Goodrive270 series VFD for fan and pump
Function
code
Speed control
P00.00
Enabling torque
P03.32
Torque setting
P03.11
method
Torque set
P03.12
through keypad
Torque reference
P03.13
filter time
Setting source of
forward rotation
P03.14 upper-limit
frequency in
torque control
Name
0: Sensorless vector control (SVC) mode 0
1: Sensorless vector control (SVC) mode 1
2: Space voltage vector control mode
mode Note: Before using a vector control mode (0 or 1),
enable the VFD to perform motor parameter
autotuning first.
0: Disable
control 1: Enable
0: Keypad (P03.12)
1: Keypad (P03.12)
2: AI1 (100% corresponding to triple the motor
rated current)
3: AI2
4: AI3 (same as the above)
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen communication
9: Ethernet communication
10: Reserved
11: PROFINET communication
12–17: Reserved
18: Keypad (for small power models)
Note: For setting sources 2–6, 100% corresponds
to triple the motor rated current.
-300.0%–300.0% (of the motor rated current)
0.000–10.000s
0: Keypad (P03.16)
1: AI1 (100% corresponding to the max. frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: PROFIBUS/CANopen communication (same as
the above)
Description
-83-
Basic operation guidelines
Default
2
0
0
50.0%
0.010s
0
