INVT Goodrive270 Series Operation Manual page 352

Goodrive270 series VFD for fan and pump
W4
Figure C-14 Mounting diagram for 380V 220–500kW VFDs with output reactors
Table C-7 Floor mounting dimensions for 380V 220–500 VFDs with output reactors
VFD model
W1
220–250kW 303
280–355kW 330
400–500kW 330
For details about the base mounting bracket, see Figure C-15 and Table C-8.
W1
H1
Base mounting bracket
Outline dimensions
(mm)
W4 H1 D1
350 1470 477
428 1619 552 1150 453 1571 225 185
430 1729 552 1280 432 1681 240 200
D1
H4
70
Mounting hole distance
(mm)
H2 H3 H4
980 471 1420 240 150
-342-
Dimension drawings
W2
d
H2
W3
d
H3
Hole
diameter
W2 W3
ø 14
ø 13
ø 13
Fixing
screw
M12
M10
M10
