EC-IO501-00 can be used in scenarios where the I/O interfaces of VFD cannot meet the application
requirements. It can provide 4 digital inputs, 1 digital output, 1 analog input, 1 analog output, and two
relay outputs. It is user-friendly, providing relay outputs through European-type screw terminals and
other inputs and outputs through spring terminals.
EC-IO501-00 terminal functions:
Category Terminal
Power supply
AI3—GND
AI and AO
AO2—GND
S5—COM
S6—COM
S7—COM
Digital
S8—COM
input/output
Y2—CME
Definition
Power
indicator
Name
PW External power
Analog input 1
Analog output 1
Digital input 1 
Digital input 2
Digital input 3
Digital input 4
Digital output
Off: The expansion card is disconnected from the
control board.
On: The expansion card is powered on.
Off: The expansion card is not powered on.
Used to provide input digital working power from
the external to the internal.
Voltage range: 12–24V
PW and +24V have been short connected before
delivery.

Input range: For AI3, 0(2)–10V or 0(4)–20mA
 Input impedance: 20kΩ for voltage input;
250Ω for current input

Whether voltage or current is used for input
is set through the corresponding function
code.

Resolution: 5mV when 10V corresponds to
50Hz

Error: ± 0.5% when input is above 5V or
10mA at 25° C

Output range: 0(2)–10V or 0(4)–20mA

Whether voltage or current is used for output
is set through the jumper J5

Error: ± 0.5% when output is above 5 V or 10
mA at 25° C
Internal impedance: 3.3kΩ

12–30V voltage input is acceptable

Bi-direction input terminal

Max. input frequency: 1kHz

Switch capacity: 200mA/30V

Output frequency range: 0–1kHz

The terminals CME and COM are shorted
