Goodrive270 series VFD for fan and pump
Function
Name
code
reference
Torque current
P17.34
reference
AC incoming
P17.35
current
P17.36 Actual output torque
Motor overload
P17.37
count value
P17.38 Process PID output -100.0%–100.0%
Function codes in
P17.39 parameter
download error
P17.40 Motor control mode
Electromotive
P17.41
torque upper limit
Description
under the vector control mode.
Range: -3000.0–3000.0A
Displays the torque current reference value
under the vector control mode.
Range: -3000.0–3000.0A
Displays the valid value of incoming current on
AC side.
Range: 0.0–5000.0A
Displays the actual output torque value of the
VFD. During forward running, the positive value
is the motoring state while the negative value is
generating state. During reverse running, the
positive value is the generating state while the
negative value is the motoring state.
Range: -3000.0N· m – 3000.0 N· m
0–65535
0.00–99.99
0x000–0x123
Ones place: Control mode
0: Vector 0
1: Vector 1
2: VF control
3: Closed-loop vector control
Tens place: Control status
0: Speed control
1: Torque control
2: Position control
Hundreds place: Motor number
0: Motor 1
1: Motor 2
0.0%–300.0% (of the motor rated current)
-236-
Function parameter list
Default Modify
●
0.0A
●
0.0A
●
0.0 N· m
●
0
●
0.00%
●
0.00
●
0x000
●
180.0%
