5.5 Basic operation description

5.5.1 What this section describes

This section introduces the function modules inside the VFD.
 Ensure that all terminals have been securely connected.
 Ensure that the motor power matches the VFD power.

5.5.2 Common commissioning procedure

The common commissioning procedure is as follows (taking motor 1 as an example).
Level 2
P08.37
Reserved
P00.00
Speed
control
mode
P01.08
Stop mode
P00.11
ACC time 1
P00.12
DEC time 1
-63-
Basic operation guidelines
Level 3
0: SVC 0
1: SVC 1
2: Space voltage
vector control
mode
0: Decelerate to
stop
1: Coast to stop
Level 4
