INVT Goodrive270 Series Operation Manual page 138

Goodrive270 series VFD for fan and pump
Related parameter list:
Function
code
P09.00 PID reference source
P09.01 PID digital setting
P09.02 PID feedback source
PID output
P09.03 characteristics
P09.04 Proportional gain (Kp) 0.00–100.00
P09.05 Integral time (Ti)
P09.06 Differential time (Td)
P09.07 Sampling cycle (T)
PID control deviation
P09.08
P09.09 PID output upper limit P09.10–100.0% (Max. frequency or voltage)
P09.10 PID output lower limit -100.0%–P09.09 (Max. frequency or voltage)
Feedback offline
P09.11
detection value
Name
0: Set by P09.01
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDIA
5: Multi-step running
6: Modbus communication
7: PROFIBUS/CANopen communication
8: Ethernet communication
9: Reserved
10: PROFINET communication
-100.0%–100.0%
0: AI1
1: AI2
2: AI3
3: High-speed pulse HDIA
4: Modbus communication
5: PROFIBUS/CANopen communication
6: Ethernet communication
7: Reserved
8: PROFINET communication
0: PID output is positive.
1: PID output is negative.
selection
0.01–10.00s
0.00–10.00s
0.000–10.000s
0.0–100.0%
limit
0.0–100.0%
Description
-128-
Basic operation guidelines
Default
0
0.0%
0
0
1.80
0.90s
0.00s
0.100s
0.0%
100.0%
0.0%
0.0%
