p @ 59.94 fps , 720p @ 59.94 fps, 1080i @ 29.97 fps, or 1080p /PsF @ 23.98 fps 1080p @ 23.98 fps Appendix C, Matrox Mojito MAX Supported Output Formats...
Page 283 Matrox Mojito MAX output Display format Main output Secondary output 1080PsF @24 fps 1080p /PsF @ 24 fps 1080p @ 24 fps 1080PsF @ 25 fps PAL, 576p @ 50 fps , 720p @ 50 fps, or 1080p /PsF @ 25 fps...
Page 284: Playback Using Avid Editing Applications
Playback using Avid editing applications The following table shows the formats that are supported on the main and secondary Mojito MAX video outputs during playback using Avid editing applications, based on your project’s video format. ¡ Important If the main and secondary output formats don’t match and the video quality for playback is not set to Full Quality, the secondary output will be blanked.
Page 285 Matrox Mojito MAX output Project video format Main output Secondary output NTSC NTSC, 480p @ 59.94 fps , 1080i @ 29.97 fps, or 1080p /PsF @ 23.98 fps 480p @ 59.94 fps 720p @ 59.94 fps 720p @ 59.94 fps, 1080i @ 29.97 fps, or 1080p /PsF@ 23.98 fps...
Page 286: Playback Using Matrox A/V Tools And Matrox Wysiwyg
Playback using Matrox A/V Tools and Matrox WYSIWYG The following table shows the formats that are supported on the main and secondary Mojito MAX video outputs during playback using Matrox A/V Tools and the Matrox WYSIWYG plug-ins, based on your selected editing video format.
Page 287 Matrox Mojito MAX output Editing video format Main output Secondary output NTSC NTSC, 480p @ 59.94 fps , or 720p @ 59.94 fps 480p @ 59.94 fps NTSC, 480p @ 59.94 fps , 720p @ 59.94 fps, 1080i @ 29.97 fps, or 720p @ 59.94 fps...
Page 288 , 720p @ 59.94 fps, 1080i @ 29.97 fps, or 1080PsF @ 23.98 fps 1080p /PsF @ 23.98 fps 1080p @ 23.98 fps 1080PsF @ 24 fps 1080p @ 24 fps 1080p/PsF @ 24 fps 1080p @ 24 fps Appendix C, Matrox Mojito MAX Supported Output Formats...
Page 289 Matrox Mojito MAX output Editing video format Main output Secondary output PAL, 576p @ 50 fps , or 1080p /PsF @ 25 fps 576p @ 50 fps 1080p @ 25 fps 720p @ 50 fps 720p @ 50 fps or 1080p...
Page 290: Supported Video Output Formats For Monitoring
1080p @ 30 fps — — — NTSC and PAL are the only supported capture formats when capturing to a Matrox .m2v file. 1080PsF @ 24 fps is supported on the SDI output only. Appendix C, Matrox Mojito MAX Supported Output Formats...
Page 291: Avid Editing Applications
Avid editing applications The following table shows the formats that are supported on the Mojito MAX video outputs for monitoring your captured video, based on your project’s video format in Avid editing applications. Matrox Mojito MAX output Project video format...
Page 292: Matrox A/V Tools
Matrox A/V Tools The following table shows the formats that are supported on the Mojito MAX video outputs for monitoring your captured video, based on your editing video format in Matrox A/V Tools. Matrox Mojito MAX output Editing video format...
Page 293: Matrox Max H.264 Capture And Telestream Wirecast
Matrox MAX H.264 Capture and Telestream Wirecast The following table shows the formats that are supported on the Mojito MAX video outputs for monitoring the source material that you’re capturing using the Matrox MAX H.264 Capture application, or streaming/recording using Telestream Wirecast, based on your selected video input format.
Page 294 Your notes Appendix C, Matrox Mojito MAX Supported Output Formats...
Page 295: Matrox Mojito Max Specifications
Matrox Mojito MAX Specifications This appendix provides specifications for Matrox Mojito MAX.
Page 296: General
HDMI Y,Cb,Cr 4:2:2 (10-bit) / RGB (8-bit) • Eight channels of embedded audio • Standard Type C HDMI connector (19 pins) • • SDI HDTV input HD-SDI with eight channels of embedded SDI audio • 24-bit, 48 kHz • Appendix D, Matrox Mojito MAX Specifications...
Page 297 Compliant with SMPTE 292M, SMPTE 299M • BNC connector (75  ), terminated • Equalized input for maximum cable length support • HDTV output HD-SDI with 16 channels of embedded SDI audio • 24-bit, 48 kHz • Compliant with SMPTE 292M, SMPTE 299M •...
Page 298 • Frequency response: +/- 0.5 dB max to 5 MHz • 2T pulse response: 1.0% max • Diff. Gain: < 2%, Diff. Phase: < 1 degree • S/N: > 58 dB, unified weighted • Appendix D, Matrox Mojito MAX Specifications...
Page 299: Audio
SDTV analog component video (passthrough) Frequency response Y: +/- 0.5 dB max to 5 MHz • Frequency response Pb, Pr: +/- 1.0 dB max to 2 MHz • Component channel delay: < 8 ns • Component S/N (Y, Pb, Pr): > 54 dB, unified weighted •...
Page 300: Environmental Specifications
• Minimum/maximum storage temperature: –40 to 75º C • Maximum altitude for operation: 3,000 meters • Maximum altitude for transport: 12,000 meters • Operating humidity: 20 to 80% relative humidity (non-condensing) • Storage humidity: 5 to 95% relative humidity (non-condensing) Appendix D, Matrox Mojito MAX Specifications...
Page 301: Matrox Customer Support
Matrox Customer Support This appendix explains how you can register your Matrox product and obtain customer support.
Page 302: How To Get Matrox Customer Support
Matrox product, please contact your Matrox representative. He or she should be able to help you quickly correct any installation or system configuration problem. If your representative is unable to solve your problem, contact Matrox for further information and assistance. Registration You can register your Matrox product in the Matrox Support section of our website at www.matrox.com/video/support.
Page 303: Index
A/V Tools displaying warnings in Events panel See Matrox A/V Tools exporting sequence to Matrox AVI file AAC files exporting sequence to Matrox MAX H.264 file 230, capturing with Matrox MAX H.264 files exporting sequence to tape 185, recording using Matrox ISO recording tool...
Page 304 Adobe Premiere Pro Audio applications 153, capturing using Matrox A/V Tools setting Mojito MAX as default audio playback de- 224, capturing using Matrox MAX H.264 Capture vice Audio capture settings exporting using Adobe Premiere Pro...
Page 305 Compressor Chroma key shadow effect selecting for VFW render creating overview Computer system connecting to your Mojito MAX I/O cable Clip information requirements updating in Matrox A/V Tools Connections Closed captioning available on Matrox Mojito MAX embedding in MP4 file during export...
Page 306 See also Rendering using VFW programs HDMI monitor calibration Exporting to tape calibrating your HDMI monitor using Adobe Premiere Pro enabling and disabling the Matrox HDMI calibra- with Matrox device control tion settings using Avid editing applications loading Matrox HDMI calibration settings...
Page 307 Isolating colors in a clip Matrox 10-bit Uncompressed codec using secondary color correction selecting for capture in A/V Tools selecting for capture in Matrox MAX H.264 Capture Key colors selecting for capture in Premiere Pro modifying using the chroma key graph...
Page 308 Matrox DV/DVCAM codec time code selecting for export in Premiere Pro video file type selection selecting for Matrox ISO recording 185, WAV files selecting for VFW render maximum duration Matrox DVCPRO codec naming convention selecting for export in Premiere Pro Matrox MAX H.264 Capture...
Page 309 VFW render using configuring in Premiere Pro Matrox WYSIWYG plug-ins selecting for capture in A/V Tools about selecting for capture in Matrox MAX H.264 Capture installing re-installing selecting for capture in Premiere Pro removing selecting for export in Premiere Pro...
Page 310 MPEG-2 I-frame HD codec Procaster See Matrox MPEG-2 I-frame HD codec See Livestream Procaster MTX files Pulldown loading Matrox HDMI calibration settings description of advanced saving Matrox HDMI calibration settings description of standard Pulldown method 32, 121, selecting for output...
Page 311 System requirements in Adobe SpeedGrade in Avid editing applications in Matrox A/V Tools and Matrox WYSIWYG Technical support Telestream Wirecast supported on Mojito MAX using Telestream Wire- Matrox ISO recording cast media streaming Video output settings using with Mojito MAX...
Page 312 Adobe Premiere Pro’s Events panel re-enabling using X.info Warranty WAV files capturing using Adobe Premiere Pro capturing using Matrox A/V Tools 230, capturing using Matrox MAX H.264 Capture 231, 209, exporting with Matrox MAX H.264 files 185, recording using Matrox ISO recording tool 190,...
Page 313 (Español) Información para usuarios europeos – Declaración de conformidad Observación referente a los productos de hardware de Matrox apoyados por este manual Estos dispositivos cumplen con la directiva de la CE 2006/95/EC para dispositivos digitales de Clase A. Dichos dispositivos han sido sometidos a prueba y se ha comprobado que cumplen con las normas EN55022/CISPR22 y EN55024/CISPR24.
Page 314 www.matrox.com/video...

Matrox Mojito MAX Installation And User Manual

Chapter 1 Introducing Matrox Mojito MAX

Chapter 2 Installing Your Matrox Mojito MAX Hardware and Software

Chapter 3 Connecting External Devices to Matrox Mojito MAX

Chapter 4 Calibrating Your HDMI Monitor for Video

Chapter 5 Using Matrox Mojito MAX with Adobe Premiere Pro

Chapter 6 Setting up Matrox Effects with Adobe Premiere Pro

Chapter 7 Using Matrox Mojito MAX with Adobe Speedgrade

Chapter 8 Using Matrox Mojito MAX with Avid Editing Applications

Chapter 9 Using Matrox A/V Tools

Chapter 10 Using the Matrox WYSIWYG Plug-Ins

Chapter 11 Using Mojito MAX with Adobe and Microsoft Live Media Encoders

Chapter 12 Using Matrox Mojito MAX with Livestream Procaster

Chapter 13 Using Matrox Mojito MAX with Telestream Wirecast

Chapter 14 Using the Matrox Video for Windows Codecs

Chapter 15 Using the Matrox MAX H.264 Codec with Adobe Software

Chapter 16 Using Matrox MAX H.264 Capture

Chapter 17 Monitoring Your Matrox Mojito MAX System

Appendix A Understanding Pulldown

Appendix B Matrox Mojito MAX Supported Input and Capture Formats

Appendix C Matrox Mojito MAX Supported Output Formats

Appendix D Matrox Mojito MAX Specifications

Appendix E Matrox Customer Support

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrox Mojito MAX

Summary of Contents for Matrox Mojito MAX
