Goodrive270 series VFD for fan and pump
Function
VFD status word 1
VFD status word 2
VFD fault code
VFD identification
code
Running frequency
Set frequency
Bus voltage
Address
Virtual output terminal command (0x00–0x0F)
200BH
Corresponding to local RO2/RO1/Reserved/Y1
Voltage setting (used when V/F separation is
implemented)
200CH
(0–1000, 1000 corresponding to 100.0% of the
motor rated voltage)
AO setting 1 (-1000–+1000, in which 1000
200DH
corresponding to 100.0%)
AO setting 2 (-1000–+1000, in which 1000
200EH
corresponding to 100.0%)
0001H: Forward running
0002H: Reverse running
0003H: Stopped
2100H
0004H: VFD in fault
0005H: POFF
0006H: Pre-exciting
Bit0=0: Not ready to run =1: Ready to run
Bit1–2=00: Motor 1
Bit3=0: Asynchronous motor =1: Synchronous
motor
Bit4=0: No overload pre-alarm
=1: Overload pre-alarm
Bit5–Bit6=00: Keypad-based control
2101H
=10: Communication-based control
Bit7: Reserved
Bit8=0: Speed control =1: Torque control
Bit9=0: Non position control
=1: Position control
Bit10–Bit11: =0: Vector 0
2102H See the description of fault types.
2103H GD270-----0x01c0
3000H 0–Fmax (Unit: 0.01Hz)
3001H 0–Fmax (Unit: 0.01Hz)
3002H 0.0–2000.0V (Unit: 0.1V)
Data description
=01: Motor 2
=01: Terminal-based control
=1: Vector 1
=2: Closed-loop vector
= 3: Space voltage vector
-305-
Communication protocol
R/W
R/W
R/W
R/W
R/W
R
R
R
R
R
Compatible
with CHF100A R
and CHV100
R
