Goodrive270 series VFD for fan and pump
Related parameter list:
Function
code
P05.01–
Digital input function selection
P05.06
P06.01– Digital output function
P06.04
P10.00 Simple PLC mode
Simple PLC memory
P10.01
P10.02 Multi-step speed 0
P10.03 Running time of step 0
P10.04 Multi-step speed 1
P10.05 Running time of step 1
P10.06 Multi-step speed 2
P10.07 Running time of step 2
P10.08 Multi-step speed 3
P10.09 Running time of step 3
P10.10 Multi-step speed 4
P10.11 Running time of step 4
P10.12 Multi-step speed 5
P10.13 Running time of step 5
P10.14 Multi-step speed 6
P10.15 Running time of step 6
P10.16 Multi-step speed 7
P10.17 Running time of step 7
P10.18 Multi-step speed 8
P10.19 Running time of step 8
P10.20 Multi-step speed 9
P10.21 Running time of step 9
P10.22 Multi-step speed 10
P10.23 Running time of step 10
P10.24 Multi-step speed 11
P10.25 Running time of step 11
Name
selection
selection
Description
23: Simple PLC stop reset
24: Pause simple PLC
25: Pause PID control
16: Simple PLC stage reached
17: Simple PLC cycle reached
0: Stop after running once
1: Keep running with the final value after
running once
2: Cyclic running
0: Without memory at power failure
1: With power-failure memory
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-121-
Basic operation guidelines
Default
0
0
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
