INVT Goodrive270 Series Operation Manual page 328

Goodrive270 series VFD for fan and pump
Figure A-3 shows the expansion card installation procedure.
Remove the screws, take off the keypad, and distach the upper cover.
STEP 1
STEP 3
Aligh the EC fixing holes with the columns to snap into place.
STEP 5
Fasten the screws
查看细节节
节
STEP 7
After the cutting
Remove the screws and distach the lower cover.
Scale: 4:1
Wiring for installation
-318-
Expansion card
STEP 2
Insert the EC.
STEP 4
STEP 6
Cut the corresponding outlet frame.
STEP 8
EC wire binding
