INVT Goodrive270 Series Operation Manual page 99

Goodrive270 series VFD for fan and pump
Function
code
Stator resistance of
P02.06
Rotor resistance of
P02.07
Leakage inductance of
P02.08
Mutual inductance of
P02.09
P02.10 No-load current of AM 1 0.1–6553.5A
P02.15 Rated power of SM 1
Rated frequency of
P02.16
Number of pole pairs of
P02.17
P02.18 Rated voltage of SM 1
P02.19 Rated current of SM 1
Stator resistance of
P02.20
Direct-axis inductance
P02.21
Quadrature-axis
P02.22
inductance of SM 1
Counter-emf constant
P02.23
Function selection of
P05.01– multifunction digital
P05.06 input terminals (S1–S4,
Switching between
P08.31
motor 1 and motor 2
Name
0.001–65.535Ω
AM 1
0.001–65.535Ω
AM 1
0.1–6553.5mH
AM 1
0.1–6553.5mH
AM 1
0.1–3000.0kW
0.01Hz–P00.03(Max. output frequency)
SM 1
1–50
SM 1
0–1200V
0.8–6000.0A
0.001–65.535Ω
SM 1
0.01–655.35mH
of SM 1
0.01–655.35mH
0–10000
of SM 1
35: Switch from motor 1 to motor 2
and HDIA)
0x00–0x14
Ones place: Switchover channel
0: Terminal
1: Modbus communication
2: PROFIBUS/CANopen communication
Description
-89-
Basic operation guidelines
Default
Depends
on model
Depends
on model
Depends
on model
Depends
on model
Depends
on model
Depends
on model
50.00Hz
2
Depends
on model
Depends
on model
Depends
on model
Depends
on model
Depends
on model
300
00
