Goodrive270 series VFD for fan and pump
Function
Name
code
HDIA switch-on
P05.20
delay
HDIA switch-off
P05.21
delay
P05.22–
Reserved
P05.23
P05.24 AI1 lower limit Used to define the relationship between the
Corresponding
P05.25 setting of AI1
lower limit
P05.26 AI1 upper limit
Corresponding
P05.27 setting of AI1
upper limit
AI1 input filter
P05.28
time
P05.29 AI2 lower limit
Corresponding
P05.30 setting of AI2
lower limit
AI2 middle
P05.31
value 1
Corresponding
P05.32 setting of AI2
middle value 1
AI2 middle
P05.33
value 2
Corresponding
P05.34 setting of AI2
middle value 2
P05.35 AI2 upper limit
Corresponding
P05.36 setting of AI2
upper limit
AI2 input filter
P05.37
time
Description
analog input voltage and its corresponding setting.
When the analog input voltage exceeds the range
from the upper limit to the lower limit, the upper
limit or lower limit is used.
When the analog input is current input,
0mA–20mA current corresponds to 0V–10V
voltage.
In different applications, 100.0% of the analog
setting corresponds to different nominal values.
See the descriptions of each application section
for details.
The following figure illustrates the cases of several
settings:
100%
-10V
AI2
Input filter time: to adjust the sensitivity of analog
input. Increasing the value properly can enhance
analog input anti-interference but may reduce the
sensitivity of analog input.
Note: AI1 supports the 0–10V/0–20mA input.
When AI1 selects the 0–20mA input, the
corresponding voltage of 20mA is 10V. AI2
supports the -10–+10V input.
P05.24 setting range: 0.00V–P05.26
-185-
Corresponding setting
AI
0
10V
20mA
AI1
-100%
Function parameter list
Default Modify
○
0.000s
○
0.000s
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.030s
-10.00
○
V
-100.0
○
%
○
0.00V
○
0.0%
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.030s
