INVT Goodrive270 Series Operation Manual page 103

Goodrive270 series VFD for fan and pump
Function
code
Starting frequency of direct
P01.01
Starting frequency hold time 0.0–50.0s
P01.02
Braking current before start 0.0–100.0%
P01.03
DC braking time before start 0.00–50.00s
P01.04
ACC/DEC mode
P01.05
P01.08
Starting frequency of DC
P01.09
Wait time before DC braking
P01.10
DC braking current for stop 0.0–100.0%
P01.11
DC braking time for stop
P01.12
FWD/REV running
P01.13
FWD/REV running
P01.14
P01.15
Stop speed detection mode
P01.16
Terminal-based running
command protection at
P01.18
Action selected when
running frequency less than
frequency lower limit (valid
P01.19
when frequency lower limit
Wake-up-from-sleep delay
P01.20
Name
start
Stop mode
braking for stop
for stop
deadzone time
switching mode
Stop speed
power-on
greater than 0)
Description
For AMs, you do not need to modify
parameters P01.35–P01.41.
0.00–50.00Hz
0: Linear
1: S curve
Note: If mode 1 is selected, set P01.06,
P01.07, P01.27 and P01.28.
0: Decelerate to stop
1: Coast to stop
0.00Hz–P00.03(Max. output frequency)
0.00–50.00s
0.00–50.00s
0.0–3600.0s
0: Switch at zero frequency
1: Switch at the starting frequency
2: Switch after the speed reaches the stop
speed with a delay
0.00–100.00Hz
0: Detect by the set speed (unique in
space voltage vector control mode)
1: Detect by the feedback speed
0: The terminal running command is
invalid at power-on
1: The terminal running command is valid
at power-on
0: Run at the frequency lower limit
1: Stop
2: Sleep
0.0–3600.0s (valid when P01.19 is 2)
-93-
Basic operation guidelines
Default
0.50Hz
0.0s
0.0%
0.00s
0
0
0.00Hz
0.00s
0.0%
0.00s
0.0s
0
0.50 Hz
1
0
0
0.0s
