Goodrive270 series VFD for fan and pump
Function
code
P08.02
P08.03
P08.04
P08.05
P08.06 Running frequency of jog
P08.07 ACC time for jogging
P08.08 DEC time for jogging
Switching frequency of
P08.19
Reference frequency of
P08.21
P08.28 Auto fault reset count
P08.29 Auto fault reset interval

5.5.8 Frequency setting

The VFD supports multiple kinds of frequency reference modes, which can be categorized into two
types: main reference channel and auxiliary reference channel.
There are two main reference channels, namely frequency reference channel A and frequency
reference channel B. These two channels support simple arithmetical operation between each other,
and they can be switched dynamically by setting multifunction terminals.
There is one input mode for auxiliary reference channel, namely terminal UP/DOWN switch input. By
setting function codes, you can enable the corresponding reference mode and the impact made on
the VFD frequency reference by this reference mode.
The VFD actual reference is comprised of the main reference channel and auxiliary reference
channel.
Name
ACC time 3
DEC time 3
ACC time 4
DEC time 4
ACC/DEC time
ACC/DEC time
Description
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.00Hz–P00.03(Max. output frequency)
0.0–3600.0s
0.0–3600.0s
0.00–P00.03(Max. frequency)
0.00Hz: No switchover
If the running frequency is greater than
P08.19, switch to ACC/DEC time 2.
0: Max. output frequency
1: Set frequency
2: 100Hz
Note: Valid only for straight-line ACC/DEC
0–10
0.1–3600.0s
-95-
Basic operation guidelines
Default
Depends
on model
Depends
on model
Depends
on model
Depends
on model
5.00Hz
Depends
on model
Depends
on model
0
0
0
1.0s
