Goodrive270 series VFD for fan and pump
Function
Name
code
Running frequency
P93.01
in fire mode
Motor running
P93.02 direction in fire
mode
P93.03 Fire mode flag
Actual month and
P93.04 date when fire
activated
Actual time when
P93.05
fire activated
P93.06–
Reserved
P93.09
P94 group––HVAC
Function
Name
code
HVAC function
P94.00
selection
Sleep method
P94.01
selection
Sleep starting
P94.02
frequency
Sleep starting
P94.03
deviation
Description
except it is damaged.
If fire mode 2 is selected, the VFD always runs
except it stops upon the following faults: OUT1,
OUT2, OUT3, OC1, OC2, OC3, OV1, OV2,
OV3, and SPO.
0.00Hz–P00.03 (Max. output frequency)
0: Run at the default direction.
1: Run at the opposite direction.
0–1
If the fire mode duration reaches 5 minutes, this
flag is set to 1, and no warranty repair is
granted.
01.01–12.31
00.00–23.59
Description
0: Invalid
1: Valid
0: Run at the frequency lower limit
1: Sleep based on running frequency
2: Sleep based on deviation
P00.05–P00.04 (Upper limit of running
frequency)
When the running frequency is less than or
equal to the value and this situation lasts the
time longer than P94.04, sleep is allowed.
0.0–30.0% (relative to PID1 max. value)
When output is positive, if the feedback is
greater than the reference, sleep is allowed only
-257-
Function parameter list
Default Modify
○
50.00Hz
○
0
●
0
●
00.00
●
00.00
Default Modify
◎
0
○
0
○
5.00Hz
○
5.0%
