Goodrive270 series VFD for fan and pump
Function
Name
code
Fault protection
P11.44
selection 14
Fault protection
P11.45
selection 15
Fault protection
P11.46
selection 16
Description
Tens place: Failed to identify the expansion card
in card slot 1
0: Coast to stop
1: Stop according to the stop mode
2: Pre-alarm and run
3: Keep running
Hundreds place: Failed to identify the expansion
card in card slot 2 (same as that for tens place)
Thousands place: Reserved
0x0000–0x0033
Ones place: Communication timeout of
expansion card at card slot 1
0: Coast to stop
1: Stop according to the stop mode
2: Pre-alarm and run
3: Keep running
Tens place: Communication timeout of
expansion card at card slot 2 (same as that for
ones place)
Hundreds place: Reserved
Thousands place: Reserved
0x0000–0x0300
Ones place: Reserved
Tens place: Reserved
Hundreds place: CAN slave fault in master/slave
synchrization
0: Coast to stop
1: Stop according to the stop mode
2: Pre-alarm and run
3: Keep running
Thousands place: Reserved
0x0000–0x3300
Ones place: Reserved
Tens place: Reserved
Hundreds place: Freezing fault
0: Coast to stop
1: Stop according to the stop mode
2: Pre-alarm and run
-224-
Function parameter list
Default Modify
○
0x0000
○
0x0000
○
0x0000
