INVT Goodrive270 Series Operation Manual page 114

Goodrive270 series VFD for fan and pump
Value
26 Rotational speed (bipolar)
Value 2 set through PROFINET
27
communication
30 Rotational speed
31 Output torque (bipolar)
32 PID1 output
33 PID2 output
34 PID1 reference value
35 PID1 feedback value
36 PID2 reference value
37 PID2 feedback value
38–47 Reserved
Related parameter list:
Function
code
P06.00
P06.14
P06.15
P06.16
Function
Name
Reserved
AO1 output
AO0 output
Reserved
corresponds to 0.0% by default.
0–Synchronous rotation speed
corresponding to max. output frequency. A
negative value corresponds to 0.0% by
default.
0–1000
0–Twice the motor rated synchronous
rotation speed
0–Twice the motor rated torque. A negative
value corresponds to 0.0% by default.
Description
Reserved
0: Running frequency (0–Max. output
frequency)
1: Set frequency (0–Max. output
frequency)
2: Ramp reference frequency (0–Max.
output frequency)
3: Rotational speed (0–Speed
corresponding to max. output
frequency)
4: Output (0–Twice the inverter unit
rated current)
5: Output current (0–Twice the motor
rated current)
6: Output (0–1.5 times the inverter unit
rated voltage)
7: Output power (0–Twice the motor
-104-
Basic operation guidelines
Description
Default
0
0
0
