Goodrive270 series VFD for fan and pump
Function
Name
code
Feedback upper
P90.17
limit detection value
Feedback lower
P90.18
limit detection value
Feedback
P90.19 out-of-range
detection time
PID1 feedback filter
P90.20
time
PID1 deviation input
P90.21
limit value
Description
reference source 1 and feedback source 1 and
the difference between reference source 2 and
feedback source 2, give priority to the condition
in which the feedback is greater than the
reference.
If there are some feedback values that are
greater than the reference values, select the
group with the max. negative difference as the
PID reference and feedback. If all feedback
values are less than the reference values, select
the group with the min. positive difference as the
PID reference and feedback.
7: Max. positive difference or min. negative
difference among multiple reference values
When calculating the difference between
reference source 1 and feedback source 1 and
the difference between reference source 2 and
feedback source 2, give priority to the condition
in which the feedback is less than the reference.
If there are some feedback values that are less
than the reference values, select the group with
the max. positive difference as the PID
reference and feedback. If all feedback values
are greater than the reference values, select the
group with the min. negative difference as the
PID reference and feedback.
0–100.0%
0–100.0%
0.0–3600.0s
0.000–60.000s
0.0–100.0%
-251-
Function parameter list
Default Modify
○
100.0%
○
0.0%
○
1.0s
○
0.000s
○
100.0%
